Suntan
M E T A L L I Z E D P O LY E S T E R F I L M C A P A C I T O R - M I N I B O X
N O N - I N D U C T I V E ,
P L A S T I C
C A S E
A N D
E P O X Y
R E S I N
TS05
FEATURES
•
High reliability
•
Box type provides the identical outer
appearance
S P E C I F I C A T I O N S
Reference Standard
Climatic Category
Rated Voltage
Capacitance Range
Capacitance Tolerance
Voltage Proof
Dissipation Factor
GB7332 (IEC 60384-2)
55/100/56
50V, 63V, 100V, 250V, 400V
0.0010
μ
F~2.2
μ
F
±5%(J), ±10%(K), ±20%(M)
1.6 U
R
(5s)
Frequency
C
R
≦
0.1
μ
F
C
R
>0.1
μ
F
1kHz
≦
1.0%
≦
1.0%
10kHz
≦
1.5%
≦
1.5%
100kHz
≦
3.0%
ˍ
U
R
>100V
≧
30
Insulation Resistance
U
R
≦
100V
000MΩ
(20℃, 100V, 1min)
≧
15 000MΩ,C
R
≦
0.33
μ
F
000s,
U
R
(V)
50
63
100
250
400
≧
5
C
R
>0.33
μ
F
(20℃, 100V, 1min)
If the working voltage (U) is lower than the
rated voltage (U
R
), the capacitor can be worked
at a higher dv/dt. In this case, the maximum
allowed dv/dt is obtain by multiplying the right
value with U
R
/U
dv/dt(V/μs)
25
25
30
40
80
Outline Drawing
Dimensions (mm)
(Capacitor Tickness)T
(Lead Wire Dia.)d±0.05
(Dimension Tolerance: W, H, T)
≦
3.5
>3.5
0.6
0.5
±0.4
Suntan
M E T A L L I Z E D P O LY E S T E R F I L M C A P A C I T O R - M I N I B O X
N O N - I N D U C T I V E ,
P L A S T I C
C A S E
A N D
E P O X Y
R E S I N
50VDC
(
μ
F)
0.0010
0.0015
0.0022
0.0033
0.0047
0.0068
0.010
0.015
0.022
0.033
0.047
0.068
0.10
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
W
H
T
P
W
63VDC
H
T
P
W
100VDC
H
T
P
W
250VDC
H
T
P
W
400VDC
H
T
P
7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0
7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0
7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0
7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0
7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0
7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 7.5 3.5 5.0
7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 7.5 3.5 5.0
7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 9.5 4.5 5.0
7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 7.5 3.5 5.0 7.2 9.5 4.5 5.0
7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 7.5 3.5 5.0 7.2 10.0 5.0 5.0
7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 9.5 4.5 5.0 7.2 11.0 6.0 5.0
7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 9.5 4.5 5.0
7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 7.5 3.5 5.0 7.2 10.0 5.0 5.0
7.2 6.5 2.5 5.0 7.2 6.5 2.5 5.0 7.2 9.5 4.5 5.0 7.2 11.0 6.0 5.0
7.2 7.5 3.5 5.0 7.2 7.5 3.5 5.0 7.2 10.0 5.0 5.0 7.2 11.0 6.0 5.0
7.2 7.5 3.5 5.0 7.2 7.5 3.5 5.0 7.2 11.0 6.0 5.0
7.2 7.5 3.5 5.0 7.2 9.5 4.5 5.0 7.2 11.0 6.0 5.0
7.2 9.5 4.5 5.0 7.2 10.0 5.0 5.0
7.2 10.0 5.0 5.0 7.2 11.0 6.0 5.0
7.2 11.0 6.0 5.0 7.2 11.0 6.0 5.0
7.5 13.0 7.5 5.0
