The TRPE03EL2-E1G SFP series of fiber optic transceivers w ith
integrated digital diagnostics monitoring functionality provide a
quick and reliable interface for long reach (
LR2)applications. The
diagnostic functions, alarm and w arning features as described
in the Multi-Source A greement (
MSA )document,SFF-8472 (
Rev.
2
9.4) are provided via an I C serial interface.
,
Available products under this series are compliant w ith applicable
SON ET/SD H standards for OC-3/STM-1. A ll modules satisfy Class I
Laser Safety requirements in accordance w ith the U .S. FD A /CD RH
and international IEC-60825 standards.
The TRPE03EL2-E1G transceivers connect to standard 20-pad
SFP connectors for hot plug capability. This allow s the system
designer to make configuration changes or maintenance by
simply plugging in different types of transceivers w ithout
removing the pow er supply from the host system.
The transceivers have colored bail-type latches,w hich offer an
easy and convenient w ay to release the modules. The latch is
compliant w ith the SFP MSA .
The transmitter design incorporates a highly reliable 1550nm
InG aA sP laser and a driver circuit. The receiver features a
transimpedance amplifier IC optimized for high sensitivity and
w ide dynamic range. The transmitter and receiver D ATA interfaces
are AC-coupled internally. LVTTL Transmitter D isable control
input and Loss of Signal output interfaces are also provided.
The transceivers operate from a single +3.3V pow er supply
over tw o operating case temperature ranges of -5°C to +70°C
(
Commercial) or -40°C to +85°C (
,
Industrial) The housing is made
.
of metal for EMI immunity.
F ea tu res
þ
Compatible w ith SFP MSA
þ
Compliant w ith SON ET/SD H OC-3/STM-1 (
155Mb/s)
þ
Lead Free D esign & Fully RoH S Compliant
þ
SON ET/SD H LR2 Reach
þ
D igital D iagnostics through Serial Interface
þ
Internal Calibration for D igital D iagnostics
þ
Eye Safe (
Class I Laser Safety)
þ
D uplex LC Optical Interface
þ
-40°C to +85°C Operating Case Temperature Option
þ
Excellent EMI & ESD Protection
þ
H ot-pluggable
þ
TX Fault & Loss of Signal Outputs
þ
TX D isable Input
þ
Single +3.3V Pow er Supply
A bsolute Maximum R atings
Parameter
Storage Temperature
Operating Case Temperature
1
Supply Voltage
Input Voltage
1
Symbol
T
st
Commercial
Industrial
T
op
V
cc
V
in
Minimum
- 40
-5
- 40
0
0
Maximum
+ 85
+ 70
+ 85
+ 5.0
V
cc
Units
°C
°C
V
V
Measured on top side of SFP module at the front center vent hole of the cage.
An Oplink Company
S0123,Rev.02
2011-03-30
TRPE 0 3E L2-E 1G Single Mode
Transmitter Perf
ormance C haracteristics
(Over Operating Case Temperature,
V
CC
= 3.13 to 3.47V)
All parameters guaranteed only at typical data rate
Parameter
Operating D ata Rate
1
Average Optical Output Pow er (
coupled into single mode
ber) 50% duty cycle
,
Extinction Ratio
Center W avelength
Spectral W idth (
-20dB)
Side Mode Suppression Ratio
Optical Output Eye
1
Symbol
B
P
O
P
hi
/
l
P
o
c
Minimum
-
- 5.0
10
1480
-
30
Typical
156
- 3.0
-
1550
-
-
Maximum
-
0
-
1580
1
-
Units
Mb/s
dBm
dB
nm
nm
dB
!
2
0
S S
M R
Compliant w ith Telcordia G R-253-CORE and ITU -T Recommendation G .957
D ata rate ranges from 50Mb/s to 266Mb/s. H ow ever,some degradation may be incurred in overall performance.
R eceiver Perf
ormance C haracteristics
(Over Operating Case Temperature,
V
CC
= 3.13 to 3.47V)
All parameters guaranteed only at typical data rate
Parameter
Operating D ata Rate
1
2
Receiver Sensitivity (
-10
BER)
10
2
Maximum Input Optical Pow er (
-10
BER)
10
Symbol
B
P
min
P
ma
x
P
l
os+
P
l
os-
t_oss_ #
l o"
t_oss_
l on
-
-
Minimum
-
- 34.0
- 7.0
-
- 45.0
-
2.3
0.5
1100
-
Typical
156
- 36.0
0
-
-
-
-
1.5
-
-
Maximum
-
-
-
- 34.0
-
100
100
-
1600
- 25.0
Units
Mb/s
dBm
dBm
dBm
µs
dB
nm
dB
LOS Thresholds
LOS Timing D elay
LOS H ysteresis
W avelength of Operation
Receiver Re ectance (
LR-2 only)
1
2
Increasing Light Input
D ecreasing Light Input
Increasing Light Input
D ecreasing Light Input
D ata rate ranges from 50Mb/s to 266Mb/s. H ow ever,some degradation may be incurred in overall performance.
Specified in average optical input pow er and measured w ith 2
23
-1 PRBS at 156Mb/s,
1550nm for LR-2.
Laser Saf
ety
Laser Safety:
A l t
l ranscei
vers are C l I Laser product
ass
s
per FD A / D R H and IEC -
C
60825 st
andards.They m ust be
operat under speci ed operat ng condi i
ed
!
i
t ons.
Oplink Communications, Inc.
D ATE OF MA N U FACTU RE:
This product complies w ith
21 CFR 1040.10 and 1040.11
Meets Class I Laser Safety Requirements
Oplink Communications,
I
nc.
2
S0123,Rev.02
2011-03-30
TRPE 0 3E L2-E 1G Single Mode
Transmitter Electrical I
nterf
ace
(Over Operating Case Temperature,
V
CC
= 3.13 to 3.47V)
Parameter
1
Input Voltage Sw ing (TD + & TD -)
2
Input H IG H Voltage (TX D isable)
2
Input LOW Voltage (TX D isable)
3
Output H IG H Voltage (TX Fault)
3
Output LOW Voltage (TX Fault)
1
Symbol
V
PP-DIF
V
IH
V
IL
V
OH
V
OL
Minimum
0.35
2.0
0
2.0
0
Typical
-
-
-
-
-
Maximum
2.4
V
CC
0.8
V
CC#
0.3
+
0.8
Units
V
V
V
V
V
D i erential peak-to-peak voltage.
There is an internal 4.7 to 10k pull-up resistor to
VccT.
3
Open collector compatible,4.7 to 10k pull-up resistor to
Vcc
( ost Supply Voltage)
H
.
2
R eceiver Electrical I
nterf
ace
(Over Operating Case Temperature,
V
CC
= 3.13 to 3.47V)
Parameter
1
Output Voltage Sw ing ( + & RD -)
RD
2
Output H IG H Voltage (
LOS)
2
Output LOW Voltage (
LOS)
1
2
Symbol
V
PP-DIF
V
OH
V
OL
Minimum
0.6
2.0
0
Typical
-
-
-
Maximum
2.0
V
CC#
0.3
+
0.5
Units
V
V
V
D i erential peak-to-peak voltage across external 100 load.
Open collector compatible,4.7 to 10k pull-up resistor to
Vcc
( ost Supply Voltage)
H
.
Electrical Pow er Supply C haracteristics
(Over Operating Case Temperature,
V
CC
= 3.13 to 3.47V)
Parameter
Supply Voltage
Supply Current
Symbol
V
CC
I
CC
Minimum
3.13
-
Typical
3.3
190
Maximum
3.47
270
Units
V
mA
Module D ef
inition
MO D _D EF(0)
pin 6
TTL LOW
MO D _D EF(1)
pin 5
SCL
MO D _D EF(2)
pin 4
SD A
I
nterpretation by H ost
Serial module definition protocol
Electrical Pad Layout
20
19
18
17
16
15
14
13
12
11
TX G N D
TD - (TX D ATA IN -)
TD + (TX D ATA IN +)
TX G N D
VccTX
VccRX
RX G N D
RD + ( D ATA OU T+)
RX
RD - ( D ATA OU T-)
RX
RX G N D
H ost B oard C onnector Pad Layout
20
19
18
17
16
15
14
13
12
11
Tow ard
A SI
C
1
2
3
4
5
6
7
8
9
10
TX G N D
TX Fault
TX D isable
MOD _D EF(
2)
MOD _D EF(
1)
MOD _D EF(
0)
N O CON N ECTION
LOS
RX G N D
RX G N D
1
2
3
Tow ard
B ezel
4
5
6
7
8
9
10
Top of Board
Bottom of Board
(as viewed thru top of board)
Oplink Communications,
I
nc.
3
S0123,Rev.02
2011-03-30
TRPE 0 3E L2-E 1G Single Mode
Example of SFP host board schematic
1
m
H c l f rt bead
oior eri
e
( 2
W
s isr it nc
<0.
ere essa e)
Vc
c
3.
3V
Vc
c
3.
3V
+
10
0.
1
0.
1
16
R R R
2
8
4
5
6
50
W
l
i
ne
13
50
W
l
i
ne
12
R
R
TX Faul
t
LOS
MOD_DEF(
2)
MOD_DEF(
1)
MOD_DEF(
0)
RX DATA OUT+
to 50
W
load
RX DATA OUT-
to 50
W
load
+
15
10
0.
1
SFP
TX Diabl
s e
50
W
l
i
ne
TX DATA IN+
50
W
l
i
ne
TX DATA IN-
19
18
3
1,9, 11, 17,
10, 14, 20
R:4.7 to 10k
CA P Values in
µF
A pplication N otes
Electrical Interface:
A ll signal interfaces are compliant w ith
the SFP MSA specification. The high speed D ATA interface is
differential AC-coupled internally w ith 1 F and can be directly
connected to a 3.3V SERD ES IC. A ll low speed control and sense
output signals are open collector TTL compatible and should
be pulled up w ith a 4.7 - 10k resistor on the host board.
Loss of Signal (LOS):
The Loss of Signal circuit monitors the
level of the incoming optical signal and generates a logic H IG H
w hen an insufficient photocurrent is produced.
TX Fault:
The output indicates LOW w hen the transmitter
is operating normally,and H IG H w ith a laser fault including
laser end-of-life. TX Fault is an open collector/drain output
and should be pulled up w ith a 4.7 - 10k resistor on the host
board. TX Fault is non-latching (
automatically deasserts w hen
fault goes aw ay)
.
TX Disable:
W hen the TX D isable pin is at logic H IG H , the
transmitter optical output is disabled (
less than -45dBm)
.
Serial Identification and Monitoring:
The module definition
of SFP is indicated by the three module definition pins,
MOD _D EF( ,MOD _D EF( and MOD _D EF( . U pon pow er up,
0)
1)
2)
MOD _D EF( 2)appear as N C ( connection) and MOD _D EF(
1:
no
,
0)
is TTL LOW . W hen the host system detects this condition,
it activates the serial protocol (
standard tw o-w ire I
2
C serial
interface) and generates the serial clock signal (
SCL) The
.
positive edge clocks data into the EEPROM segments of the
SFP that are not w rite protected,and the negative edge clocks
data from the SFP.
The serial data signal ( A ) is for serial data transfer. The
SD
host uses SD A in conj
unction w ith SCL to mark the start and
end of serial protocol activation. The supported monitoring
functions are temperature,voltage,bias current,transmitter
pow er,average receiver signal,all alarms and w arnings,and
softw are monitoring of TX Fault/LOS. The device is internally
calibrated.
The data transfer protocol and the details of the mandatory
and vendor specific data structures are defined in the SFP MSA ,
and SFF-8472,Rev. 9.4.
Pow er Supply and G rounding:
The pow er supply line should
be w ell-filtered. A ll 0.1 F pow er supply bypass capacitors
should be as close to the transceiver module as possible.
Oplink Communications,
I
nc.
4
S0123 ,
Rev.02
2011-03-30
TRPE 0 3E L2-E 1G Single Mode
Package O utline
41.80
[1.646]
13.62
[.536]
14.94
[.588]
45.00
[1.772]
6.25
[.246]
1.99
[.078]
[.257]
6.54
0.60
[.024]
435 and P y rmont, 958 e (1) 3-20 ax(1) 3-30 mail:ale
63 L ing kw Fe
CA 43 Tl: 0 9370 F : 0 9370 E S s@Oplink. • w .
5
5
com w woplink.
com
[.470]
11.94
[.362]
9.20
10.45
2.29
[.090]
13.80
[.543]
1.49
[.059]
2.50
[.098]
0.60
[.024]
0.45
[.018]
[.411]
D imensions in inches [
mm]
D efault tolerances:
.xxx = ± .005” .xx = ± .01”
,
O rdering I ormation
nf
Part N umber
O perating Tem-
perature
Latch
C olor
W hite
N ominal
W avelength
1550nm
SO N ET/ H
SD
Standards
LR-2/L-1.2
D istance
1
100/80km
TRPE03EL2C000E1G
TRPE03EL2I000E1G
1
- 5°C to +70°C
- 40°C to +85°C
These are target distances to be used for classi cation and not for speci cation,per Telcordia G R-253-CORE/ITU -T Recommendation G .957.
Oplink Communications,Inc. reserves the right to make changes in equipment design or speci cations w ithout notice. Information supplied by Oplink Commu-
nications,Inc. is believed to be accurate and reliable. H ow ever,no responsibility is assumed by Oplink Communications,Inc. for its use nor for any infringements
of third parties,w hich may result from its use. N o license is granted by implication or otherw ise under any patent right of Oplink Communications,Inc.
[b][font=宋体]Chapter 41[/font] [font=宋体]Camera Experiment[/font][/b] [align=left]The ALIENTEK Battleship STM32 development board has a camera interface (P8) onboard, which can be used to connect the AL...
I use STM32 to read external RTC (8025), IIC communication, the host sends 0x64, and then starts to read. Through the oscilloscope, the data I send is correct, 0x64 + read flag = the data sent should ...
When using stm32F407 + lwip-1.3.1 communication without an operating system, suddenly the return value of udp sending data is always = ERR_IF; This ERR_IF is explained by an error in the underlying ne...
[font="][size=11.0pt]Almost every embedded device has a debugging serial port. In some scenarios, it is inconvenient to connect to the PC with a physical cable, and a wireless connection is required. ...
I am planning now,,, basically considering Beijing, Chengdu, Chongqing, Hunan,,, I am a Shanghai native,,,,,,,,, I have a house in Shanghai,,,,,,,,,...
We have a WinCE platform with Hive registry. Customers use the installation package to install software on the platform. During the installation process, the registry will be written, the relevant fil...
stm32/stm8
京公网安备 11010802033920号
EEWORLD
