WIMA MKS 2
Metallized Polyester (PET)
Capacitors in PCM 5 mm
D
Special Features
˜
High volume/capacitance ratio
˜
Self-healing
˜
According to RoHS 2002/95/EC
Electrical Data
Capacitance range:
0.01
mF
to 10
mF
(E12-values on request)
Rated voltages:
50 VDC, 63 VDC, 100 VDC, 250 VDC,
400 VDC, 630 VDC
Capacitance tolerances:
±20%, ±10%, ±5%
Operating temperature range:
–55+ C to +100+ C
Climatic test category:
55/100/21 in accordance with IEC
Insulation resistance
at +20+ C:
U
r
50 VDC
63 VDC
U
test
C
0.33
mF
Test specifications:
In accordance with IEC 60384-2
and EN 130 400
Test voltage:
1.6 U
r
, 2 sec.
Voltage derating:
A voltage derating factor of 1.25 % per K
must be applied from +85+ C for DC
voltages and from +75+ C for AC
voltages
Reliability:
Operational life
300 000 hours
Failure rate
2 fit (0.5 x U
r
and 40) C)
0.33
mF
< C
10
mF
Typical Applications
For general DC-applications e.g.
˜
By-pass
˜
Blocking
˜
Coupling and decoupling
˜
Timing
Construction
Dielectric:
Polyethylene-terephthalate (PET) film
Capacitor electrodes:
Vacuum-deposited
Internal construction:
Plastic film
Vacuum-deposited
electrode
Metal contact layer
(schoopage)
Terminating wire
10 V
5
x 10
3
M¸ (mean value: 3 x 10
4
M¸)
1000
sec (M¸ x
mF)
(mean value: 3000 sec)
50 V
1
x 10
4
M¸ (mean value: 5 x 10
4
M¸)
1250
sec (M¸ x
mF)
(mean value: 3000 sec)
100
VDC 100 V
1.5
x 10
4
M¸ (mean value: 1 x 10
5
M¸)
3000
sec (M¸ x
mF)
(mean value: 6000 sec)
Measuring time: 1 min.
Dissipation factors
at + 20) C: tan
d
at f
1 kHz
10 kHz
100 kHz
C
0.1
mF
8 x 10
-3
15 x 10
-3
30 x 10
-3
0.1
mF
< C
1.0
mF
8 x 10
-3
15 x 10
-3
–
C > 1.0
mF
10 x 10
-3
–
–
Maximum pulse rise time:
for pulses equal to the rated voltage
Capacitance
mF
Pulse rise time V/msec
max. operation/test
100 VDC 250 VDC 400 VDC
35/350
25/250
20/200
15/150
10/100
–
–
–
50/500
50/500
50/500
25/250
–
–
–
–
80/800
80/800
80/800
–
–
–
–
–
50 VDC
–
–
10/100
8/80
8/80
5/50
3/30
2.5/25
63 VDC
35/350
20/200
15/150
12/120
7.5/75
5/50
3/30
–
630 VDC
110/1100
90/900
–
–
–
–
–
–
Encapsulation:
Solvent-resistant, flame-retardant plastic
case with epoxy resin seal, UL 94 V-0
Terminations:
Tinned wire.
Marking:
Colour: Red. Marking: Silver/White.
Epoxy resin seal: Red
0.01
0.033
0.1
0.68
1.5
...
...
...
...
...
0.022
0.068
0.47
1.0
3.3
4.7
6.8
10
Mechanical Tests
Pull test on leads:
10 N in direction of leads according to
IEC 60068-2-21
Vibration:
6 hours at 10 ... 2000 Hz and 0.75 mm
displacement amplitude or 10 g in
accordance with IEC 60068-2-6
Low air density:
1kPa = 10 mbar in accordance with
IEC 60068-2-13
Bump test:
4000 bumps at 390 m/sec
2
in
accordance with IEC 60068-2-29
11.10
Packing
Available taped and reeled.
Detailed taping information and graphs
at the end of the catalogue.
For further details and graphs please
refer to Technical Information.
33
WIMA MKS 4
WIMA FKP 2
Continuation
D
General Data
Capacitance
0.01
0.015
0.022
0.033
0.047
0.068
mF
„
„
„
„
„
W
2.5
2.5
3.5
4.5
4.5
5.5
7.2
8.5
11
H
6.5
6.5
8.5
9.5
9.5
11.5
13
14
16
400 VDC/200 VAC*
L PCM**
Part number
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
7.2
5
5
5
5
5
5
5
5
5
MKS2G021001A00_ _ _ _
MKS2G021501A00_ _ _ _
MKS2G022201C00_ _ _ _
MKS2G023301E00_ _ _ _
MKS2G024701E00_ _ _ _
MKS2G026801H00_ _ _ _
MKS2G031001K00_ _ _ _
MKS2G031501M00_ _ _ _
MKS2G032201N00_ _ _ _
W
5.5
7.2
7.2
7.2
8.5
H
11.5
13
13
13
14
630 VDC/220 VAC*
L PCM**
Part number
7.2
7.2
7.2
7.2
7.2
5
5
5
5
5
MKS2J021001H00_ _ _ _
MKS2J021501K00_ _ _ _
MKS2J022201K00_ _ _ _
MKS2J023301K00_ _ _ _
MKS2J024701M00_ _ _ _
0.1
mF
0.15 „
0.22 „
* AC voltage: f = 50 Hz; 1.4 x U
rms
+ UDC
U
r
** PCM = Printed circuit module = lead spacing.
Dims. in mm.
The values of the WIMA MKM 2 and
WIMA MKI 2 ranges according to the
main catalogue 2009 are still available
on request.
Part number completion:
Tolerance:
20 % = M
10 % = K
5%=J
Packing:
bulk = S
Lead length: 6-2 = SD
Taped version see page 127.
Impedance change with frequency
(general guide).
Rights reserved to amend design data without prior notification.
Permissible AC voltage in relation to
frequency at 10) C internal tempera-
ture rise (general guide).
