DDR2 SDRAM SO-DIMM
HYMP112S64(L)8
DESCRIPTION
128Mx64 bits
Hynix HYMP112S648 series is unbuffered 200-pin double data rate 2 Synchronous DRAM Small Outline Dual In-Line
Memory Modules (DIMMs) which are organized as 128Mx64 high-speed memory arrays. Hynix HYMP112S648 series
consists of eight 128Mx8 DDR2 SDRAMs in 68 ball FBGA chipsize packages. Hynix HYMP112S648 series provide a
high performance 8-byte interface in 67.60mm X 30.00mm form factor of industry standard. It is suitable for easy inter-
change and addition.
Hynix HYMP112S648 series is designed for high speed and offers fully synchronous operations referenced to both ris-
ing and falling edges of differential clock inputs. While all addresses and control inputs are latched on the rising edges
of the clock, Data, Data strobes and Write data masks inputs are sampled on both rising and falling edges of it. The
data paths are internally pipelined and 4-bit prefetched to achieve very high bandwidth. All input and output voltage
levels are compatible with SSTL_1.8. High speed frequencies, programmable latencies and burst lengths allow variety
of device operation in high performance memory system.
Hynix HYMP112S648 series incorporates SPD(serial presence detect). Serial presence detect function is imple-
mented via a serial 2,048-bit EEPROM. The first 128 bytes of serial PD data are programmed by Hynix to identify
DIMM type, capacity and other the information of DIMM and the last 128 bytes are available to the customer.
FEATURES
•
•
1GB (128M x 64) Unbuffered DDR2 SO - DIMM
based on 128Mx8 DDR2 SDRAM
JEDEC standard Double Data Rate2 Synchronous
DRAMs (DDR2 SDRAMs) with 1.8V +/- 0.1V Power
Supply
All inputs and outputs are compatible with SSTL_1.8
interface
OCD (Off-Chip Driver Impedance Adjustment) and
ODT (On-Die Termination)
•
•
•
•
•
•
Fully differential clock operations (CK & /CK)
Programmable CAS Latency 3 / 4 /5 supported
Programmable Burst Length 4 / 8 with both sequen-
tial and interleave mode
All inputs and outputs SSTL_1.8 compatible
Auto refresh and self refresh supported
8192 refresh cycles / 64ms
•
•
ORDERING INFORMATION
Type
Part No.
HYMP112S64(L)8-E4
PC2-3200 (DDR2-400)
HYMP112S64(L)8-E3
HYMP112S64(L)8-C5
PC2-4300 (DDR2-533)
HYMP112S64(L)8-C4
4-4-4
one rank 1GB
SO-DIMM
3-3-3
5-5-5
Description
CL-tRCD-tRP
4-4-4
Form Factor
200pin Unbuffered SO-
DIMM
67.60 mm x 30,00 mm
(MO-224)
This document is a general product description and is subject to change without notice. Hynix Semiconductor does not assume any
responsibility for use of circuits described. No patent licenses are implied.
Rev. 0.1 / June 2004
2
HYMP112S64(L)8
PIN DESCRIPTION
Symbol
CK[1:0],
CK[1:0]
Type
Polarity
Cross
Point
Active
High
Active
Low
Active
Low
Pin Description
The system clock inputs. All adress an commands lines are sampled on the cross point of the
rising edge of CK and falling edge of CK. A Delay Locked Loop(DLL) circuit is driven from the
clock inputs and output timing for read operations is synchronized to the input clock.
Activates the DDR2 SDRAM CK signal when high and deactivates the CK signal when low. By
deactivating the clocks, CKE low initiates the Power Down mode or the Self Refresh mode.
Enables the associated DDR2 SDRAM command decoder when low and disables the com-
mand decoder when high. When the command decoder is disabled, new commands are
ignored but previous operations continue. Rank 0 is selected by S0; Rank 1 is selected by S1
When sampled at the cross point of the rising edge of CK and falling edge of CK, CAS, RAS
and WE define the operation to be excecuted by the SDRAM.
Selects which DDR2 SDRAM internal bank of four or eight is activated.
Active
High
Asserts on-die termination for DQ, DM, DQS and DQS signals if enabled via the DDR2
SDRAM mode register.
During a Bank Activate command cycle, difines the row address when sampled at the cross
point of the rising edge of CK and falling edge of CK. During a Read or Write command cycle,
defines the column address when sampled at the cross point of the rising edge of CK and fall-
ing edge of CK. In addition to the column address, AP is used to invoke autoprecharge opera-
tion at the end of the burst read or write cycle. If AP is high., autoprecharge is selected and
BA0-BAn defines the bank to be precharged. If AP is low, autoprecharge is disabled. During a
Precharge command cycle., AP is used in conjunction with BA0-BAn to control which bank(s)
to precharge. If AP is high, all banks will be precharged regardless of the state of BA0-BAn
inputs. If AP is low, then BA0-BAn are used to define which bank to precharge.
Data Input/Output pins.
Active
High
The data write masks, associated with one data byte. In Write mode, DM operates as a byte
mask by allowing input data to be written if it is low but blocks the write operation if it is high. In
Read mode, DM lines have no effect.
The data strobe, associated with one data byte, sourced whit data transfers. In Write mode, the
data strobe is sourced by the controller and is centered in the data window. In Read mode, the
data strobe is sourced by the DDR2 SDRAMs and is sent at leading edge of the data window.
DQS signals are complements, and timing is relative to the crosspoint of respective DQS and
DQS. If the module is to be operated in single ended strobe mode, all DQS signals must be
tied on the system board to VSS and DDR2 SDRAM mode registers programmed approriately.
Power supplies for core, I/O, Serial Presense Detect, and ground for the module.
This is a bidirectional pin used to transfer data into or out of the SPD EEPROM. A resister must
be connected to V
DD t
o act as a pull up.
This signals is used to clock data into and out of the SPD EEPROM. A resistor may be con-
nected from SCL to VDD to act as a pull up.
Address pins used to select the Serial Presence Detect base address.
The TEST pin is reserved for bus analysis tools and is not connected on normal memory mod-
ules(SODIMMs).
Input
CKE[1:0]
Input
/S[1:0]
Input
/RAS, /CAS,
/WE
BA[2:0]
ODT{1:0]
Input
Input
Input
A[9:0], A10/AP,
A[15:11]
Input
DQ[63:0]
In/Out
DM[7:0]
Input
DQS[7:0],
DQS[7:0]
In/Out
Cross
point
V
DD
,
V
DD
SPD,V
SS
SDA
Sup-
ply
In/Out
SCL
SA[1:0]
TEST
Input
Input
In/Out
Rev. 0.1 / June 2004
3
