ALUMINUM ELECTROLYTIC CAPACITORS
CB
Chip Type, Long Life Assurance
series
Chip type with load life of 7000 hours at +105
°C
.
Applicable to automatic mounting machine fed with carrier tape.
Compliant to the RoHS directive (2011/65/EU).
CB
Low
Impedance
Long Life
UL
CW
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Tangent of loss angle (tan
δ)
Performance Characteristics
– 25 to +105°C
6.3 to 50V
0.1 to 1000µF
± 20% at 120Hz, 20°C
After 2 minutes' application of rated voltage, leakage current is not more than 0.03 CV or 4 (µA) , whichever is greater.
Measurement frequency : 120Hz at 20°C
Rated voltage (V)
tan
δ
(MAX.)
6.3
0.32
10
0.28
6.3
4
16
0.26
10
3
25
0.16
16
2
25
2
35
0.14
35
2
50
0.14
50
2
Measurement frequency : 120Hz
Rated voltage (V)
Stability at Low Temperature
Impedance ratio
ZT / Z20 (MAX.)
Z– 25°C / Z+20°C
Endurance
The specifications listed at right shall be met
when the capacitors are restored to 20°C
after the rated voltage is applied for 7000
hours at 105°C.
Capacitance change
tan
δ
Leakage current
Within ±30% of the initial capacitance value
300% or less than the initial specified value
Less than or equal to the initial specified value
Shelf Life
Resistance to soldering
heat
Marking
After storing the capacitors under no load at 105°C for 1000 hours and then performing voltage treatment based on JIS C 5101-4
clause 4.1 at 20°C, they shall meet the specified values for the endurance characteristics listed above.
The capacitors are kept on a hot plate for 30 seconds, which is
Capacitance change
Within ±10% of the initial capacitance value
maintained at 250°C. The capacitors shall meet the characteristic
Less than or equal to the initial specified value
tan
δ
requirements listed at right when they are removed from the plate
Less than or equal to the initial specified value
Leakage current
and restored to 20°C.
Black print on the case top.
Chip Type
(φ4 to
φ6.3)
0.5MAX.
Voltage ( C : 16V )
Series
Plastic platform
0.3MAX.
φD±0.5
C
±0.2
Positive
Type numbering system (Example : 16V 100
µ
F)
1
2
3
4
5
6
7
8
9 10 11 12 13 14
UCB 1 C 1 0 1 MC L 1 GS
Taping code
A± 0.2 A
±0.2
A2
100C
CB
B± 0.2
Configuration
Capacitance tolerance (±20%)
Rated capacitance (100µF)
Rated voltage (16V)
Series name
Type
φD
4 to 6.3
8
•
10
E
L
±0.3
Lot No.
Capacitance
H
Negative
Code
CL
NL
(φ8 to
φ10
)
Voltage ( V : 35V )
Trade mark
Plastic platform
Series
φD±0.5
0.3MAX.
C±0.2
0.5MAX.
Positive
φD
(mm)
×
L
4
×
7
1.8
4.3
4.3
1.0
7.0
0.5 to 0.8
5
×
7
2.1
5.3
5.3
1.3
7.0
0.5 to 0.8
6.3
×
7
2.4
6.6
6.6
2.2
7.0
0.5 to 0.8
6.3
×
8.7
2.4
6.6
6.6
2.2
8.7
0.5 to 0.8
8
×
10
2.9
8.3
8.3
3.1
10
0.8 to 1.1
10
×
10
3.2
10.3
10.3
4.5
10
0.8 to 1.1
A±0.2 A±0.2
A
B
C
E
L
H
A2
220V
CB
B±0.2
L±0.5
Lot No.
Capacitance
Pressure relief vent
H
Voltage
V
6.3
Code
j
10
A
16
C
25
E
35
V
50
H
Dimension table in next page.
E
Negative
CAT.8100C
ALUMINUM ELECTROLYTIC CAPACITORS
CB
Cap.(µF)
series
Dimensions
V
Code
6.3
0J
10
1A
16
1C
25
1E
4
×
7
4
×
7
4
×
7
4
×
7
4
×
7
4
×
7
4
×
7
4
×
7
35
1V
1.0
2.6
3.2
3.8
6.2
11
14
15
25
42
57
8
×
10
8
×
10
10
×
10
10
×
10
50
1H
0.1
0.22
0.33
0.47
1
2.2
3.3
4.7
10
22
33
47
100
220
330
470
1000
0R1
R22
R33
R47
010
2R2
3R3
4R7
100
220
330
470
101
221
331
471
102
10
×
10
5
×
7
6.3
×
7
6.3
×
8.7
8
×
10
4
×
7
4
×
7
18
30
6.3
×
7
5
×
7
6.3
×
7
22
5
×
7
5
×
7
35
6.3
×
7
6.3
×
8.7
48
63
116
6.3
×
8.7
77
92
151
36
60
101
160
8
×
10
50
81
6.3
×
8.7
8
×
10
141
10
×
10
216
254
313
Case size
Rated
φ
D
×
L (mm)
ripple
Rated ripple current (mArms) at 105°C 120Hz
Frequency coefficient of rated ripple current
Frequency
Coefficient
50 Hz
0.70
120 Hz
1.00
300 Hz
1.17
1 kHz
1.36
10 kHz or more
1.50
Taping specifications are given in page 23.
Recommended land size, soldering by reflow are given
in page 18, 19.
Please refer to page 3 for the minimum order quantity.
CAT.8100C
