Pendant Stations
XAC Standard Duty Pistol Grips, Enclosures, Contact Blocks
Refer to Catalog
9001CT1001
Table 19.359: Contact Blocks for Operators in Cover
Description
1 N.O./spring return/1 speed
1 N.C./spring return/1 speed
1 N.O. early close & 1 N.C. & 1 N.O./spring return/2 speed
1 N.C. & 2 N.O./spring return/1 speed
1 N.O. & 1 N.O. latching/1 speed/interlocked
1 N.O. & 1 N.C. latching/1 speed/interlocked
3 N.C.—all
direct acting
Wiring Diagram
—
—
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Catalog Number
ZB2BE101
ZB2BE102
XENG1191
XENG1491
XENG3781
XENG3791
XENT1192
$ Price
16.40
49.00
ZB2BE10
XENG37
Table 19.360: Contact Blocks for Operators in Base of Enclosure
a
1 N.O./1 speed
1 N.C./1 speed
2 N.O./1 speed
2 N.C./1 speed
1 N.O. & 1 N.C./1 speed
a
Cannot be used with
XACA03
pendant.
XACS101
XACS102
XACS103
XACS104
XACS105
28.60
38.20
XENG1191
XACS10
Wiring Diagrams
13
21
33
14
22
34
13
21
14
22
13 14 13 14
33
34
13 14
11 12
12
22
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Table 19.361: Operators
b
Description
Color
White
Black
Green
Red
Yellow
Blue
Brown
Catalog Number
XACA9411
XACA9412
XACA9413
XACA9414
XACA9415
XACA9416
XACA9419
$ Price
Booted push button
8.20
Booted Push Button
Table 19.362: Mushroom Operators
Description
Mushroom head, momentary
Mushroom head, push to maintain/turn-to-release
Mushroom head, push to maintain/turn-to-release
(trigger action)c
Mushroom Size
30 mm
30 mm
40 mm
30 mm
40 mm
30 mm
40 mm
40 mm
Color
Red
Red
Red
Red
Red
Red
Red
Red
Catalog Number
ZA2BC44
ZA2BS44
ZA2BS54
ZA2BS834
ZA2BS844
ZA2BS74
ZA2BS14
ZA2BS944
$ Price
36.80
79.00
32
N/C + N/C + N/C
with positive
opening operation
11
21
31
Mushroom Head
Mushroom head, push to maintain/key turn-to-release
Mushroom head, push to maintain/key turn-to-release
(trigger action)c
112.00
Table 19.363: Selector Switches and Wobble Stick
Description
Selector switch/2 position—maintainedd
Selector switch/3 position—maintainedd
Selector switch/2 position—maintained key operated—key removal from LT or RT positiond
Selector switch/3 position—maintained key operated—key removal from LT or RT positiond
Wobble stick (bottom mounting recommended)
Color
Black
Black
NA
NA
Black
Red
Catalog Number
ZA2BD2
ZA2BD3
ZA2BG4
ZA2BG5
ZA2BB2
ZA2BB4
$ Price
30.00
112.00
102.00
Selector Switch
Description
Direct supply base/without lamp (for 6 to 120 V applications) (AC/DC)
e
Color
—
Catalog Number
ZB2BV006
$ Price
24.60
Selector Switch
(key operated)
b
c
d
e
Booted push buttons are for cover mounting only. All other operators can be mounted on cover or bottom.
Trigger action mushroom heads are tamper proof in that a change of contact state is not possible by teasing or floating the operator.
Not for use with XEN G contact blocks.
For lamps, see page 19-120.
Wobble Stick
© 2012 Schneider Electric
All Rights Reserved
CS2
Discount
Schedule
19-119
19
