1SS302T5LFH

Description
Ultra High Speed Switching Applications
File Size200KB,4 Pages
ManufacturerToshiba Semiconductor
Websitehttp://toshiba-semicon-storage.com/
Download Datasheet View All

1SS302T5LFH Overview

Ultra High Speed Switching Applications

1SS302
TOSHIBA Diode
Silicon Epitaxial Planar Type
1SS302
Ultra High Speed Switching Applications
Small package
Low forward voltage
Small total capacitance
: SC-70
: V
F (3)
= 0.90V (typ.)
: C
T
= 0.9pF (typ.)
Unit: mm
Fast reverse recovery time : t
rr
= 1.6ns (typ.)
Absolute Maximum Ratings
(Ta = 25
°C
)
Characteristic
Maximum (peak) reverse voltage
Reverse voltage
Maximum (peak) forward current
Average forward current
Surge current (10ms)
Power dissipation
Junction temperature
Storage temperature
Symbol
V
RM
V
R
I
FM
I
O
I
FSM
P
T
j
T
stg
Rating
85
80
300 (*)
100 (*)
2 (*)
100
125
−55~125
Unit
V
V
mA
mA
A
mW
°C
°C
JEDEC
JEITA
TOSHIBA
Weight: 0.006g (typ.)
SC-70
1-2P1C
Note: Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the
significant change in temperature, etc.) may cause this product to decrease in the reliability significantly even
if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum
ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
*:
Unit rating. Total rating = unit rating × 0.7
Electrical Characteristics
(Ta = 25
°C
)
Characteristic
Symbol
V
F (1)
Forward voltage
V
F (2)
V
F (3)
Reverse current
Total capacitance
Reverse recovery time
I
R (1)
I
R (2)
C
T
t
rr
Test
Circuit
Test Condition
I
F
= 1mA
I
F
= 10mA
I
F
= 100mA
V
R
= 30V
V
R
= 80V
V
R
= 0, f = 1MHz
I
F
= 10mA, Fig.1
Min
Typ.
0.60
0.72
0.90
0.9
1.6
Max
1.20
0.1
0.5
3.0
4.0
μA
pF
ns
V
Unit
1
2007-11-01
