Terminals
®
®
Vinyl Insulated Ring – Insulation Grip
Cat.
No.
18RA-4
RA77
18RA-6
RA857
18RA-8
RA867
18RA-10
RA877
18RA-14
RA717
18RA-516
RA727
18RA-38
RA737
14RB-4
RB1327
14RB-6
RB857
14RB-8
RB867
14RB-10
RB877
14RB-14
RB717
14RB-516
RB727
14RB-38
RB-737
10RC-6
RC337
10RC-8
RC777
10RC-10
RC367
10RC-14
RC717
10RC-516
RC707
10RC-38
RC737
Pkg.
Qty.
100
1000
100
1000
100
1000
100
1000
100
1000
100
1000
100
1000
100
1000
100
1000
100
1000
100
1000
100
1000
100
1000
100
1000
50
500
50
500
50
500
50
500
50
500
50
500
Wire
Range
22-16
22-16
22-16
22-16
22-16
22-16
22-16
22-16
22-16
22-16
22-16
22-16
22-16
22-16
18-14
18-14
18-14
18-14
18-14
18-14
18-14
18-14
18-14
18-14
18-14
18-14
18-14
18-14
12-10
12-10
12-10
12-10
12-10
12-10
12-10
12-10
12-10
12-10
12-10
12-10
Max.
Ins.
.150
.150
.150
.150
.150
.150
.150
.150
.150
.150
.150
.150
.150
.150
.170
.170
.170
.170
.170
.170
.170
.170
.170
.170
.170
.170
.170
.170
.210
.210
.210
.210
.210
.210
.210
.210
.210
.210
.210
.210
Bolt
Hole
#4
#4
#6
#6
#8
#8
#10
#10
b"
b"
j"
j"
c"
c"
#4
#4
#6
#6
#8
#8
#10
#10
b"
b"
j"
j"
c"
c"
#6
#6
#8
#8
#10
#10
b"
b"
j"
j"
c"
c"
Wt./Lbs.
Per
1000
3
3
3
3
3
3
3
3
4
4
4
4
4
4
3
3
3
3
3
3
3
3
4
4
4
4
4
4
5
5
5
5
5
5
6
6
6
6
6
6
Dimensions
A
.97
.97
.94
.94
.97
.97
.97
.97
1.13
1.13
1.13
1.13
1.24
1.24
.94
.94
.97
.97
.97
.97
.97
.97
1.14
1.14
1.15
1.15
1.16
1.16
1.06
1.06
1.06
1.06
1.06
1.06
1.16
1.16
1.17
1.17
1.29
1.29
B
.31
.31
.25
.25
.31
.31
.31
.31
.50
.50
.50
.50
.54
.54
.25
.25
.31
.31
.31
.31
.31
.31
.50
.50
.50
.50
.54
.54
.31
.31
.31
.31
.31
.31
.50
.50
.50
.50
.59
.59
C
.27
.27
.27
.27
.27
.27
.27
.27
.37
.37
.37
.37
.37
.37
.27
.27
.27
.27
.27
.27
.27
.27
.38
.38
.38
.38
.38
.38
.27
.27
.27
.27
.27
.27
.27
.27
.37
.37
.44
.44
M
.81
.81
.81
.81
.81
.81
.81
.81
.88
.88
.88
.88
.91
.91
.81
.81
.81
.81
.81
.81
.81
.81
.89
.89
.89
.89
.91
.91
.90
.90
.90
.90
.90
.90
.90
.90
.92
.92
.99
.99
These ring terminals are self-insulated with a
PVC insulation sleeve of extra length to give pro-
tection and relieve bending stress at wire’s flex
point. Brazed seam barrel is serrated to obtain
high pull-out value. Terminal is made of high
conductivity electrolytic copper, electro-tin plated.
Insulation material is color-coded:
Color Code
red
blue
yellow
Stock Thickness:
RA & RB =
RC
=
Wire Range
22-16
18-14
12-10
.03
.04
Most standard bulk catalog numbers can be put
on Mylar Tape for reel fed applications (i.e.
12050 tool and application dies). See pages
K61- K62.
Please put the suffix M for Mylar Tape RA2573M.
(Bulk number 1000 and 500 packages.)
K
Sta-Kon
®
U.L. Listed E9809
Installing tools: WT145C, WT2000, WT112M, ERG-2001, ERG-2003
M
C
B
A
© 2002 Thomas & Betts Corporation. Specifications are subject to change without notice.
www.tnb.com
K11
