3-103634-4
AMPMODU MTE, PCB Mount Header, Right Angle, Wire-to-Board, 12 Position, .1 in
[2.54 mm] Centerline, Fully Shrouded, Tin, Through Hole - Solder, Signal
3-103634-4
ACTIVE
AMPMODU
|
AMPMODU MTE
TE Internal #: 3-103634-4
AMPMODU MTE, PCB Mount Header, Right Angle, Wire-to-Board,
12 Position, .1 in [2.54 mm] Centerline, Fully Shrouded, Tin,
Through Hole - Solder, Signal
View on TE.com >
Connectors
>
PCB Connectors
>
PCB Headers & Receptacles
Connector System:
Wire-to-Board
Number of Positions:
12
Number of Rows:
1
Centerline (Pitch):
2.54 mm [ .1 in ]
PCB Mount Orientation:
Right Angle
Features
Product Type Features
Connector System
Header Type
Sealable
Connector & Contact Terminates To
PCB Connector Assembly Type
Configuration Features
Number of Positions
Number of Rows
PCB Mount Orientation
Electrical Characteristics
Termination Resistance
Insulation Resistance
Dielectric Withstanding Voltage (Max)
Body Features
Primary Product Color
Contact Features
Contact Mating Area Length
Mating Square Post Dimension
Wire-to-Board
Fully Shrouded
No
Printed Circuit Board
PCB Mount Header
12
1
Right Angle
15 mΩ
5000 MΩ
600 V
Black
5.84 mm[.23 in]
.64 mm[.025 in]
2.54 µm[100 µin]
05/26/2022 11:37PM | Page 1
PCB
522 6752
For support call+1 800
Contact Termination Area Plating Material Thickness
3-103634-4
AMPMODU MTE, PCB Mount Header, Right Angle, Wire-to-Board, 12 Position, .1 in
[2.54 mm] Centerline, Fully Shrouded, Tin, Through Hole - Solder, Signal
Mating Square Post Dimension
PCB Contact Termination Area Plating Material Thickness
Contact Mating Area Plating Material Thickness
PCB Contact Termination Area Plating Material Finish
Contact Shape & Form
Contact Mating Area Plating Material Finish
PCB Contact Termination Area Plating Material
Contact Base Material
Contact Mating Area Plating Material
Contact Type
Contact Current Rating (Max)
Termination Features
Square Termination Post & Tail Dimension
Termination Post & Tail Length
Termination Method to Printed Circuit Board
Mechanical Attachment
Mating Alignment Type
Mating Retention
Mating Retention Type
Connector Mounting Type
Mating Alignment
PCB Mount Alignment
PCB Mount Retention
Housing Features
Housing Material
Centerline (Pitch)
Dimensions
Connector Length
Connector Height
PCB Thickness (Recommended)
Usage Conditions
Operating Temperature Range
Operation/Application
For support call+1 800 522 6752
.64 mm[.025 in]
2.54 µm[100 µin]
2.54 µm[100 µin]
Bright
Square
Bright
Tin
Brass
Tin
Pin
3A
.64 mm[.025 in]
3.3 mm[.13 in]
Through Hole - Solder
Latched, Polarization
With
Polarized Lock
Board Mount
With
Without
Without
Thermoplastic
2.54 mm[.1 in]
33.02 mm[1.3 in]
6.99 mm[.275 in]
1.57 mm[.062 in]
-65 – 105 °C[-85 – 221 °F]
Circuit Application
Signal
05/26/2022 11:37PM | Page 2
3-103634-4
AMPMODU MTE, PCB Mount Header, Right Angle, Wire-to-Board, 12 Position, .1 in
[2.54 mm] Centerline, Fully Shrouded, Tin, Through Hole - Solder, Signal
Circuit Application
Industry Standards
CSA Rating
Approved Standards
UL Flammability Rating
Packaging Features
Packaging Quantity
Packaging Type
Signal
Certified
CSA LR7189, UL E28476
UL 94V-0
16
Box, Tube
Product Compliance
For compliance documentation, visit the product page on TE.com>
EU RoHS Directive 2011/65/EU
EU ELV Directive 2000/53/EC
China RoHS 2 Directive MIIT Order No 32, 2016
EU REACH Regulation (EC) No. 1907/2006
Compliant
Compliant
No Restricted Materials Above Threshold
Current ECHA Candidate List: JAN 2022
(223)
Candidate List Declared Against: JAN 2022
(223)
Does not contain REACH SVHC
Low Halogen - Br, Cl, F, I < 900 ppm per
homogenous material. Also BFR/CFR/PVC
Free
Reflow solder capable to 260°C
Halogen Content
Solder Process Capability
Product Compliance Disclaimer
This information is provided based on reasonable inquiry of our suppliers and represents our current actual knowledge
based on the information they provided. This information is subject to change. The part numbers that TE has identified as
EU RoHS compliant have a maximum concentration of 0.1% by weight in homogenous materials for lead, hexavalent
chromium, mercury, PBB, PBDE, DBP, BBP, DEHP, DIBP, and 0.01% for cadmium, or qualify for an exemption to these
limits as defined in the Annexes of Directive 2011/65/EU (RoHS2). Finished electrical and electronic equipment products
will be CE marked as required by Directive 2011/65/EU. Components may not be CE marked. Additionally, the part
numbers that TE has identified as EU ELV compliant have a maximum concentration of 0.1% by weight in homogenous
materials for lead, hexavalent chromium, and mercury, and 0.01% for cadmium, or qualify for an exemption to these limits
as defined in the Annexes of Directive 2000/53/EC (ELV). Regarding the REACH Regulation, the information TE provides
on SVHC in articles for this part number is based on the latest European Chemicals Agency (ECHA) ‘Guidance on
requirements for substances in articles’ posted at this URL: https://echa.europa.eu/guidance-documents/guidance-on-
reach
