NCV7342
High Speed Low Power CAN
Transceiver
Description
The NCV7342 CAN transceiver is the interface between a
controller area network (CAN) protocol controller and the physical
bus and may be used in both 12 V and 24 V systems. The transceiver
provides differential transmit capability to the bus and differential
receive capability to the CAN controller.
The NCV7342 is an addition to the CAN high−speed transceiver
family complementing NCV734x CAN stand−alone transceivers and
previous generations such as AMIS42665, AMIS3066x, etc.
Due to the wide common−mode voltage range of the receiver inputs
and other design features, the NCV7342 is able to reach outstanding
levels of electromagnetic susceptibility (EMS). Similarly, extremely
low electromagnetic emission (EME) is achieved by the excellent
matching of the output signals.
8
www.onsemi.com
8
1
SOIC−8
D SUFFIX
CASE 751AZ
1
DFN8
MW SUFFIX
CASE 506DG
MARKING DIAGRAMS
NV7342−x
ALYW
G
G
1
NV7342−x= Specific Device Code
x = 0 or 3
A
= Assembly Location
L
= Wafer Lot
Y
= Year
W
= Work Week
G
= Pb−Free Package
(Note: Microdot may be in either location)
1
NV7342−x
ALYWG
G
Features
•
Compatible with the ISO 11898−2, ISO 11898−5 Standards
•
High Speed (up to 1 Mbps)
•
V
IO
Pin on NCV7342−3 Version Allowing Direct Interfacing with
•
•
•
•
•
•
•
•
•
•
•
•
3 V to 5 V Microcontrollers
V
SPLIT
Pin on NCV7342−0 Version for Bus Common Mode
Stabilization
Very Low Current Consumption in Standby Mode with Wake−up via
the Bus
Excellent Electromagnetic Susceptibility (EMS) Level Over Full
Frequency Range. Very Low Electromagnetic Emissions (EME) Low
EME Also Without Common Mode (CM) Choke
Bus Pins Protected Against >15 kV System ESD Pulses
Transmit Data (TxD) Dominant Time−out Function
Bus Dominant Time−out function in Standby Mode
Under All Supply Condition the Chip Behaves Predictably
No Disturbance of the Bus Lines with an Unpowered Node
Thermal Protection
Bus Pins Protected Against Transients in an Automotive
Environment
Bus Pins Short Circuit Proof to Supply Voltage and Ground
These are Pb−Free Devices
PIN ASSIGNMENTS
TxD
GND
V
CC
RxD
1
NV7342−x
ALYWG
G
2
3
4
8
7
6
5
STB
CANH
CANL
V
SPLIT
(−0)
V
IO
(−3)
TxD
GND
V
CC
RxD
1
2
3
4
(Top Views)
EP Flag
8 STB
7 CANH
6 CANL
5 V
IO
Quality
•
Wettable Flank Package for Enhanced Optical Inspection
•
NCV Prefix for Automotive and Other Applications Requiring
Unique Site and Control Change Requirements; AEC−Q100
Qualified and PPAP Capable
Typical Applications
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 13 of this data sheet.
•
Automotive
•
Industrial Networks
©
Semiconductor Components Industries, LLC, 2016
1
June, 2016 − Rev. 4
Publication Order Number:
NCV7342/D
NCV7342
Table 1. KEY TECHNICAL CHARACTERISTICS AND OPERATING RANGES
Symbol
V
CC
V
UVVcc
I
CC
I
CCS
V
CANH
V
CANL
V
CANH,L
V
ESD
V
O(dif)(bus_dom)
CM−range
C
load
t
pd_dr
Parameter
Power supply voltage
Undervoltage detection voltage
on pin V
CC
(NCV7342−3 only)
Supply current
Supply current in standby mode
including V
IO
current
DC voltage at pin CANH
DC voltage at pin CANL
DC voltage between CANH and
CANL pin
Electrostatic discharge voltage
Differential bus output voltage in
dominant state
Input common−mode range for
comparator
Load capacitance on IC outputs
Propagation delay TxD to RxD
dominant to recessive transition
See Figure 8
Propagation delay TxD to RxD
recessive to dominant transition
See Figure 8
Junction temperature
C
i
= 100 pF between CANH to
CANL, C
RxD
= 15 pF
C
i
= 100 pF between CANH to
CANL, C
RxD
= 15 pF
50
100
Dominant; V
TxD
= 0 V
Recessive; V
TxD
= V
IO
T
J
v
100°C, (Note 1)
0 < V
CC
< 5.5 V; no time limit
0 < V
CC
< 5.5 V; no time limit
0 < V
CC
< 5.5 V
IEC 61000−4−2 at pins CANH
and CANL
45
W
< R
LT
< 65
W
Guaranteed differential receiver
threshold and leakage current
−50
−50
−50
−15
1.5
−35
Conditions
Min
4.5
3.5
Typ
Max
5.5
4.5
75
10
15
+50
+50
+50
15
3
+35
15
230
Unit
V
V
mA
mA
V
V
V
kV
V
V
pF
ns
t
pd_rd
50
120
230
ns
T
J
−40
150
°C
1. Not tested in production. Guaranteed by design and prototype evaluation.
www.onsemi.com
2
NCV7342
TYPICAL APPLICATION
VBAT
5V−reg
3V−reg
V
IO
V
IO
5
3
7
STB
Micro
Controller
RxD
4
TxD
1
2
GND
GND
6
CANL
R
LT
= 60
W
RB20120816
NCV7342−3
CANH
8
C
LT
= 4.7 nF CAN
BUS
V
CC
R
LT
= 60
W
Figure 3. Application Diagram NCV7342−3
VBAT
IN
5V−reg
OUT
V
CC
STB
8
NCV7342−0
RxD
4
TxD
1
RB20120816
2
GND
GND
3
7
CANH
V
SPLIT
C
LT
= 4.7 nF
CAN
BUS
V
CC
R
LT
= 60
W
Micro
Controller
5
6
CANL
R
LT
= 60
W
Figure 4. Application Diagram NCV7342−0
Table 2. PIN FUNCTION DESCRIPTION
Pin
1
2
3
4
5
5
6
7
8
EP
Name
TxD
GND
V
CC
RxD
V
IO
V
SPLIT
CANL
CANH
STB
Exposed Pad
Description
Transmit data input; Low input
Ù
dominant driver; internal pull−up current
Ground
Supply voltage
Receive data output; dominant transmitter
Ù
Low output
Input/Output pins supply voltage. On NCV7342−3 only
Common−mode stabilization output. On NCV7342−0 only
Low−level CAN bus line (Low in dominant mode)
High−level CAN bus line (High in dominant mode)
Standby mode control input
Connect to GND or left floating
www.onsemi.com
5
