Confidential
ZXHF5002
4:2 IF switch with integrated gain and control
Summary
The ZXHF5000 provides an integrated IF
solution for multiple output LNB and switch
box applications. The ZXHF5000 includes a 4
by 2 switch with 19dB of positive gain which
can be connected directly to the output of the
LNB or switch box eliminating the need for
cable drive amplifiers.
The ZXHF5000 includes all the control required
for voltage and tone based systems providing a
reliable and highly integrated solution.
Features
•
•
•
•
•
•
•
•
•
•
•
•
•
High linearity 4:2 switch
Integrated cable drive amplifiers
Integrated switch control - Tone and Voltage
Wide bandwidth 200 to 2700MHz
Gain 19dB, rising across band
High isolation Typ. >30dB, 200 to 2150MHz
OIP3 >15dBm, 200 to 2150MHz
Reliable tone detector with unwanted
signal rejection filter
Accurate voltage detector 14.0V to 15.5V
Intelligent low power mode
3.3V operation
Unconditionally stable
Pin-out programmable for double-sided
assembly
Applications
•
•
•
Twin universal LNB's
Quad universal LNB's
Multiple output LNB's
Figure 1 Typical low power twin universal LNB system
RF Gain Stages
GaAs HEMT FET
Mixer
IF Gain Stages and
Power Management
Set-top-box
Receiver 1
ZABG
Series
ZXHF
5002
Set-top-box
Receiver 2
78L
06
Vcc
78L
06
Issue 1 - June 2008
© Zetex Semiconductors plc 2008
1
www.zetex.com
Zetex reserves the right to alter, without notice, the specifications, design or conditions of this product.
