245047020900861

Description
Board Stacking Connector, 20 Contact(s), 2 Row(s), Female, Straight, Surface Mount Terminal, Receptacle,
CategoryThe connector    The connector
File Size274KB，6 Pages
ManufacturerAVX
Download Datasheet Parametric View All

245047020900861 Overview

Board Stacking Connector, 20 Contact(s), 2 Row(s), Female, Straight, Surface Mount Terminal, Receptacle,

245047020900861 Parametric

Parameter NameAttribute value
Objectid1671163793
Reach Compliance Codecompliant
ECCN codeEAR99
Body/casing typeRECEPTACLE
Connector typeBOARD STACKING CONNECTOR
Contact to complete cooperationGOLD (8)
Contact completed and terminatedGOLD (8)
Contact point genderFEMALE
DIN complianceNO
Filter functionNO
IEC complianceNO
JESD-609 codee4
MIL complianceNO
Manufacturer's serial number5047
Plug informationMULTIPLE MATING PARTS AVAILABLE
Mixed contactsNO
Installation methodSTRAIGHT
Installation typeBOARD
Number of rows loaded2
OptionsGENERAL PURPOSE
Terminal pitch0.5 mm
Termination typeSURFACE MOUNT
Total number of contacts20

Preview

Download Datasheet
Fine Pitch SMT
Board to Board Connectors
Series 5047
Series 5047 is the board to board, fine pitch connector which
meets the requirement for high density circuitry in the market
and designed especially for portable equipment. Mated
height between boards can be 5.0mm or 7.0mm.
FEATURES
Designed to have the strong resistance against torque forces
on mating area to achieve the high reliability in the natural fall
shock environment.
Adoption of bellows type contact with excellent contact reli-
ability.
High durability to achieve 50 times of mating and unmating
cycles.
Parts are supplied in tape and reel with 800 pieces per reel.
SPECIFICATIONS
Series
Mated Height
Pitch
Current
Voltage
D.W. Voltage
Mating Cycles
5047
5.0, 7.0mm
0.5mm
0.4A Max
50V Max
500V rms/min
50
No. of Dimension
Pos.
A
020
030
040
050
060
070
080
90
100
7.5
(0.295)
10.0
(0.394)
12.5
(0.492)
15.0
(0.591)
17.5
(0.689)
20.0
(0.787)
22.5
(0.886)
25.0
(0.984)
27.5
(1.083)
Series
5047
Variation
Plug
Mated
Height
5.0mm
Gold
Plating
0.1µm
0.2µm
Strain
Relief
1
1
1
1
1
1
Vacuum
Cover
O
1
O
1
O
1
O
1
1
1
14
14
14
14
14
14
14
14
24
24
Part Number
5047
5047
5047
5047
5047
5047
5047
5047
5047
5047
XXX
XXX
XXX
XXX
XXX
XXX
XXX
XXX
XXX
XXX
9
4
9
4
9
4
9
4
4
4
50
50
50
50
70
70
70
70
00
00
856
856
861
861
856
856
861
861
856
861
020
O
O
O
O
O
O
O
O
O
O
030
O
O
O
O
O
O
O
O
O
O
Number of Positions
040
O
O
O
O
O
O
O
O
O
O
050
O
O
O
O
O
O
O
O
O
O
060
O
O
O
O
O
O
O
O
O
O
070
O
O
O
O
O
O
O
O
O
O
080
O
O
O
O
O
O
O
O
O
O
090
O
O
O
O
O
O
O
O
O
O
100
O
O
O
O
O
O
O
O
O
O
7.0mm
0.1µm
0.2µm
Receptacle
0.1µm
0.2µm
O = Available
1 = Not available
