PLED120W Series– Fixed Output & Dimmable
Flicker-Free LED Drivers
Constant Current & Constant Voltage with Isolation
Black Magic Thermal Advantage™ Aluminum Housing
Electrical Specifications
Input Voltage Range:
Input Over-Voltage:
Frequency:
Power Factor:
Inrush Current:
Input Current:
Maximum Power:
Current Accuracy:
Load Regulation:
THD:
Ripple & Noise:
(Vpk-pk)
Ripple:
(Ipk-pk)
Start-up Time:
Leakage Current:
Hold Up Time:
Output Protection:
100-277 Vac Nom. (90-305 V Min/Max)
Can endure 320Vac for 48 Hrs, 350Vac for 2 Hrs
50/60 Hz Nom. (47-63 Hz Min/Max)
>0.90 @ > 70% load, 120-277V
60.0 Amps max @ 277 Vac, cold start, full load
0.60 Amps max @ 230 Vac, 1.20 A max @ 120 Vac
120W
± 3%
± 4%
< 20% @ > 70% load, 120-277V
_
5% Vo max @ 20 MHz BW, Full load output
in parallel with 0.1 μF ceramic & 10 μF Electrolytic
5% Io max @ 20 MHz BW, Full load output
in parallel with 0.1 μF ceramic & 10 μFElectrolytic.
120 Hz component (Flicker Free)
150mS typical @ Full Load, 120Vac/60Hz (1000mS max)
0.68 mA max @ 120Vac, 0.75 mA max @ 277Vac
30mS typical @ Full Load, 277Vac
Over-Voltage, Over-Current, and Short Circuit
(auto-recovery)
• Total Power: 120 Watts
• Input Voltage: 100-277 Vac Nom.
• UL Dry & Damp Location Rated
• IP66 & NEMA6
• UL Type HL Rated for Hazardous Locations
• UL Sign Components Manual (S.A.M. Models)
Constant Current Versions - Product Specifications
Model Number
PLED120W-343-C0350-XX
PLED120W-266-C0450-XX
PLED120W-171-C0700-XX
PLED120W-114-C1050-XX
PLED120W-086-C1400-XX
PLED120W-068-C1750-XX
PLED120W-057-C2100-XX
PLED120W-049-C2450-XX
PLED120W-043-C2800-XX
PLED120W-038-C3150-XX
PLED120W-034-C3500-XX
PLED120W-028-C4200-XX
PLED120W-024-C5000-XX
Output Current Output Voltage Max Output
Typical
(mA ±5%)
Range
(Vdc)
Power
(W)
Efficiency
350
450
700
1050
1400
1750
2100
2450
2800
3150
3500
4200
5000
114-343
89-266
57-171
38-114
29-86
23-68
19-57
17-49
15-43
13-38
12-34
10-28
8-24
120
120
120
120
120
120
120
120
120
120
120
120
120
92%
92%
91%
91%
91%
91%
90%
90%
90%
90%
89%
89%
89%
Environmental Specifications
Minimum Starting Temp:
Maximum Case Temp.
Storage Temperature:
Humidity:
Cooling:
Vibration Frequency:
MTBF:
EMC:
Impact Resistance:
Weight:
-30ºC
90°C
-40ºC to +85ºC
5% to 95%
Convection
5-55 Hz/2g, 30 minutes
280,000 Hours at full load and 40ºC ambient conditions
per MIL-217F Notice 2
FCC 47CFR Part 15 Class B compliant
1g/s
24.4 oz (690 grams)
-XX
indicates dimming options are available. See options at left. Blank = fixed current output
Constant Voltage Versions - Product Specifications
Model Number
PLED120W-024
PLED120W-028
PLED120W-034
PLED120W-038
PLED120W-043
PLED120W-049
PLED120W-057
PLED120W-068
PLED120W-086
PLED120W-114
PLED120W-171
PLED120W-266
PLED120W-343
Ordering Options:
-D:
0-10V & Resistance dimmable models dim 100-10%. Two extra wires on the output
side (+Purple/-Gray). Compatible with most quality 0-10V wall dimmers. See page 3.
•
Output Voltage Output Current
(Vdc ±5%)
Range
(mA)
24
28
34
38
43
49
57
68
86
114
171
266
343
1250-5000
1050-4200
875-3500
788-3150
700-2800
613-2450
525-2100
438-1750
350-1400
263-1050
175-700
113-450
88-350
Max Output
Power
(W)
120
120
120
120
120
120
120
120
120
120
120
120
120
Typical
Efficiency
89%
89%
89%
90%
90%
90%
90%
91%
91%
91%
91%
92%
92%
-D3: 3-wire dimmable models dim 100-10%. Three extra wires on the output side
(Yellow/Purple/Gray). Compatible with potentiometer dimming. See page 3.
-PD: PWM Dimmable models. Two extra wires on the output side(+Purple/-Gray). Dims
via positive 10% to 100% Duty Cycle, 200Hz to 1KHz, 0-10V Pulse. See page 4.
Sign Components Manual
E332160
•
Indicates S.A.M.
Note:
LED drivers are designed and intended to operate LED loads only.
Non-LED loading may be outside the specified design limits of our
LED drivers, and therefore cannot be covered by any warranty.
If you desire to use our LED drivers to operate non-LED loads
please contact us to discuss compatibility.
Specifications subject to change without notice.
Rev 9-11-15
Thomas Research Products • 1225 Bowes Rd • Elgin, IL 60123 • T 847-515-3057 • F 847-515-3047 • www.trpssl.com
PLED120W Series
SSL Solutions Faster Than The Speed Of Light
®
Pg 2 of 4
Dimensions - IN [mm]
7.2±0.047 [183±1.2]
1.165 [29.6]
0.236 [6]
0.71 [18]
1.34 [34]
2.24±0.12 [57.0±3]
0.236 [6]
0.16 [4]
2.24±0.12 [57.0±3]
0.31 [8]
6.8 [173]
7.6 [193]
WIRE SPECS:
Input Leads:
18 AWG, rated 600 V, 105C, min.
Output Leads:
18 AWG, rated 300 V, 105C, min.
Dimming Leads:
22 AWG, rated 300 V, 105C.
All wires are stranded with solder dipped ends.
12.0 Min [305 Min]
0.39±0.04 [10±1]
Dimming
Purple (Dim+)
Gray (Dim-)
2.7 [68.6]
Tc = 90°C max
12.0 Min [305 Min]
0.39±0.04 [10±1]
1.47 [37.3]
2.33 [59.2]
OUPUT
Red (V+)
Blue (V-)
INPUT
Black (L)
White (N)
Green/Yellow (G)
1.000
0.975
0.950
0.925
Power Factor / Load
30%
25%
20%
THD / Load
120Vac
230Vac
277Vac
Typical Efficiency / Load
100%
95%
Efficiency
90%
85%
80%
75%
70%
40%
0.900
0.875
0.850
0.825
0.800
40%
60%
80%
100%
120Vac
230Vac
277Vac
THD
PF
15%
10%
5%
0%
40%
60%
80%
100%
120Vac
230Vac
277Vac
Load
Load
Normalized Output Voltage
60%
80%
100%
Lifetime / Case Temperature
140
130
120
110
100
90
80
70
60
50
40
30
20
10
0
50
Full Load @ 120Vac
Safety and EMC Compliance
UL/CUL
CE
UL8750 & CAN/CSA-22.2 No. 250.13-12, UL1012/CSA-C22.2 No.107.1
EN 61347-1, EN61347-2-13
Limits and methods of measurement of radio disturbance characteristics
of electrical lighting and similar equipment.
Part 3-2: Limits for harmonic current emissions Class C, >80% Rated Power
Part 3-3: Limitation of voltage changes, voltage fluctuations and flicker.
Part 4-5: Surge Immunity test, 2 kV L-N, 4 kV L-G & N-G
Lifetime
(kHrs)
FCC, 47CFR Part 15 Class B
EN 55015
EN 61000-3-2
EN 61000-3-3
EN 61000-4-5
55
Case Hotspot Temperature
(°C)
60
65
70
75
80
85
90
Note:
Life calculations are based on reliability with confidence using
a 90% confidence level and <5% failure rate. At a confidence
level of 90% it is expected that <5% of the parts will fail at
the rated life provided. (Failure is defined as a driver drifting
outside specification, rather than fail to operate)
UL Conditions of Acceptability
See website for additional information
Thomas Research Products • 1225 Bowes Rd • Elgin, IL 60123 • T 847-515-3057 • F 847-515-3047 • www.trpssl.com
PLED120W Series
SSL Solutions Faster Than The Speed Of Light
®
Pg 3 of 4
"-D" and "-D3" Options: 0-10VDC and Resistance Dimming
Parameters
10V Output, Yellow Wire
10 Output Source Current, Yellow Wire
Absolute Voltage Range on 0-10V (+) Purple Wire
Source Current out of 0-10V Purple Wire
Minimum
9.2V
0mA
-2.0V
0mA
Typical
10.0V
—
—
—
Maximum
10.8V
10mA
+15V
2mA
Typical Dimming Circuit
Dim (+) Purple
3-Wire Dimming Typical Circuit
10V Output
(Yellow)
0-10V Input
(Purple)
Return
(Gray)
20K
Potentiometer
PLED120W-xxx-Cxxxx-D
IP710
Wall Dimmer
Dim (-) Gray
PLED120W-xxx-Cxxxx-D3
(Dimmer must be current-sink type control)
100
90
80
70
60
50
40
30
20
10
0
Output Current / 0-10VDC Dimming Input
Output Current %
0V
1V
2V
3V
Dimming Input
(Vdc)
4V
5V
6V
7V
8V
9V
10V
Notes:
1.
2.
3.
4.
0-10V dimmable version comes with an extra two wires +Purple/-Gray on the output side.
Compatible with most 0-10V Wall Slide dimmers and direct 0-10V analog signal. Recommended dimmer is Leviton IP710 or equivalent
0-10V dimmable version is not intended to dim to zero (off). Will be Iout <10% @ Vdim <1.0V
0-10V dimmable version output will be 100% with Purple/Gray open and minimum with Purple/Gray Shorted.
Thomas Research Products • 1225 Bowes Rd • Elgin, IL 60123 • T 847-515-3057 • F 847-515-3047 • www.trpssl.com
PLED120W Series
SSL Solutions Faster Than The Speed Of Light
®
Pg 4 of 4
"-PD" Option: PWM Dimming
Parameters
Absolute Maximum Voltage Range on PWM Input (Purple Wire)
Input LOW Level Voltage Range (Purple Wire)
Input HIGH Level Voltage Range (Purple Wire)
Current into PWM Input (Purple Wire)
Source Current out of PWM Input (Purple Wire)
PWM Input Signal Frequency
PWM Input Signal Positive Duty Cycle
Minimum
-2.0V
-2.0V
+9.0V
0mA
0mA
500Hz
0%
Typical
10V
0V
10V
—
—
—
10-90%
Maximum
+15V
+5.5V
+15V
1.2mA
2mA
1500Hz
100%
PWM Positive Dimming Typical Circuit
PWM (+) Purple
PLED120W-xxx-Cxxxx-PD
PWM In
PWM (-) Gray
100
90
80
70
60
50
40
30
20
10
0
Output Current / 1.0 kHz Positive Duty Cycle
Output Current %
0%
10%
20%
30%
Positive Duty Cycle
40%
50%
60%
70%
80%
90%
100%
Notes:
1. PWM Dimmable version comes with an extra 2 wires +Purple/-Gray on the output side.
2. Below 10% Duty cycle proper dimming operation is not assured. Unit is not intended to turn off at <10% Duty Cycle.
3. PWM dimmable version output will be 100% with Purple/Gray open and minimum with Purple/Gray Shorted.
Thomas Research Products • 1225 Bowes Rd • Elgin, IL 60123 • T 847-515-3057 • F 847-515-3047 • www.trpssl.com
