F-217
T2M–110–01–L–D–TH–WT–DS
ISD2–05–D
™
ISD2–05–D–S
CC81–2426–01–L
T2M–105–01–L–D–RA–WT
(2.00 mm) .0787"
ISD2, CC81L, CC81R, T2M SERIES
DISCRETE WIRE COMPONENTS & TOOLING
SPECIFICATIONS
For complete specifications
see www.samtec.com?ISD2
www.samtec.com?CC81L
or www.samtec.com?CC81R
TYPE
POSITIONS
PER ROW
ROW
OPTION
LATCH
OPTION
TYPE
WIRE
GAUGE
01
L
–L
TOOLING
• Hand tool:
CAT-HT-281-2430-13
• Mini Applicator
(24-26 AWG):
CAT-MA-281-2426-XX-01
• Mini Applicator
(28-30 AWG):
CAT-MA-281-2830-XX-01
• Extraction tool:
CAT-EX-169-01
ISD2
= Body,
Loose
(Standard sizes)
Insulator Material:
Black LCP
(2.07) .081
(2.03)
.080
(2.64)
.104
–05,
–07, –10,
–15, –20,
–25, –30
= Double
Row
–D
= Metal
Retention
Latch
–M
–S
= Contact, Loose
CC81L
= 24 to 26 AWG
–2426
–2830
= Screw
Down
(2.00)
.079
DIA
= Contact,
Full Reel
(17,000 Parts
per Reel)
CC81R
= 28 to 30 AWG
Contact Material:
BeCu
(0.38)
.014
= 10 µ"
(0.25 µm)
Gold on
contact
(3.68)
.145
(12.35)
.486
(1.78)
.070
(1.27)
.050
DIA
(6.00)
.236
(3.17)
.125
–M
–S
Board Mate:
S2M
Cable Mate:
S2SD, S2SDT
T2M
1
NO. OF
POSITIONS
01
PLATING
OPTION
D
OPTION
OTHER
OPTION
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?T2M
Insulator Material:
Black Liquid Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
Sn or Au over 50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +105 °C with Tin;
-55 °C to +125 °C with Gold
RoHS Compliant:
Yes
05, 07, 10,
15, 20, 25, 30
(Per Row)
= 10 µ" (0.25 µm) Gold on contact,
Matte Tin on tail
(6.00)
.236
(3.98)
.157
–L
= Through-hole
–TH
No. of positions x (2.00) .0787 + (14.38) .566
= Right-angle
–RA
= Weld Tab
(S2SD & S2SDT,
–SR/–DR required
mate)
–WT
= Surface Mount
–SM
(0.64)
.025
SQ
(3.81)
.150
No. of positions x (2.00) .0787 + (5.67) .223
(1.98)
.078
–DS
(1.77)
(2.26) .070
.089
= Screw Down
(N/A with –RA)
(mates with
–S2M–DS,
S2SD/S2SDT
–SS/–DS option)
–DS
PROCESSING
Lead–Free Solderable:
Yes
SMT Lead Coplanarity:
(0.10 mm) .004" max
02
(2.29)
.090
(7.44)
.293
= (7.50 mm) .295" DIA
Polyimide film
Pick & Place Pad
(–SM only)
–K
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
(2.00)
.0787
01
–RA–WT
(2.00)
.0787 (1.52)
.060
= Tape & Reel
(–SM only)
–TR
FILE NO. E111594
(8.76)
.345
(2.41)
.095
(2.00)
.0787
(0.50)
.020
SQ
(0.64)
.025
(6.55)
.258 (1.64)
.065
Note:
Some lengths,
styles and options are
non-standard, non-returnable.
(8.63) .340
–TH–WT
–SM–WT
