Resistors
Metal Element Current Sense Resistor
ULR Series
Robust metal strip able to withstand high
temperature and high current.
Low TCR and Inductance
Resistance Range from 0.1mΩ to 10mΩ
Includes anti-sulphur types
AEC-Q200
Higher wattage devices feature PCB clearance gap to
maximize thermal performance
All parts are Pb-free and comply with EU Directive 2011/65/EU amended by (EU) 2015/863 (RoHS3)
Electrical Data
Type
ULRG1 /
ULR1S
ULRG15 /
ULR15S
ULR2N
ULRG2 /
ULR2
ULRG25 /
ULR25
ULRG3 /
ULR3
3
ULR3N
1225
Size
1206
2010
1020
Coating
Power
Rating
@80°C (W)
1
1.5
2
2
2512
Green
Underside
2.5
Standard Resistance Value mΩ
1
0.2, 0.25, 0.3, 0.4, 0.5, 0.6
0.75, 1, 1.2, 2, 2.5, 3, 3.5, 4, 5, 5.5, 6, 7, 8, 9, 10
0.2, 0.25, 0.3, 0.4, 0.5
0.75, 1, 1.5, 2, 2.5, 3, 4, 5, 5.5, 6, 7, 8, 9, 10
1
1.5, 2, 2.5, 3
6.5, 7, 7.5, 8, 9, 10
3.5, 4, 4.5, 5, 5.5, 6
0.15, 0.25, 0.3, 0.4, 0.5, 0.75
1, 1.5, 2, 2.5, 3
0.1
0.2, 0.25, 0.3, 0.4
0.5
0.7, 0.75, 0.8, 0.9, 1.0
1.5, 2.0, 2.5, 3.0
0.5, 0.75, 1, 1.5, 2
2.5, 3, 3.5
4, 4.5, 5, 5.5, 10
6, 6.5, 7, 7.5
0.5, 0.75, 1, 1.5, 2
2.5, 3
150
50
500
350
300
250
100
50
150
100
75
50
150
1, 5
TCR
(ppm/°C)
200
50
150
50
300
170
50
Dielectric
Ambient
Tolerance (%) Withstanding
Temperature (°C)
Voltage (V)
N/A
-55 to +170
ULRB1 /
ULR1
ULRB2 /
ULR2
2512
Black
1
2
200
Notes: 1.
For higher resistance values please refer to LRMA series.
Performance Data
AEC-Q200 Table 7
ref.
3
4
6
7
8
14
15
16
18
21
22
Test
1
High Temp. Exposure *
Temperature Cycling
Moisture Resistance
Biased Humidity
Operational Life (Cyclic Load) *
Vibration
Resistance to Soldering Heat *
Thermal Shock *
Solderability
Board Flex
Terminal Strength
Short Term Overload *
Resistance to Sulphur-Bearing Gas
2
Method
MIL-STD-202 Method 108
JESD22 Method JA-104
MIL-STD-202 Method 106
MIL-STD-202 Method 103
MIL-STD-202 Method 108
MIL-STD-202 Method 204
MIL-STD-202 Method 210
MIL-STD-202 Method 107
J-STD-002
AEC-Q200-005
AEC-Q200-006
5 x Pr for 5s
EIA-977
∆R%
∆R%
∆R%
∆R%
∆R%
∆R%
∆R%
∆R%
∆R%
∆R%
∆R%
∆R%
Black
Max. (add R0005)
Green Underside
1206 & 2010
1020, 2512 & 1225
1
0.5
1
1
1
1
0.5
1
0.5
1
0.5
1
>95% coverage
0.5
1
0.25
1
0.5
1
1
N/A
Notes: 1.
Full AEC-Q200 qualification applies to 2512 size. The 1206 and 2010 sizes have received the tests marked *.
2.
Resistance to sulphur bearing gas has been tested for green underside construction only.
General Note
TT Electronics reserves the right to make changes in product specification without notice or liability.
All information is subject to TT Electronics’ own data and is considered accurate at time of going to print.
BI Technologies IRC Welwyn
www.ttelectronics.com/resistors
© TT Electronics plc
08.21
