3-171825-0 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 3-171825-0

3-171825-0: DescriptionV-TYPE E.I.S.CONN. 10P ASSY; CategoryThe connector The connector; File Size43KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

3-171825-0 Overview

V-TYPE E.I.S.CONN. 10P ASSY

3-171825-0 Parametric

Parameter Name	Attribute value
Brand Name	AMP
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1483095221
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	AMP
body width	0.209 inch
subject depth	0.409 inch
body length	0.984 inch
Body/casing type	RECEPTACLE
Connector type	BOARD CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact completed and terminated	Tin (Sn)
Contact point gender	MALE
Contact material	BRASS
contact mode	RECTANGULAR
Contact resistance	20 mΩ
Contact style	SQ PIN-SKT
DIN compliance	NO
Dielectric withstand voltage	1000VAC V
Durability	25 Cycles
Filter function	NO
IEC compliance	NO
Insulation resistance	500000000 Ω
Insulator color	BLACK
insulator material	NYLON
JESD-609 code	e3
MIL compliance	NO
Plug contact pitch	0.098 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	1
Number of rows loaded	1
Maximum operating temperature	95 °C
Minimum operating temperature	-20 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
Plating thickness	31u inch
Rated current (signal)	3.5 A
Guideline	UL, CSA
reliability	COMMERCIAL
Terminal length	0.142 inch
Terminal pitch	2.5 mm
Termination type	SOLDER
Total number of contacts	10
UL Flammability Code	94V-0

Preview

Download Datasheet

View All

3-171825-0 Related Products

	3-171825-0	2-173051-0	SMDT0402ABC2640N	SMDT0402ABOY2641N	SMDT0402ATC8251	SMDT2010CTD2641N	B41042A0127M001	5-171825-0
Description	V-TYPE E.I.S.CONN. 10P ASSY	20 CONTACT(S), MALE, STRAIGHT TWO PART BOARD CONNECTOR, SOLDER	Fixed Resistor, Thin Film, 0.0625W, 264ohm, 25V, 0.05% +/-Tol, 25ppm/Cel, Surface Mount, 0402, CHIP	Fixed Resistor, Thin Film, 0.0625W, 2640ohm, 25V, 0.05% +/-Tol, 3ppm/Cel, Surface Mount, 0402, CHIP	Fixed Resistor, Thin Film, 0.0625W, 8250ohm, 25V, 0.05% +/-Tol, 25ppm/Cel, Surface Mount, 0402, CHIP	Fixed Resistor, Thin Film, 0.25W, 2640ohm, 150V, 0.25% +/-Tol, 50ppm/Cel, Surface Mount, 2010, CHIP	CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, NON-POLARIZED, 80V, 120uF, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT	V-TYPE E.I.S.CONN. 10P ASSY
Reach Compliance Code	compliant	unknown	compliant	compliant	compliant	compliant	compliant	compliant
Is it Rohs certified?	conform to	-	conform to	conform to	conform to	conform to	conform to	conform to
Objectid	1483095221	-	145059320006	145059334658	145059037894	145058970839	1432714708	1483095269
ECCN code	EAR99	-	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Other features	AMP	AMP	PRECISION	PRECISION	PRECISION	PRECISION	-	AMP
JESD-609 code	e3	-	e3	e3	e3	e3	-	e3
Maximum operating temperature	95 °C	-	155 °C	155 °C	155 °C	155 °C	105 °C	95 °C
Minimum operating temperature	-20 °C	-	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-20 °C
Installation features	-	-	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	THROUGH HOLE MOUNT	-
Number of terminals	-	-	2	2	2	2	2	-
method of packing	-	-	BULK	BULK	TR, Paper, 7 Inch	TR, Embossed Plastic, 7 Inch	BULK	-
surface mount	-	-	YES	YES	YES	YES	NO	-
Terminal shape	-	-	WRAPAROUND	WRAPAROUND	WRAPAROUND	WRAPAROUND	WIRE	-
