SBR3045RF
Elektronische Bauelemente
VOLTAGE 45V
30
.0AMP Schottky Barrier Rectifiers
RoHS Compliant Product
A suffix of "-C" specifies halogen & lead-free
ITO-220
10
0.5
3.2
0.2
0.1
4.5
0.2
FEATURES
* Low forward voltage drop
* High current capability
* High reliability
* High surge current capability
* Epitaxial construction
0.2
2.8
0.3
2.7
3.7
0.2
* Case: Molded plastic
* Epoxy: UL 94V-0 rate flame retardant
* Lead: Lead solderable per MIL-STD-202,
method 208 guaranteed
* Polarity: As Marked
* Mounting position: Any
* Weight: 2.24 grams(Approximately)
2.54
0.2
0.7
2.54
0.2
0.2
13Min
MECHANICAL DATA
1.3
0.2
15
0.3
0.5
2.6
0.2
0.2
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating 25 C ambient temperature unless otherwise specified.
Single phase half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
TYPE NUMBER
Maximum Recurrent Peak Reverse Voltage
Working Peak Reverse Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
(Per Leg)
(Per Device)
Peak Forward Surge Current, 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
Maximum Instantaneous Forward Voltage (I
F
= 15 Amps,T
A
= 25 C, per leg)
Maximum Instantaneous Forward Voltage (I
F
= 15 Amps,T
A
= 100 C, per leg)
Maximum DC Reverse Current
Ta=25
o
C
at Rated DC Blocking Voltage (Note3)
Typical Junction Capacitance (Note1)
Typical Thermal Resistance
(Note2)
Voltage Rate Of Chance (Rated V
R
)
Operating Temperature Range
Storage Temperature Range
NOTES:
SYMBOL
V
RRM
V
RSM
V
DC
I
F
I
FSM
V
F
I
R
C
J
R
θ
JC
dv/dt
T
J
T
STG
SBR3045RF
45
45
45
15
30
180
0.57
0.52
0.5
12
2400
4.0
10000
-50
~
+150
-65
~
+175
UNITS
V
V
V
A
A
V
mA
o
Ta=100 C
o
pF
C/W
C
C
V/us
1. Measured at 1MHz and applied reverse voltage of 5.0V D.C.
2. Thermal Resistance Junction to Case.
3. Pulse Test : Pulse Width = 300us, Duty Cycle <= 2.0%.
http://www.SeCoSGmbH.com
Any changing of specification will not be informed individual
07-Oct-2010
Rev.
A
Page 1 of 2
SBR3045RF
Elektronische Bauelemente
VOLTAGE 45V
30
.0AMP Schottky Barrier Rectifiers
RATING AND CHARACTERISTIC CURVES
Typical Forward Current Derating Curve
50
Typical Forward Characteristic
Average Forward Current (A); per Leg
d
erage
21
18
15
12
9
6
3
Instantaneous Forward Current (A) ,Per Leg
20
5
100℃
1
75℃
25℃
50℃
Tc, Case Temperature ( )
Typical Junction Capacitance
4000
0.1
0.1
0.2
0.3
0.4
0.5
0.6
0.7
Junction Capacitance (pF)
3000
Forward Voltage (V)
2000
1000
Typical Reverse Characteristic
100
1
10
100
0
0.1
Revise Voltage (%)
100℃
Maximum Non- Repetitive Forward
Surge Current
200
10
Reverse Curren
t(mA)
75℃
Peak Forwad surge Current (A)
160
Tj=25℃
8.3mS Single half
Sine Wave
JEDEC Method
1
120
50℃
80
0.1
25℃
40
0
0
10
100
0.01
0
10
20
30
40
50
Number of Cycles at 60Hz
Reverse Voltage(V)
http://www.SeCoSGmbH.com
Any changing of specification will not be informed individua
l
07-Oct-2010 Rev. A
Page 2 of 2
