DATASHEET
K2 SERIES ULTRACAPACITORS
PRODUCT SPECIFICATIONS (Cont’d)
POWER & ENERGY
Usable Specific Power, P
d4
Impedance Match Specific Power, P
max5
Specific Energy, E
max6
Stored Energy, E
stored7,11
BCAP0650
6,800 W/kg
14,000 W/kg
4.1 Wh/kg
0.66 Wh
BCAP1200
5,800 W/kg
12,000 W/kg
4.7 Wh/kg
1.22 Wh
BCAP1500
6,600 W/kg
14,000 W/kg
5.4 Wh/kg
1.52 Wh
BCAP2000
6,900 W/kg
14,000 W/kg
5.6 Wh/kg
2.03 Wh
BCAP3000
5,900 W/kg
12,000 W/kg
6.0 Wh/kg
3.04 Wh
SAFETY
Short Circuit Current, typical
(Current possible with short circuit from rated
voltage. Do not use as an operating current.)
3,400 A
UL810a, RoHS
4,700 A
UL810a, RoHS
5,700 A
UL810a, RoHS
7,700 A
UL810a, RoHS
9,300 A
UL810a, RoHS
Certifications
TYPICAL CHARACTERISTICS
THERMAL
CHARACTERISTICS
Thermal Resistance (R
ca
, Case to
Ambient), typical
8
Thermal Capacitance (C
th
), typical
8
Maximum Continuous Current
(ΔT = 15
o
C)
8
Maximum Continuous Current
(ΔT = 40
o
C)
8
6.5
o
C/W
190 J/
o
C
54 A
RMS
88 A
RMS
5.3
o
C/W
300 J/
o
C
70 A
RMS
110 A
RMS
4.5
o
C/W
320 J/
o
C
84 A
RMS
140 A
RMS
3.8
o
C/W
410 J/
o
C
110 A
RMS
170 A
RMS
3.2
o
C/W
600 J/
o
C
130 A
RMS
210 A
RMS
LIFE
DC Life at High Temperature
1
Capacitance Change
ESR Change
(held continuously at Rated Voltage and Maximum
Operating Temperature)
(% decrease from minimum initial value)
(% increase from maximum initial value)
1,500 hours
20%
100%
10 years
20%
100%
1,000,000 cycles
20%
1,500 hours
20%
100%
10 years
20%
100%
1,000,000 cycles
20%
1,500 hours
20%
100%
10 years
20%
100%
1,000,000 cycles
20%
1,500 hours
20%
100%
10 years
20%
100%
1,000,000 cycles
20%
1,500 hours
20%
100%
10 years
20%
100%
1,000,000 cycles
20%
Projected DC Life at 25
o
C
1
(held continuously at Rated Voltage)
Capacitance Change
ESR Change
(% decrease from minimum initial value)
(% increase from maximum initial value)
Projected Cycle Life at 25
o
C
1, 9, 10
Capacitance Change
(% decrease from minimum initial value)
Page 2
Document number: 1015370.4
maxwell.com
DATASHEET
K2 SERIES ULTRACAPACITORS
LIFE (Cont'd)
ESR Change
(% increase from maximum initial value)
100%
65 A
4 years
100%
75 A
4 years
100%
100 A
4 years
100%
100 A
4 years
100%
100 A
4 years
Test Current
Shelf Life
(Stored uncharged at 25
o
C)
ESR AND CAPACITANCE VS TEMPERATURE
180%
170%
160%
150%
140%
130%
120%
110%
100%
90%
80%
-60
-40
-20
0
20
40
60
80
Temperature (°C)
Capacitance
DC ESR
NOTES
1. Capacitance and ESR
DC
measured at 25°C using
specified test current per waveform below.
2. Absolute maximum voltage, non-repeated. Not to
exceed 1 second.
3. After 72 hours at rated voltage. Initial leakage current
can be higher.
0.12V
2
4. Per IEC 62391-2, P
d
= ESR x mass
DC
5. P
max
=
6. E
max
=
V
2
4 x ESR
DC
x mass
½ CV
2
3,600 x mass
8. ∆T=I
RMS2
x ESR x R
ca
9. Cycle using specified test current per waveform
below.
10. Cycle life varies depending upon application-specific
characteristics. Actual results will vary.
11. Per United Nations material classification UN3499, all
Maxwell ultracapacitors have less than 10 Wh capacity
to meet the requirements of Special Provisions 361.
When packaged according to the regulation, both
individual ultracapacitors and modules composed
of those ultracapacitors shipped by Maxwell can be
transported without being treated as dangerous
goods (hazardous materials).
7. E
stored
= ½ CV
2
3,600
Percentage change from value at 25°C
Page 3
Document number: 1015370.4
maxwell.com
DATASHEET
K2 SERIES ULTRACAPACITORS
MOUNTING RECOMMENDATIONS
Do not reverse polarity. Please refer to document
Products are marked with the following information:
number 1016419, available at maxwell.com for welding Rated capacitance, rated voltage, product number,
4
3
2
1
name of manufacturer, positive terminal, warning
recommendations.
marking, serial number.
REVISIONS
REV
1
DESCRIPTION
CO
PROTOTYPE
MARKINGS
BCAPxxxx P270 K04
2.8 MAX
UNTHREADED
LENGTH
2.8 MAX
UNTHREADED
LENGTH
D
M12 X 1.75 - 6g
D2
53 MAX
M12 X 1.75 - 6g
D1
C
14
14
4
3
L
2
REVISIONS
REV
1
DESCRIPTION
1
CO
-
BCAPxxxx P270 K05
D
R 0.6 MAX
0.5 MAX EDGE BREAK
PRODUCTION RELEASE
R 0.6 MAX
0.5 MAX EDGE BREAK
D
B
60.7 0.7
D2
60.4 0.2
D1
14.00 0.05
53 MAX
DO NOT SCALE DRAWING
UNLESS OTHERWISE SPECIFIED, ALL DIMENSIONS
ARE IN MILLIMETERS AFTER PLATING.
BREAK EDGES 0.3
LATHE FINISH 63 µINCH, MILL FINISH 125 µINCH
X.XXX DIAMETERS
0.125 TIR X.XXX DIA
SURFACES
&
DRAWN
14.00 0.05
C
C
THE INFORMATION CONTAINED IN THIS
DOCUMENT IS MAXWELL CONFIDENTIAL
INFORMATION AND IS THE SOLE PROPERTY
OF MAXWELL TECHNOLOGIES. ANY
REPRODUCTION IN PART OR WHOLE
WITHOUT WRITTEN PERMISSION OF
MAXWELL TECHNOLOGIES IS PROHIBITED.
NOTICE:
APPROVALS
DATE
R.DUBINSKAYA
PER IFS
3/2/2011
3.180 0.125
3.180 0.125
0.025mm
CHECKED
DESIGN ENGR
MECHANICAL ENGR
PROCESS ENGR
TEST ENGR
A
L
0.3
X/X
.X
.XX
MATERIAL
±.5
±.25
±.125
ANGLE ±0.5°
9244 BALBOA AVENUE, SAN DIEGO, CA 92123 U.S.A
DESCRIPTION
3000-T
B
PART NO.
REV
A
N/A
B
MODEL
BCAP0650
BCAP1200
BCAP1500
BCAP2000
BCAP3000
P/N WITH HEAT SHRINK TUBING
108700, 108700B
108702, 108702B
108704, 108704B
108706, 108706B
108708, 108708B
3RD ANGLE PROJECTION
4
A
3
P/N WITH LABELS
108294, 108294B
CAUTION
ASSEMBLIES
108316,
CONTAINS PARTS AND/ORBY
108316B
SUSCEPTIBLE TO DAMAGE
108324,
ELECTROSTATIC DISCHARGE (ESD)
108324B
108325, 108325B
108058, 108058B
THE INFORMATION CONTAINED IN THIS
DOCUMENT IS MAXWELL CONFIDENTIAL
INFORMATION AND IS THE SOLE PROPERTY
OF MAXWELL TECHNOLOGIES. ANY
REPRODUCTION IN PART OR WHOLE
WITHOUT WRITTEN PERMISSION OF
MAXWELL TECHNOLOGIES IS PROHIBITED.
A
FINISH
51.5
74
85
102
138
DO NOT SCALE DRAWING
UNLESS OTHERWISE SPECIFIED
ALL DIMENSIONS ARE IN MILIMETERS AFTER
PLATING.
BREAK SHARP EDGES
USE MINIMUM BEND RADII
DRAWN
QUALITY ENGR
PRODUCTION ENGR
PER IFS
SCALE
B 68911
2:1
SIZE
CAGE CODE
DOC. NO.
REV
5
SHEET
1 OF 1
NOTICE:
2
APPROVALS
DATE
1
9244 BALBOA AVENUE, SAN DIEGO, CA 92123 U.S.A
DESCRIPTION
Author
1
9/13/2010
CHECKED
DESIGN ENGR
MECHANICAL ENGR
PROCESS ENGR
TEST ENGR
QUALITY ENGR
PRODUCTION ENGR
Page 4
Document number: 1015370.4
1
REFERENCE IFS FOR APPROVAL AND APPROVAL
DATES
maxwell.com
3RD ANGLE PROJECTION
CAUTION
CONTAINS PARTS AND/OR ASSEMBLIES
SUSCEPTIBLE TO DAMAGE BY
ELECTROSTATIC DISCHARGE (ESD)
MATERIAL
BCAP, ENVELOPE ASSY, K2, J
Material
FINISH
ANODIZE, TYPE II
CLASS 2, PANTONE
286 BLUE
1
SCALE
B 68911
1:1
SIZE
CAGE CODE
PART NO.
SEE TABLE
REV
REV
N/A
1 OF 1
DOC. NO.
1014428
1
SHEET
4
3
2
1
C:\Rina\ALISON\
.X
±.5
.XX
±.25
.XXX ±.125
ANGLE ±0.5°
A
DATASHEET
K2 SERIES ULTRACAPACITORS
Part Description
BCAP0650 P270 K04/05
BCAP1200 P270 K04/05
BCAP1500 P270 K04/05
BCAP2000 P270 K04/05
BCAP3000 P270 K04/05
L (
±
0.3mm)
51.5
74
85
102
138
Dimensions (mm)
D1 (
±
0.2mm)
60.4
60.4
60.4
60.4
60.4
D2 (
±
0.7mm)
60.7
60.7
60.7
60.7
60.7
Package Quantity
30
30
30
15
15
Product dimensions are for reference only unless otherwise identified. Product dimensions and specifications may change without notice.
Please contact Maxwell Technologies directly for any technical specifications critical to application. All products featured on this datasheet are covered
by the following U.S. patents and their respective counterparts: 6643119, 7295423, 7342770, 7352558, 7384433, 7440258, 7492571, 7508651, 7580243,
