LHGAT OSCILLATOR
Leaded Military Grade/High Shock
320 kHz - 50 MHz
DESCRIPTION
An increasing number of military applications require the use
of leaded (through hole) ceramic packaged oscillators. For
these applications, Statek offers the LHGAT 5x7mm
oscillator. This oscillator is designed to operate over a
temperature range of -55ºC to 125ºC with high shock
survivability.
FEATURES
PIN CONNECTIONS
Full military testing available
Excellent stability over temperature
High shock resistance
CMOS output / output enable/disable
Double hermetically sealed package option
Hermetically sealed ceramic package - 5x7mm
Through-hole leaded package
Reduces mechanical and thermal mounting stresses
Robust lead-attach eutectic brazing process
Gold Plated Kovar Leads
APPLICATIONS
1.
2.
3.
4.
Enable/Disable (E) or No Connection (N)
Ground
Output
V
DD
DIMENSIONS
TYPICAL
DIM
A
B
C
D
E
F
G
H
I
J
inches
0.276
0.197
0.065
0.200
0.195
0.200
0.040
0.160
0.028
0.018
mm
7.00
5.00
1.65
5.08
4.90
5.08
1.02
4.06
0.71
0.46
MAX
inches
.281
.202
.070
.205
.205
.205
mm
7.14
5.13
1.78
5.20
5.20
5.20
Military and Aerospace
Navigation / Communications
Avionics applications
Flight recorder
Engine control
PACKAGE DIMENSIONS LHGAT
0.021
0.53
Lead Thickness: 0.008 ±0.001 (0.20mm ±0.03)
Lead Plating: Gold/Nickel over Kovar
10211 Rev B
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256
www.statek.com
SPECIFICATIONS
ABSOLUTE MAXIMUM RATINGS
O
Specifications are typical at 25 C unless otherwise noted.
Specifications are subject to change without notice. Tighter
specifications available. Please contact factory.
Supply Voltages
1
Calibration Tolerance
Frequency Stability
Over Temperature
2
Total Frequency
3
Tolerance
Supply Current (Typical)
1.8 V to 5.0 V
± 20 ppm and up
± 100 ppm to ±40 ppm (Military)
± 100 ppm to ±30 ppm (Industrial)
± 50 ppm to ±15 ppm (Commercial)
± 100 ppm for Military
± 50 ppm for Industrial
± 30 ppm for Commercial
5.0 V
3.3 V
24 MHz
3.0 mA
8.0 mA
32 MHz
5.0 mA
10 mA
40 MHz
5.5 mA
12 mA
50 MHz
6.0 mA
13 mA
Supply Voltage V
DD
Storage Temperature
Maximum Process Temperature
-0.5 V to 7.0 V*
-55
O
C to +125
O
C
260
O
C for 20 seconds
*The supply voltage range is -0.5 V to +4.0 V for some products. Contact Factory.
ENABLE/DISABLE OPTIONS (E/N)
Statek offers three enable/disable options: E, T, and N.
Both the E-version and T-version have Tri-State outputs and
differ in whether the oscillator continues to run internally
when the output is put into the high Z state: it stops in the
E-version and continues to run in the T-version. So, the E-
version offers very low current consumption when the
oscillator is disabled and the T-version offers very fast output
recovery when the oscillator is re-enabled. The N-version
does not have PIN 1 connected internally and so has no
enable/disable capability. The following table summarizes
the three options.
COMPARISON OF
ENABLE/DISABLE OPTIONS E AND T
Output Load (CMOS)
Start-up Time
Rise/Fall Time
Duty Cycle
4
Aging, first year
Shock, survival
5
15 pF
5 ms MAX
4 ns TYP, 8 ns MAX
40% MIN, 60% MAX
5 ppm
Std: 5,000 g, 0.5 ms,
1
/
2
sine
HG: up to 30,000 g, 0.5 ms,
1
/
2
sine
Vibration, survival
20 g, 10-2,000 Hz swept sine
Operating Temp Ranges
6
-55
O
C to +125
O
C (Military)
-40
O
C to +85
O
C (Industrial)
-10
O
C to + 70
O
C (Commercial)
1. Not all frequencies are available in certain voltages. Contact factory for details.
2. Does not include calibration tolerance.
3. Tighter tolerances available; Does not include aging.
4. Tighter Duty Cycles available. Contact factory.
5. Contact factory for requirements above 30,000 g.
E
T
7
When enabled (PIN 1 is high*)
Output
Oscillator
Current consumption
Freq. output
Oscillates
Normal
Freq. output
Oscillates
Normal
When disabled (PIN 1 is low)
Output
Oscillator
Current consumption
High Z state
Stops
Very low
High Z state
Oscillates
Lower than normal
6. Higher temp available (up to 200
O
C). Contact factory.
Note: All parameters are measured at ambient temperature with a 10 MΩ, 15 pF load.
When re-enabled (PIN 1 changes from low to high)
Output recovery
Delayed
Immediate
PACKAGING OPTIONS
7. The T-version is not available for all frequencies. Contact factory.
LHGAT - Tube Pack (Standard)
HOW TO ORDER LHGAT OSCILLATORS
LHGAT
4
Supply Voltage
1 = 1.8 V
2 = 2.5 V
3 = 3.0 V
4 = 3.3 V
5 = 5.0 V
*
When PIN 1 is allowed to float, it is held high by an internal pull-up resistor.
B
“S” if special or
custom design.
Blank if Std.
Shock Level
A = 5,000 g
B = 10,000 g
C = 20,000 g
D = 30,000 g
E
Enable/Disable
Option
E, T or N
05
Terminations
Blank = Gold Plated
03
= Solder Dipped
05
= Solder Dipped
(Lead Free)
20.0M
Frequency
M = MHz
K = kHz
,
50
Calibration
Tolerance
@ 25
0
C
(in ppm)
/
50
Frequency
Stability over
Temp. Range
(in ppm)
/
/
M
Temperature Range:
C = -10
O
C to +70
O
C
I
= -40
O
C to +85
O
C
M = -55
O
C to +125
O
C
S = Customer Specified
OR
Note: The LHGAT oscillator with gold plated or 05
termination is Pb free. The LHGAT oscillator with 03
termination contains Pb.
/
/
100
Total
Frequency
Tolerance
(in ppm)
/
M
Temperature Range:
C = -10
O
C to +70
O
C
I
= -40
O
C to +85
O
C
M = -55
O
C to +125
O
C
S = Customer Specified
10211 Rev B
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256
www.statek.com
