1480/1550
(1585)
nm WDM/ T Couper/
ap
Isolator Hybrid Combination
WTIH1514 Series
Product Description
Oplink’s WTIH is a combination of a wavelength division multiplexer, tap cou-
pler and an isolator in a compact package. This product has an extremely low
insertion loss, and a very stable tap-coupling ratio. Fiber optic amplification is
the ideal application for this product.
Oplink can provide customized designs to meet specialized feature applica-
tions. Also, Oplink offers modular assemblies that integrate other compo-
nents to form a full function module or subsystem.
Performance Specificationns
WTIH1514 Series
Single Stage
Dual Stage
Unit
Operating Wavelength Range
Signal Channel
Pump Channel
Signal Port
Pump Port
1% Tap Ratio
Tap
Port
2% Tap Ratio
5% Tap Ratio
10% Tap Ratio
C band : 1528 ~ 1564
L band : 1570 ~ 1605
1450 ~ 1495
< 1.1
< 0.6
19.2 ~ 21.0
16.2 ~ 18.0
12.2 ~ 14.0
9.6 ~ 10.8
< 0.4
> 25
< 0.5
< 1.2
nm
nm
dB
Insertion Loss
Features
dB
[1]
Wide Operating Wavelength Range
Compact Size
High Isolation
Ultra Low PDL & PMD
High Stability & Reliability
Epoxy-free Optical Path
Wavelength Dependent Loss
Wavelength Isolation
Signal to Common
dB
dB
Signal to Common @ Pump
Wavelength Range
Pump to Common @ Signal
Wavelength Range
Common to Signal
> 15
> 21
< 0.1
< 0.25
≥ 55
≥ 50
≤ 500
0 to +70
-40 to +85
> 36
< 0.2
< 0.05
dB
dB
ps
dB
dB
mW
°C
°C
(over signal wavelength range,
0~70°C, all SOP)
Reverse Direction Isolation
Polarization Dependent Loss
Polarization Mode Dispersion (standard)
Directivity
Return Loss
Maximun Power Handling
Operating Temperature
Storage Temperature
Fiber Type
Package Dimension
[3]
Signal & Tap Ports
Common & Pump Ports
Applications
Fiberoptic Amplifiers
CATV Fiberoptic Links
WDM Systems
Fiberoptic Instruments
Transmitters and Fiber Lasers
Laboratory R&D
Corning SMF-28
Corning HI1060 FLEX
P2 : (Ø) 5.5 x (L) 40.0
mm
Values are referenced without connector loss
[1]
The maximum IL is under all states of polarization and within the full operating temperature and wavelength
ranges specified. Add 0.3dB on signal port IL for 10% tapping case.
[2]
All the parameters are excluding connectors.
[3]
The mechanical tolerance should be +/-0.2mm on all package dimensions unless otherwise custom specified.
S0080 - R01. 20100707
1480/1550(1585)nm WDM/TAP Coupler/
Isolator Hybrid Combination
WTIH1514 Series
Mechanical Drawing / Package Dimensions (dimension in mm)
40.0mm
SIGNAL
COMMON
COMMON
SIGNAL
Ø5.5mm
TAP
PUMP
TAP
PUMP
46335 Landing Pkwy Fremont, CA 94538 Tel: (510) 933-7200 Fax: (510) 933-7300 Email: Sales@Oplink.com • www.oplink.com
Ordering Information
Oplink can provide a remarkable range of customized optical solutions. For detail, please contact Oplink’s OEM
design team or account manager for your requirements and ordering information (510) 933-7200.
WTIH
1
1
4
2
Wavelength
1550/1480nm = 1514
1585/1480nm = 1614
Tap Ratio
1% = 01
2% = 02
5% = 05
10% = 10
Fiber Length
0.5 meter = H
1.0 Meter = 1*
1.5 Meters = 5
2.0 Meters = 2
Connector Type
None = 1
FC/PC = 2
FC/SPC = 3
FC/APC = 4
SC/PC = 5
SC/SPC = 6
SC/APC = 7
ST = 8
LC = 9
MU = A
Stage
Single Stage = S
Dual Stage = D
Package & Fiber Jacket Type
* The tolerance of fiber length is +/-0.1m. 1 meter is standard.
The lead-time for special fiber length will be longer.
P2 + 250μm bare fiber = 21
P2 + 900µm loose tube = 22
S0080 - R01. 20100707
Product Lines:
Mux/Demux
Switching/Routing
Coupling/Splitting
Monitoring/Conditioning
Amplification
Transmission
Interconnect
RGB Laser Modules
