A/L UNIV HDR 50P VERT SHT LAT BLUE
AMP-LATCH
|
Universal Headers
3-5499160-0
TE Internal Number: 3-5499160-0
Always EU RoHS/ELV Compliant
Centerline
2.54 mm [ .1 in ]
PCB Mount Retention
Without
Active
PCB Mounting Orientation
Vertical
Termination Method to PC Board
Through Hole
Shrouded
Yes
PRODUCT DRAWING
English
3D PDF
Product Drawings
HEADER ASSY, UNIVERSAL, AMP-LATCH
PDF
English
CAD Files
Customer View Model
2D_DXF.ZIP
English
Customer View Model
3D_IGS.ZIP
English
Customer View Model
3D_STP.ZIP
English
3D PDF
PDF
English
Product Specifications
Product Specification
AMP-LATCH And IDC Header Connectors, .100 X .100 Inch Grid
PDF
English
Please review product documents or
contact us
for the latest agency approval information. Please Note: Use the Product
Drawing for all design activity.
Product Type Features
PCB Mounting Orientation
Shrouded
Row-to-Row Spacing
Connector Style
Profile
Vertical
Yes
2.54 mm [ .1 in ]
Plug
Standard
Profile
Applies To
Product Type
Board Standoff
Connector Type
Connector System
Ejection Latches
Latch Type
Standard
Printed Circuit Board
Connector
Without
Header
Wire-to-Board
With
Short
Configuration Features
Number of Positions
Number of Rows
50
2
Electrical Characteristics
Operating Voltage (VAC)
Insulation Resistance (MΩ)
250
5000
Body Features
Post Size
Header Type
.64 mm [ .025 in ]
Universal Ejection Pin Headers
Contact Features
Contact Mating Area Plating Material
Contact Mating Area Plating Thickness
Contact Design
Contact Transmits (Typical)
Solder Tail Contact Plating Material
Contact Current Rating (A)
Contact Base Material
Contact Type
Contact Termination Area Plating Material
Contact Termination Area Plating Thickness
Gold
.76 µm [ 30 µin ]
Square Post
Signal (Data)
Tin
1
Brass, Phosphor Bronze
Pin
Tin
2.54 µm [ 100 µin ]
Termination Features
Termination Method to PC Board
Termination Post Length
Through Hole
2.79 mm [ .11 in ]
Mechanical Attachment
PCB Mount Retention
Mating Alignment Type
Mating Connector Lock
Mating Connector Lock Type
Mating Alignment
Without
Center
With
Latch
With
Polarization
Panel Mount Retention
Mating Retention
PCB Mount Alignment
With
Without
With
Without
Housing Features
Centerline
Housing Color
Housing Style
Housing Material
2.54 mm [ .1 in ]
Blue
4-Sided
Glass Filled Nylon/Polyester
Dimensions
Height
Length
PCB Thickness (Recommended)
Shrouded End Dimension
13.94 mm [ .548 in ]
82.8 mm [ 3.26 in ]
1.57 mm [ .062 in ]
3.81 mm [ .15 in ]
Usage Conditions
Temperature Rating
Operating Temperature Range (°C)
Standard
-65 – 105
Operation/Application
For Use With
Mates with Receptacles
Industry Standards
UL Flammability Rating
UL 94V-0
Packaging Features
Packaging Method
Packaging Quantity
Package
24
Product Compliance
Statement of Compliance
PDF
VIEW ALL PRODUCT COMPLIANCE
Products
- 10 Results
View All
Compare 0/10
Relation Type
RELATIONSHIP
Mating Products
Used to identify Mating Parts
See All Mating Products
PRODUCT - MATING PRODUCTS
Always EU RoHS/ELV Compliant
Centerline
2.54 mm
PCB Mount Retention
Without
PCB Mounting Orientation
Vertical
Termination Method to PC Board
Through Hole - Solder
Termination Method to
Wire/Cable
Insulation
Displacement Crimp (IDC)
Connectors - Ribbon Cable Connectors
AMP- LATCH | AMP- LATCH - NOVO
050 NOVO DUAL 30DP
FT - 1-1658624-0
TE INTERNAL NUMBER: 1-1658624-0
Active
RELATIONSHIP
Mating Products
Used to identify Mating Parts
PRODUCT - MATING PRODUCTS
See All Mating Products
Always EU RoHS/ELV Compliant
Centerline
2.54 mm
PCB Mount Retention
Without
PCB Mounting Orientation
Vertical
Termination Method to PC Board
Through Hole - Solder
Termination Method to
Wire/Cable
Insulation
Displacement Crimp (IDC)
Connectors - Ribbon Cable Connectors
AMP- LATCH | AMP- LATCH - NOVO
50 NOVO MIL 15DP,
LEAD FREE - 1-1658620-0
TE INTERNAL NUMBER: 1-1658620-0
Active
RELATIONSHIP
Mating Products
Used to identify Mating Parts
PRODUCT - MATING PRODUCTS
See All Mating Products
Always EU RoHS/ELV Compliant
Centerline
2.54 mm
PCB Mount Retention
Without
PCB Mounting Orientation
Vertical
Termination Method to PC Board
Through Hole - Solder
Termination Method to
Wire/Cable
Insulation
Displacement Crimp (IDC)
Connectors - Ribbon Cable Connectors
AMP- LATCH | AMP- LATCH - NOVO
50 NOVO MIL 30DP,
LEAD FREE - 1-1658623-0
TE INTERNAL NUMBER: 1-1658623-0
Active
