SFT5002/SFT5004
Series
10 AMP
NPN HIGH SPEED
POWER TRANSISTOR
150 VOLTS
Features:
BV
CEO
120V min.
Fast Switching
High Frequency
High Linear Gain, Low Saturation Voltage
Radiation Tolerant
200°C Operating Temperature
High Current, High Voltage Version of
2N5002 and 2N5004
TX, TXV, S-Level Screening Available -
Consult Factory.
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
B
P
D
T
J
& T
STG
R
0JC
DESIGNER’S DATA SHEET
Part Number / Ordering Information
1/
SFT5002
SFT5004 __ __ __
│ │ └
Screening
2/
__
= Not Screened
│ │
TX = TX Level
│ │
TXV = TXV Level
│ │
S = S Level
│ │
│ └
Lead Bend
3/
__
= Straight Leads
│
UB = Up Bend
│
DB = Down Bend
3/
└
Package
/59 = TO-59
M = TO-254
J = TO-257
Maximum Ratings
Collector – Base Voltage
Collector – Emitter Voltage
Emitter – Base Voltage
Continuous Collector Current
Base Current
Total Device Dissipation @ T
C
= 25ºC
Derate Above 25ºC
Operating & Storage Temperature
Maximum Thermal Resistance
(Junction to Case)
Available Part Numbers:
SFT5002/59
SFT5004/59
SFT5002J
SFT5002JUB
SFT5002JDB
SFT5004J
SFT5004JUB
SFT5004JDB
SFT5002M
SFT5002MUB
SFT5002MDB
SFT5004M
SFT5004MUB
SFT5004MDB
Value
150
120
6.0
10
2
50
0.33
-65 to +200
3.0
Units
Volts
Volts
Volts
Amps
Amps
Watts
W/ºC
ºC
ºC/W
TO-59 (/59)
TO-254 (M)
TO-257 (J)
PIN ASSIGNMENT
CODE
-
FUNCTION
Normal
PIN 1
Collector
PIN 2
Emitter
PIN 3
Base
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: TR0020E
DOC
Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SFT5002/SFT5004
Series
Symbol
(I
C
= 100mA)
(I
C
= 200µA)
(I
E
= 200µA)
(V
CE
= 40V)
(V
CB
= 60V, V
BE
= 2V, T
C
= 150°C)
(V
CE
= 60V)
(V
CE
= 100V)
(V
EB
= 5V)
(V
EB
= 6V)
SFT5002 - (I
C
= 50mA, V
CE
= 5V)
(I
C
= 2.5A, V
CE
= 5V)
(I
C
= 5.0 A, V
CE
= 5V)
SFT5004 - (I
C
= 10A, V
CE
= 5V)
(I
C
= 50mA, V
CE
= 5V)
(I
C
= 2.5A, V
CE
= 5V)
(I
C
= 5.0A, V
CE
= 5V)
(I
C
= 10A, V
CE
= 5V)
(I
C
= 2.5A, I
B
= 250mA)
(I
C
= 5.0A, I
B
= 500mA)
(I
C
= 2.5A, I
B
= 250mA)
(I
C
= 5.0 A, I
B
= 500mA)
SFT5002 - V
CE
= 5V, I
C
= 0.5A, f = 10MHz
SFT5004 - V
CE
= 5V, I
C
= 0.5A, f = 10MHz
Electrical Characteristics
4/
Collector – Emitter Blocking Voltage
Collector – Base Sustaining Voltage
Emitter – Base Sustaining Voltage
Collector Cutoff Current
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain *
Min
120
150
6
––
––
––
––
––
––
20
30
20
15
50
70
40
22
––
––
––
––
60
70
––
––
––
Max
––
––
––
50
500
1.0
1.0
1.0
1.0
Units
Volts
Volts
Volts
μA
μA
μA
mA
BV
CEO
BV
CBO
BV
EBO
I
CEO
I
CEV
I
CES
I
EBO
150
200
h
FE
Collector-Emitter Saturation Voltage *
Base-Emitter Saturation Voltage *
Current Gain – Bandwidth Product
Output Capacitance
On Time
Off Time
V
CE (SAT)
V
BE (SAT)
f
T
C
ob
t
(on)
0.75
1.5
1.45
2.2
––
––
250
500
1.3
Volts
Volts
MHz
pF
ns
µs
V
CB
= 10V, I
E
= 0, f = 1.0MHz
(V
CC
= 30 V, I
C
= 5.0 A, V
BE (off)
= 3.7 V, I
B1
= I
B2
= 500 mA,
R
L
= 6Ω)
t
(off)
NOTES:
*
1/
2/
3/
4/
Pulse Test: Pulse Width = 300µsec, Duty Cycle = 2%
For Ordering Information, Price, and Availability Contact Factory.
Screening per MIL-PRF-19500
For Package Outlines Contact Factory.
Unless Otherwise Specified, All Electrical Characteristics @25ºC.
PACKAGE OUTLINE
Part Number
SFT5002/59 and SFT5004/59
SFT5002J and SFT5004J
SFT5002M and SFT5004M
Document
60-0149-059
60-0149-504
60-0149-503
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: TR0020E
DOC
