Mul
ti-rate Gigabit Ethernet & Fibre Channel SFP
CWDM Transceivers with Digital Diagnostics
TRP1G1xxXIxG CWDM
Product Description
The TRP1G1xxXIxG SFP series of multi-rate fiber optic transceiv-
ers with integrated digital diagnostics monitoring functional-
ity provide a quick and reliable interface for Gigabit Ethernet
and 1.062GBd Fibre Channel applications. The transceivers are
designed to support data rates ranging from 1.25Gb/s down to
125Mb/s. Diagnostics monitoring functionality (alarm and warn-
ing features) is integrated into the design via an I
2
C serial inter-
face per the Multi-Source Agreement (MSA) SFF-8472, Rev. 9.4.
There are eight center wavelengths available: 1471nm, 1491nm,
1511nm, 1531nm, 1551nm, 1571nm, 1591nm and 1611nm. Three
optical link power budget options are offered, YX (22dB mini-
mum), ZX (24dB minimum) and VX (32dB minimum). They cor-
respond to transmission distances of 62km, 70km and 120km,
respectively (assuming a total connector/splice/CWDM mux and
demux loss of 4.5dB, allocated system penalty of 2dB and fiber
loss of 0.25dB/km). All modules satisfy Class I Laser Safety require-
ments in accordance with the U.S. FDA/CDRH and international
IEC-60825 standards.
The TRP1G1xxXIxG CWDM transceivers connect to standard 20-
pad SFP connectors for hot plug capability. This allows the system
designer to make configuration changes or maintenance by sim-
ply plugging in different types of transceivers without removing
the power supply from the host system.
The transceivers have colored bail-type latches, which offer an
easy and convenient way to release the modules. The latch is
compliant with the SFP MSA.
The transmitter and receiver DATA interfaces are AC coupled in-
ternally. LV-TTL Transmitter Disable control input and Loss of Sig-
nal output interfaces are also provided.
The transceivers operate from a single +3.3V power supply over
an operating temperature range of -40°C to +85°C (-40°C to 0°C is
ambient, and 0°C to +85°C is case). The housing is made of metal
for EMI immunity.
Absolute Maximum Ratings
Parameter
Storage Temperature
Operating Case Temperature
1
Supply Voltage
Input Voltage
1
Pb
Features
Industrial Operating Temperature Range
Lead Free Design & Fully RoHS Compliant
Eight (8) Wavelength CWDM Transceivers
Compatible with SFP MSA
Compatible with IEEE 802.3z Gigabit Ethernet
1000BASE-LX PMD Specifications
Compatible with 1.062GBd Fibre Channel 100-SM-LC-L
FC-PI Standards
Digital Diagnostics through Serial Interface
Internal Calibration for Digital Diagnostics
Minimum Optical Link Power Budgets of 22dB, 24dB
and 32dB to Support 62km, 70km and 120km
Eye Safe (Class I Laser Safety)
Duplex LC Optical Interface
Loss of Signal Output & TX Disable Input
Hot-pluggable
Single +3.3V Power Supply
Symbol
T
st
T
op
V
cc
V
in
Minimum
- 40
- 40
0
0
Maximum
+ 85
+ 85
+ 4.5
V
cc
Units
°C
°C
V
V
-40°C to 0°C is ambient, and 0°C to +85°C is case temperature. For case temperature, measure on top side of SFP module at the front center vent hole
of the cage.
S0137. Rev. 04 (web) 2013-02-15
TRP1G1xxXIxG CWDM
Transmitter Performance Characteristics
(Over Operating Case Temperature,
V
CC
= 3.13 to 3.47V)
Parameter
Operating Data Rate
YX
Optical Output Power
1
ZX
VX
1271nm
1291nm
1311nm
1331nm
1351nm
1371nm
1391nm
1411nm
Center Wavelength
1431nm
1451nm
1471nm
1491nm
1511nm
1531nm
1551nm
1571nm
1591nm
1611nm
Spectral Width (-20dB)
Side Mode Suppression Ratio
Extinction Ratio
Deterministic Jitter
Total Jitter
Optical Rise/Fall Time (20% to 80%)
Relative Intensity Noise
Dispersion Penalty
1
2
Symbol
B
P
o
Minimum
125
- 2.0
0
0
1264.5
1284.5
1304.5
1324.5
1344.5
1364.5
1384.5
1404.5
1424.5
1444.5
1464.5
1484.5
1504.5
1524.5
1544.5
1564.5
1584.5
1604.5
Typical
-
-
-
-
1271
1291
1311
1331
1351
1371
1391
1411
1431
1451
1471
1491
1511
1531
1551
1571
1591
1611
-
-
-
-
-
-
-
-
Maximum
1250
+ 3.0
+ 5.0
+ 5.0
1277.5
1297.5
1317.5
1337.5
1357.5
1377.5
1397.5
1417.5
1437.5
1457.5
1477.5
1497.5
1517.5
1537.5
1557.5
1577.5
1597.5
1617.5
1.0
-
-
80
227
0.32
- 120
1.5
Units
Mb/s
dBm
λ
C
nm
Δλ
20
SMSR
P
hi
/P
lo
DJ
TJ
t
r
,t
f
RIN
-
-
30
9
-
-
-
-
-
nm
dB
dB
ps
ps
ns
dB/Hz
dB
2
Transmitter Output Eye
Compliant with Eye Mask Defined in IEEE 802.3z Standard
Measured average power coupled into single mode fiber.
Specified at 1360ps/nm (YX), 1540ps/nm (ZX) and 2600ps/nm dispersion, which corresponds to the approximate worst-case dispersion for 62km,
70km and 120km G .652 fiber over the wavelength range of 1464.5 to 1617.5nm
Oplink Communications, Inc
2
S0137. Rev. 04 (web) 2013-02-15
TRP1G1xxXIxG CWDM
Receiver Performance Characteristics
(Over Operating Case Temperature,
V
CC
= 3.13 to 3.47V)
Parameter
Operating Data Rate
Minimum Input Optical
Power (10
-12
BER)
1
Maximum Input Optical
Power (10
-12
BER)
1
Increasing
Light Input
Decreasing
Light Input
YX, ZX
VX
YX, ZX
VX
YX, ZX
VX
YX, ZX
VX
Symbol
B
P
min
P
max
P
los+
P
los-
t_loss_off
t_loss_on
-
DJ
TJ
λ
ORL
-
Minimum
125
- 24.0
- 32.0
- 3.0
- 10.0
-
-
- 35.0
- 45.0
-
-
0.5
-
-
1260
12
-
Typical
-
-
- 35.0
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Maximum
1250
-
-
-
-
- 24.0
- 32.0
-
-
100
100
-
170
266
1620
-
1500
µs
dB
ps
ps
nm
dB
MHz
dBm
Units
Mb/s
dBm
dBm
LOS Thresholds
LOS Timing Delay
LOS Hysteresis
Deterministic Jitter
Total Jitter
Wavelength of Operation
Optical Return Loss
Increasing Light Input
Decreasing Light Input
Electrical 3dB Upper Cutoff Frequency
1
When measured with 2
7
-1 PRBS at 125Mb/s, 1062.5Mb/s and 1250Mb/s.
Oplink Communications, Inc
3
S0137. Rev. 04 (web) 2013-02-15
TRP1G1xxXIxG CWDM
Transmitter Electrical Interface
(Over Operating Case Temperature,
V
CC
= 3.13 to 3.47V)
Parameter
Input Voltage Swing (TD+ & TD-)
1
Input HIGH Voltage (TX Disable)
2
Input LOW Voltage (TX Disable)
2
Output HIGH Voltage (TX Fault)
3
Output LOW Voltage (TX Fault)
3
1
2
Symbol
V
PP-DIF
V
IH
V
IL
V
OH
V
OL
Minimum
0.50
2.0
0
2.0
0
Typical
-
-
-
-
-
Maximum
2.4
V
CC
0.8
V
CC
+ 0.3
0.8
Units
V
V
V
V
V
Differential peak-to-peak voltage.
There is an internal 4.7 to 10kΩ pull-up resistor to
VccT.
3
Open collector compatible, 4.7 to 10kΩ pull-up resistor to
Vcc
(Host Supply Voltage).
Receiver Electrical Interface
(Over Operating Case Temperature,
V
CC
= 3.13 to 3.47V)
Parameter
Output Voltage Swing (RD+ & RD-)
1
Output HIGH Voltage (LOS)
2
Output LOW Voltage (LOS)
2
1
2
Symbol
V
PP-DIF
V
OH
V
OL
Minimum
0.6
2.0
0
Typical
-
-
-
Maximum
2.0
V
CC
+ 0.3
0.5
Units
V
V
V
Differential peak-to-peak voltage across external 100Ω load.
Open collector compatible, 4.7 to 10kΩ pull-up resistor to
Vcc
(Host Supply Voltage).
Electrical Power Supply Characteristics
(Over Operating Case Temperature,
V
CC
= 3.13 to 3.47V)
Parameter
Supply Voltage
Supply Current
0°C to +85°C
- 40°C to 0°C
Symbol
V
CC
I
CC
Minimum
3.13
-
-
Typical
3.3
200
-
Maximum
3.47
300
550
Units
V
mA
Module Definition
MOD_DEF(0)
pin 6
TTL LOW
MOD_DEF(1)
pin 5
SCL
MOD_DEF(2)
pin 4
SDA
Interpretation by Host
Serial module definition protocol
Electrical Pad Layout
20
19
18
17
16
15
14
13
12
11
TX GND
TD- (TX DATA IN-)
TD+ (TX DATA IN+)
TX GND
VccTX
VccRX
RX GND
RD+ (RX DATA OUT+)
RD- (RX DATA OUT-)
RX GND
Host Board Connector Pad Layout
1
2
3
4
5
6
7
8
9
10
TX GND
TX Fault
TX Disable
MOD_DEF(2)
MOD_DEF(1)
MOD_DEF(0)
NO CONNECTION
LOS
RX GND
RX GND
1
2
3
Toward
Bezel
20
19
18
17
16
15
14
13
12
11
Toward
ASIC
4
5
6
7
8
9
10
Top of Board
Bottom of Board
(as viewed thru top of board)
Oplink Communications, Inc
4
S0137. Rev. 04 (web) 2013-02-15
TRP1G1xxXIxG CWDM
Example of SFP host board schematic
1 µH coil or ferrite bead
(<0.2 Ω series resistance)
Vcc
3.3V
Vcc
3.3V
+
10
0.1
0.1
16
15
R
2
8
4
5
R
R
R
R
TX Fault
LOS
MOD_DEF(2)
MOD_DEF(1)
MOD_DEF(0)
+
10
0.1
TX Disable
50Ω line
TX DATA IN+
TX DATA IN-
50Ω line
TRP1G1xxXI
3
MR CWDM
6
18
19
50Ω line
13
50Ω line
12
RX DATA OUT+
to 50Ω load
RX DATA OUT-
to 50 Ωload
R: 4.7 to 10kΩ
CAP Values in µF
1, 9,10,11,14,17,20
Application Notes
Electrical Interface:
All signal interfaces are compliant with
the SFP MSA specification. The high speed DATA interface
is differential AC-coupled internally with 0.1μF and can be
directly connected to a 3.3V SERDES IC. All low speed control
and sense output signals are open collector TTL compatible
and should be pulled up with a 4.7 - 10kΩ resistor on the host
board.
Loss of Signal (LOS):
The Loss of Signal circuit monitors the
level of the incoming optical signal and generates a logic HIGH
when an insufficient photocurrent is produced.
TX Fault:
The output indicates LOW when the transmitter
is operating normally, and HIGH with a laser fault including
laser end-of-life. TX Fault is an open collector/drain output
and should be pulled up with a 4.7 - 10kΩ resistor on the host
board. TX Fault is non-latching (automatically deasserts when
fault goes away).
TX Disable:
When the TX Disable pin is at logic HIGH, the
transmitter optical output is disabled (less than -35dBm,
-45dBm for F7G). Optical output is disabled from cold start
until operating wavelength is within specified range.
Serial Identification and Monitoring:
The module definition
of SFP is indicated by the three module definition pins,
MOD_DEF(0), MOD_DEF(1) and MOD_DEF(2). Upon power
up, MOD_DEF(1:2) appear as NC (no connection), and
MOD_DEF(0) is TTL LOW. When the host system detects this
condition, it activates the serial protocol (standard two-wire
I
2
C serial interface) and generates the serial clock signal (SCL).
The positive edge clocks data into the EEPROM segments of
the SFP that are not write protected, and the negative edge
clocks data from the SFP.
The serial data signal (SDA) is for serial data transfer. The
host uses SDA in conjunction with SCL to mark the start and
end of serial protocol activation. The supported monitoring
functions are temperature, voltage, bias current, transmitter
power, average receiver signal, all alarms and warnings, and
software monitoring of TX Fault/LOS. The device is internally
calibrated.
The data transfer protocol and the details of the mandatory
and vendor specific data structures are defined in the SFP MSA,
and SFF-8472, Rev. 9.4.
Power supply and grounding:
The power supply line should
be well-filtered. All 0.1μF power supply bypass capacitors
should be as close to the transceiver module as possible.
Laser Safety:
All transceivers are Class I Laser products per
FDA/CDRH and IEC-60825 standards. They must be operated
under specified operating conditions.
Oplink Communications, Inc.
DATE OF MANUFACTURE:
This product complies with
21 CFR 1040.10 and 1040.11
Meets Class I Laser Safety Requirements
Oplink Communications, Inc
5
S0137. Rev. 04 (web) 2013-02-15
京公网安备 11010802033920号
EEWORLD
