MSCD100B
Glass Passivated Rectifier
Diode Modules
V
RRM
800 to 1800V
I
FAV
100 Amp
Applications
Non-controllable rectifiers for AC/AC
converters
Line rectifiers for transistorized AC motor
controllers
Field supply for DC motors
Circuit
Features
Blocking voltage:800 to 1800V
Heat transfer through aluminum oxide DBC
ceramic isolated metal baseplate
Glass passivated chip
Module Type
TYPE
MSCD100B-08
MSCD100B-12
MSCD100B-16
MSCD100B-18
MSAD100B-08
MSAD100B-12
MSAD100B-16
MSAD100B-18
MSKD100B-08
MSKD100B-12
MSKD100B-16
MSKD100B-18
V
RRM
800V
1200V
1600V
1800V
V
RSM
900V
1300V
1700V
1900V
Maximum Ratings
Symbol
Conditions
Single phase ,half wave 180°conduction Tc=109℃
I
FAV
Single phase ,half wave 180°conduction Tc=97℃
I
F(RMS)
t=10mS Tvj =45℃
I
FSM
2
t=10mS Tvj =45℃
it
a.c.50HZ;r.m.s.;1min
V
isol
T
vj
T
stg
Mt
Ms
Weight
To terminals(M5)
To heatsink(M6)
Module
Values
100
150
2500
31250
3000
-40 to +150
-40 to +125
3±15%
5±15%
140
Units
A
A
A
A
2
s
V
℃
℃
Nm
Nm
g
Thermal Characteristics
Symbol
R
th(j-c)
R
th(c-s)
Electrical Characteristics
Symbol
V
FM
I
RD
Document Number: MSCD100B
Aug.20, 2010
Conditions
Per diode
Module
Values
0.35
0.1
Units
℃/W
℃/W
Conditions
T=25℃ I
F
=300A
T
vj
=150℃ V
RD
=V
RRM
1
Values
Min.
-
-
Typ.
1.30
-
Max.
1.55
5
Units
V
mA
www.
smsemi.com
MSCD100B
Performance Curves
150
W
sin.180
rec.120
DC
200
A
DC
100
rec.60
rec.30
100
sin.180
rec.120
50
rec.60
rec.30
P
vtot
I
D
0
0 I
D
90
A 180
0
0 Tc
50
100
℃
150
Fig1. Power dissipation
0.5
℃/
W
Z
th(j-
C
)
3000
A
Fig2.Forward Current Derating Curve
50HZ
0.25
1500
0
0.001
0.01
0.1
1.0
10
S 100
0
1
10
cycles 100
Fig3. Transient thermal impedance
400
A
300
typ.
200
max.
100
IF
0
0
VF
0.5
1.0
1.5
V 2.0
25℃
- - -125℃
Fig4. Max Non-Repetitive Forward Surge
Current
Fig5. Forward Characteristics
Document Number: MSCD100B
Aug.20, 2010
www.
smsemi.com
2
