ZXT3M322

Description
3000 mA, 40 V, PNP, Si, SMALL SIGNAL TRANSISTOR
Categorysemiconductor    Discrete semiconductor
File Size177KB,7 Pages
ManufacturerDiodes
Websitehttp://www.diodes.com/
Download Datasheet Parametric Compare View All

ZXT3M322 Overview

3000 mA, 40 V, PNP, Si, SMALL SIGNAL TRANSISTOR

ZXT3M322 Parametric

Parameter NameAttribute value
Number of terminals3
Transistor polarityPNP
Maximum collector current3 A
Maximum Collector-Emitter Voltage40 V
Processing package description2 X 2 MM, MLP322, 5 PIN
Lead-freeYes
EU RoHS regulationsYes
China RoHS regulationsYes
stateDISCONTINUED
packaging shapeSQUARE
Package SizeSMALL OUTLINE
surface mountYes
Terminal formFLAT
terminal coatingMATTE TIN
Terminal locationDUAL
Packaging MaterialsPLASTIC/EPOXY
structureSINGLE
Shell connectionCOLLECTOR
Number of components1
transistor applicationsSWITCHING
Transistor component materialsSILICON
Transistor typeGENERAL PURPOSE SMALL SIGNAL
Minimum DC amplification factor12
Rated crossover frequency190 MHz
ZXT3M322
MPPS™ Miniature Package Power Solutions
40V PNP LOW SATURATION SWITCHING TRANSISTOR
SUMMARY
V
CEO
= -40V; R
SAT
= 104m ; I
C
= -3A
DESCRIPTION
Packaged in the innovative 2mm x 2mm MLP (Micro Leaded Package) outline,
this new 4
th
generation low saturation transistor offers extremely low on state
losses making it ideal for use in DC-DC circuits and various driving and power
management functions.
Additionally users will also gain several other
key benefits:
Performance capability equivalent to much larger packages
Improved circuit efficiency & power levels
PCB area and device placement savings
Lower package height (nom 0.9mm)
2mm x 2mm MLP
(single die)
FEATURES
Low Equivalent On Resistance
Extremely Low Saturation Voltage
(-220mV@ -1A)
hFE specified up to -3A
IC= -3A Continuous Collector Current
2mm x 2mm MLP
APPLICATIONS
DC - DC Converters (FET Driving)
Charging Circuits
Power switches
Motor control
PINOUT
ORDERING INFORMATION
DEVICE
ZXT3M322TA
ZXT3M322TC
REEL
7
13
TAPE
WIDTH
8mm
8mm
QUANTITY
PER REEL
3000
10000
2mm x 2mm Single MLP
underside view
DEVICE MARKING
S3
ISSUE 2 - JUNE 2002
1
