CX3VSM CRYSTAL
18 kHz to 600 kHz
Miniature Surface Mount
Quartz Crystal for Pierce Oscillators
DESCRIPTION
The CX3VSM quartz crystals are leadless devices
designed for surface mounting on printed circuit boards
or hybrid substrates. These miniature crystals are
intended to be used in Pierce oscillators. They are
hermetically sealed in a rugged, miniature ceramic
package. They are manufactured using the STATEK-
developed photolithographic process, and were
designed utilizing the experience acquired by producing
millions of crystals for industrial, commercial, military and
medical applications. Maximum process temperature
should not exceed 260
O
C.
FEATURES
actual size
Glass Lid Shown
PACKAGE DIMENSIONS
D
side view
A
TOP
E
BOTTOM
D
B
E
C
Miniature tuning fork design
High shock resistance
Designed for low power applications
Compatible with hybrid or PC board packaging
Low aging
Full military testing available
Ideal for battery operated applications
Designed and manufactured in the USA
EQUIVALENT CIRCUIT
TYP.
DIM
A
B
C
D
E
DIM “C“”
MAX
SM1
SM2/SM4
inches
0.263
0.097
-
0.052
0.030
mm
6.68
2.46
-
1.32
0.76
inches
0.270
0.104
0.058
0.035
MAX.
mm
6.86
2.64
1.47
0.89
see below
GLASS LID
inches
0.053
0.055
0.058
mm
1.35
1.40
1.47
CERAMIC LID
inches
0.067
0.069
0.072
mm
1.70
1.75
1.83
C
0
1
L
1
C
1
R
1
2
SM3/SM5
CONVENTIONAL CMOS
PIERCE OSCILLATOR CIRCUIT
R
1
Motional Resistance L
1
Motional Inductance
C
1
Motional Capacitance C
0
Shunt Capacitance
SUGGESTED LAND PATTERN
0.070 (1.78)
R
f
BUFFER
OSC
Freq (f
O
)
AMPLIFIER
0.110 (2.79)
R
A
C
G
inches (mm)
0.210 (5.33)
CX3
XTAL
C
D
10104 - Rev C
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256
www.statek.com
SPECIFICATIONS
FIGURE 1
CX3V TYPICAL MOTIONAL RESISTANCE (R
1
)
Specifications are typical at 25
0
C unless otherwise noted.
Specifications are subject to change without notice.
Frequency Range
18 kHz to 600 kHz
Functional Mode
Tuning Fork (Flexure)
Standard Calibration Tolerance
1
(see table below)
Motional Resistance (R
1
)
See Figure 1
MAX.: 18-25 kHz, 2x Typ.
25-600 kHz, 2.5x Typ.
Motional Capacitance (C
1
) Figure 2
Quality Factor (Q)
Figure 3
MIN is 0.25x Typ.
Shunt Capacitance (C
0
)
1.8 pF MAX
Drive Level
18-24.9 kHz 0.5
µW
MAX.
25-600 kHz 1.0
µW
MAX.
2
Turning Point (T
0
)
Figure 4
Temperature Coefficient (k) -0.035 ppm/
0
C
2
Aging, first year
5 ppm MAX
3
Shock, survival
1,500 g peak, 0.3 ms, 1/2 sine
3
Vibration, survival
10 g RMS, 20-2,000 Hz random
Operating Temp. Range
-10
O
C to +70
O
C (Commercial)
-40
O
C to +85
O
C (Industrial)
-55
O
C to +125
O
C (Military)
Storage Temp. Range
-55
O
C to +125
O
C
Max Process Temperature 260
O
C for 20 sec.
1. Tighter frequency calibration available.
2. Other turning point available.
3. Higher shock and vibration available.
300
200
100
50
R
1
(k )
20
10
5
2
18
50
100
200
600
Frequency (kHz)
FIGURE 2
CX3V TYPICAL MOTIONAL CAPACITANCE (C
1
)
5
C
1
(fF)
2
1.0
0.5
18
50
FIGURE 3
CX3V TYPICAL QUALITY FACTOR (Q)
Frequency (kHz)
100
200
600
300
200
(in 1000's)
100
50
20
CX3V Standard Calibration T
olerance at 25
0
C
Frequency Range (kHz)
18-74.9
30 ppm
(0.003%)
+
_
+
_
18
50
75-169.9
50 ppm
(0.005%)
+
_
+
_
170-249.9
+
_
250-600
+
_
FIGURE 4
CX3V TYPICAL TURNING POINT TEMP (T
0
)
.
Frequency (kHz)
100
200
600
100 ppm
(0.01%)
200 ppm
(0.02%)
200 ppm
(0.02%)
+
_
1000 ppm
(0.1%)
+
_
1000 ppm
(0.1%)
+
_
2000 ppm
(0.2%)
+
_
5000 ppm
(0.5%)
Load Capacitance (C
L
), Used to Calibrate CX3V
(other C
L
available)
T
O
(
O
C)
100 ppm
(0.01%)
100 ppm
(0.01%)
+
_
+
_
500 ppm
(0.05%)
+80
+70
+60
+50
+40
+30
+20
+10
0
-10
-20
18
Frequency (kHz)
50
100
200
600
Frequency Load
Range
Capacitance
(kHz)
(pF)
18-24.9
25-54.9
55-100.0
CX3V
S
Frequency
Range
(kHz)
100.1-179.9
180-600
Load
Capacitance
(pF)
5
4
Note: Frequency f at temperature T is related to frequency f
0
at
turning point temperature T
0
by:
2
f-f
0
=
k(T-T
0
)
TERMINATIONS
f
0
10
9
8
C
SM1
32.0K
Frequency
K = kHz
HOW TO ORDER CX3VSM CRYSTALS
,
30
/
M
Blank = Glass Lid
C = Ceramic Lid
SM1 = Gold Plated (Lead Free)
SM2 = Solder Plated
“S” if special or
SM3 = Solder Dipped
custom design.
SM4 = Solder Plated (Lead Free)
Blank if Std.
SM5 = Solder Dipped (Lead Free)
Calibration Operating Temp. Range:
Tolerance C = -10
O
C to +70
O
C
@ 25
O
C I = -40
O
C to +85
O
C
(in ppm) M = -55
O
C to +125
O
C
S = Customer Specified
Designation
SM1
SM2
SM3
SM4
SM5
CX3VSM
Termination
Gold Plated (Lead Free)
Solder Plated
Solder Dipped
Solder Plated (Lead Free)
Solder Dipped (Lead Free)
- Tray Pack
- Tape and Reel
(Reference tape and reel data sheet 10109)
10104 - Rev C
PACKAGING OPTIONS
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256
www.statek.com
