High power chip resistors<wide terminal type / anti-surge>
LTR series
●
Datasheet
Features
1)High joint reliability with long side terminations.
2)Highest power ratings in their class.
3)Guaranteed anti-surge characteristic in all series.
4)ROHM resistors have obtained ISO9001 / IATF16949 certification.
5)Corresponds to AEC-Q200.
●
Products list
Size
(mm)
Rated
power
(70
℃
)
(inch)
(W)
Limiting
element
voltage
(V)
T
emperature
coefficient
Resistance
tolerance
Resistance range
Operating
temperature
range
(
℃
)
-55
½
+155
Automotive
grade
available
Part No.
(ppm /
℃
)
(%)
(Ω)
±100
D ( ±0.5% )
10
≦
R
≦
1M (E24/96 series)
LTR10
1220 0508 0.25
150
±100
F ( ±1% )
1
≦
R
≦
1M (E24 series)
±200
J ( ±5% )
1
≦
R
≦
1M (E24 series)
±100
D ( ±0.5% )
10
≦
R
≦
1M (E24/96 series)
LTR18
1632 0612 0.75
200
±100
F ( ±1% )
1
≦
R
≦
1M (E24 series)
±200
J ( ±5% )
1
≦
R
≦
1M (E24 series)
±100
D ( ±0.5% )
10
≦
R
≦
130k (E24 series)
LTR50
2550 1020 1.0
200
±100
F ( ±1% )
1
≦
R
≦
1M (E24 series)
±200
J ( ±5% )
1
≦
R
≦
1M (E24 series)
±100
D ( ±0.5% )
10
≦
R
≦
1M (E24 series)
LTR100
3264 1225 2.0
200
±100
F ( ±1% )
1
≦
R
≦
1M (E24 series)
J ( ±5% )
(E24 series)
±200
1
≦
R<1M
*E24 : Standard products, E96 : Custom products.(Class J is E24 series only)
Design and specifications are subject to change without notice.
Carefully check the specification sheet supplied with the product before using or ordering it.
●
Yes
-55
½
+155
Yes
-55
½
+155
Yes
-55
½
+155
Yes
Part Number Description
L T R
Part No.
LTR
(High power
chip resistors
wide terminal
type / anti-
surge)
1 8
Size
(mm [inch])
10(1220 [0508])
18(1632 [0612])
50(2550 [1020])
100(3264 [1225])
EZ P
Packaging specifications code
Packaging
Part No. Code specifications
Paper tape
LTR10
EZP (4mm Pitch)
Paper tape
LTR18
EZP (4mm Pitch)
Embossed tape
LTR50
UZP (4mm Pitch)
Embossed tape
LTR100
JZP (4mm Pitch)
Quantity
/ Reel
5,000
5,000
5,000
4,000
J
Resistance
tolerance
D (±0.5%)
F (±1%)
J (±5%)
1 0 5
Nominal resistance
Resistance code, 3 or 4 digits.
Resistance
tolerance
D,F
J
：
：
Resistance
code
4 digits
3 digits
EX.)
1Ω = 1R00 (±1%)
1R0 (±5%)
9.1Ω = 9R10 (±1%)
9R0 (±5%)
10Ω = 10R0 (±0.5%,± 1%)
100 (±5%)
1MΩ = 1004 (±0.5%,± 1%)
105 (±5%)
www.rohm.com
© 2020 ROHM Co., Ltd. All rights reserved.
1/4
2020.07 - Rev.J
LTR series
●
Datasheet
Derating curve
When the ambient temperature exceeds 70°C, power dissipation must be adjusted according to the derating curve below.
■
LTR 10 / 18 / 50 / 100
●
Characteristics
T items
est
Guaranteed value
See P.1
See P.1
±(2.0
％＋
0.1Ω)
Anew uniform coating of minimum
of 95% of the surface being
immersed and no soldering
damage.
±(1.0
％＋
0.05Ω)
No remarkable abnormality on the appearance.
±(1.0
％＋
0.05Ω)
±(3.0
％＋
0.1Ω)
±(3.0
％＋
0.1Ω)
±(3.0
％＋
0.1Ω)
±(1.0
％＋
0.05Ω)
±(1.0
％＋
0.05Ω)
Without mechanical damage such as breaks.
20
℃
Measurement
：
+25/-55, +25/+125
℃
T voltage is the smaller one of
①
or
②
est
①
Rated voltage(current)×2.5
，
2s
②
Maximum overload voltage
※
Rosin-ethanol solution(25% mass)
Soldering condition
：
245±5
℃
Duration of immersion
：
2.0±0.5s
Soldering condition
：
260±5
℃
Duration of immersion
：
10±1s
T temp
：
-55
℃½
+125
℃
5cycles
est
40
℃，
93
％
(Relative humidity)
T time
：
1,000h
est
Rated voltage(current),70
℃
1.5h:ON
－
0.5h:OFF
T time
：
1,000h
est
155
℃
T time
：
1,000h
est
23±5
℃
Immersion cleaning,
Solvent: 2-propanol
-
EIAJ ED-4701/300 T method 304
est
Voltage
：
3kV
C
：
100pF
R
：
1.5kΩ
Apply cycle
：
Once
Compliance Standard(s) : IEC60115-8
JIS C 5201-1
T conditions
est
Resistance
Variation of resistance
with temperature
Overload
Solderability
Resistance to
soldering heat
Rapid change of
temperature
Damp heat, steady state
Endurance at 70
℃
Endurance
Resistance to solvent
Bend strength of
the end face plating
Static
electric
characteristics
±(5.0
％＋
0.05Ω)
※
Maximum overload voltage (T voltage)
est
LTR10
300V
LTR18
400V
LTR50
400V
LTR100
400V
www.rohm.com
© 2020 ROHM Co., Ltd. All rights reserved.
3/4
2020.07 - Rev.J
