M4
M4
R
Characteristics
Electrostatic capacitance
Between open Contacts
Between coil & Contacts
Between Contact Poles
Insulation Resistance
Dielectric Strength
Between open Contacts
Between coil & Contacts
Between Contact Poles
Surge Withstand Voltage
Between open Contacts
Between coil & Contacts
Between Contact Poles
Shock resistance
Vibration resistance
Approx.0.7pF
Approx.1.0pF
Approx.0.9pF
1000M min (at 500VDC)
1000VAC 1min
1000VAC 1min
1000VAC 1min
1500V
1500V
1500V
Functional:100m/s
2
11ms;
Survival:1000 m/s
2
6ms
10~55Hz Double amplitude
Functional:1.5mm Survival:5mm
5N
235
2
3 0.5s
-40~90 (-40~194 F)
(-40~80 for 0.3W Coil)
4.5g
Item 4.41 of IEC 61810-7
Item 4.41 of IEC 61810-7
Item 4.41 of IEC 61810-7
Item 7 of IEC 61810-5
Item 6 of IEC 61810-5
Item 6 of IEC 61810-5
Item 6 of IEC 61810-5
FCC68
FCC68
FCC68
IEC68-2-27 Test Ea
IEC68-2-6 Test Fc
IEC68-2-21 Test Ua1
IEC68-2-20 Test Ta method 1
20.0 9.8 12.0
C
US
E169380
R50044268
Features
DIL Pitch Terminals .High Sensitivity.
Conforms to FCC Part 68 1.5kV Surge and Dielectric 1000VAC.
Fully sealed (immersion cleaning).
High Reliability bifurcated Contact.
Application for Telecommunication Equipment,Office Equipment,Security Alarm Systems,Measuring instruments,
Medical Monitoring Equipment,Audio Visual Equipment,Flight Simulator,Sensor Control.
Ordering Information
M4 12 H A
1
2
3
4
W
5
3 Enclosure H: Sealed Type
4 Nominal coil power Nil:0.15W A:0.2W M:0.45W
5 Contact material Nil: AgPd W: AgNi
1 Part mumber M4
2 Coil rated voltage DC:3:3V 5:5V 6:6V 9:9V
12:12V 18:18V 24:24V 48:48V
Terminals strength
Solderability
Temperature Range
Contact Data
Contact Arrangement
Contact Material
Contact Rating (resistive)
Max. Switching Power
Max. Switching Voltage
Contact Resistance or
Voltage drop
Operational
Life
Electrical
Mechanical
2C DPDT(B-M)
Bifurcated Crossbar
AgPd( Gold clad ) AgNi(Gold clad
1A/24VDC; 0.5A/120VAC
60W 125VA
220VDC 250VAC
50m
1A/24VDC 5 10
5
Ag Ni
0.5A/120VAC 2 10
5
10
8
1
10
5
Item 4.30 of IEC 61810-7
Item 4.30 of IEC 61810-7
Mass
Safety approvals
Min. Switching load 0.01mA/10mV Reference Value
Max. Switching Current:2A
Item 4.12 of IEC 61810-7
Safety approval
Load
UL&CUR
1A/24VDC 0.5A/120VAC
T
U
V
1A/24VDC
0.5A/120VAC
Dimensions
20max.
0.787max.
9.8max.
0.386max.
1
4
6
8
mm/inch
CAUTION:
Relays previously tested or used above 10mA resistive at 6VDC maximum or peak AC open circuit are not
recommended for subsequent use in low level applications.
Dash
numbers
M4-003
M4-005
M4-006
M4-009
M4-012
M4-018
M4-024
M4-048
M4-003A
M4-005A
M4-006A
M4-009A
M4-012A
M4-024A
M4-048A
M4-005M
M4-006M
M4-009M
M4-012M
M4-018M
M4-024M
M4-048M
Coil voltage
VDC
Rated
3
5
6
9
12
18
24
48
3
5
6
9
12
24
48
5
6
9
12
18
24
48
Max.
7.5
12.5
15.0
22.5
30.0
40.0
52.9
84.9
6.5
10.8
13.0
19.5
26.5
52.9
103.9
7.7
9.2
13.7
18.3
27.5
36.7
72.5
Coil
resistance
10%
60
167
240
540
960
1620
2880
7680
45
125
180
405
720
2880
11520
56
80
180
320
720
1280
5000
Pick up voltage
VDC(max)
(70% or 66%of rated
voltage )
2.1
3.5
4.2
6.3
8.4
12.6
16.8
33.6
2.1
3.5
4.2
6.3
8.4
16.8
33.6
3.3
4.0
6.0
8.0
12.0
15.9
33.0
Release voltage
VDC(min)
(5% or 10% of
rated voltage)
0.15
0.25
0.3
0.45
0.6
0.9
1.2
2.4
0.3
0.5
0.6
0.9
1.2
2.4
4.8
0.5
0.6
0.9
1.2
1.8
2.4
4.8
Coil
power
W
0.15
0.15
0.15
0.15
0.15
0.20
0.20
0.30
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.45
0.45
0.45
0.45
0.45
0.45
0.45
Operate
Time
ms
Release
Time
ms
3.5
0.138
12max.
0.472max.
Coil Parameter
16
13
11
9
0.5
0.787
0.25
0.01
7.62
0.30
2.54
0.1
Wiring diagram
(Bottom view)
2.54
0.1
Approx. 5 Approx. 3
1.11
0.044
7.62
0.30
5.08
0.20
5.08
0.20
Dimensions
Approx. 5 Approx. 3
8- 0.8
0.031
Tolerance: 0.1/ 0.004
Approx. 5 Approx. 3
NOTES 1).Dimensions are in millimeters.
2).Inch equivalents are given for general information only.
Mounting (Bottom view)
CAUTION:
1.The use of any coil voltage less than the rated coil voltage will compromise the operation of the relay.
2.Pickup and release voltage are for test purposes only and are not to be used as design criteria.
3.Unless otherwise stated, the rated coil voltage specified in coil parameter table shall be used for all tests
and its application to the relay.
