980/1550nm WDM/Isolator
Hybrid Combination
WDIH1598 Series
Product Description
Oplink’s WDIH is a combination of a 980/1550nm filter and a 1550nm polarization
insensitive optical isolator. The WDIH is a low cost model with excellent perfor-
mance including low insertion loss, high isolation, high return loss, low polarization
dependent loss (PDL), and low polarization mode dispersion (PMD). This product
offers integrated solutions to EDFA applications by combining more functions into
a very compact package.
Oplink can provide customized designs to meet specialized feature applications.
Also, Oplink offers modular assemblies that integrate other components to form
a full function module or subsystem.
Performance Specificationns
WDIH1598 Series
Single Stage
Dual Stage
Unit
Operating Wavelength Range
Signal Channel
Pump Channel
C band : 1528 ~ 1564
L band : 1570 ~ 1605
965 ~ 995
< 1.2
< 0.6
> 30
> 12
> 21
< 0.25
< 0.4
< 0.10
< 0.25
≥ 50
≥ 55
≤ 500
0 to +70
-40 to +85
> 36
< 0.3
< 0.5
< 0.20
< 0.05
< 1.3
nm
Features
Insertion Loss
[1]
Signal Channel
Pump Channel
Signal Channel
Pump Channel
Signal Channel
Wide Operating Wavelength Range
dB
dB
dB
Low Insertion Loss
High Isolation
Ultra Low PDL & PMD
High Stability & Reliability
Epoxy-free Optical Path
Wavelength Isolation
(Over signa wavelength range and
0~70°C, all SOP)
Reverse Direction Insertion
TDL
WDL
Polarization Dependent Loss
Polarization Mode Dispersion (standard)
Return Loss
Directivity
Operting Power Handling
Operating Temperature
Storage Temperature
Fiber Type
Package Dimension
[3]
[1]
dB
dB
dB
dB
mW
°C
°C
Applications
Fiberoptic Amplifiers
CATV Fiberoptic Links
WDM Systems
Fiberoptic Instruments
Transmitters and Fiber Lasers
Laboratory R&D
Signal Port
COM/Pump Ports
Corning SMF-28
Corning HI1060
P1 : (Ø) 5.5 x (L) 34.0
P2 : (Ø) 5.5 x (L) 40.0
mm
The maximum IL is under all states of polarization and within the full operating temperature and wave-
length ranges specified.
[2]
All the parameters are excluding connectors.
[3]
The mechanical tolerance should be +/-0.2mm on all package dimensions unless otherwise custom speci-
fied.
S0079 - R02. 20111121
980/1550nm WDM/Isolator
Hybrid Combination
WDIH1598 Series
Mechanical Drawing / Package Dimensions (dimension in mm)
P1: SMF-28 250µm bare fiber
34.0 mm
1
COMMON
Ø5.5 mm
PASS
1550 nm
PASS
2
COMM
1550 nm
3
REFLECT
54.0mm
1480 nm
PUMP
P2: 900
µ
m loose tube
40.0 mm
COMM
1550 nm
PASS
2
PASS
1550 nm
46335 Landing Pkwy Fremont, CA 94538 Tel: (510) 933-7200 Fax: (510) 933-7300 Email: Sales@Oplink.com • www.oplink.com
1
COMMON
Ø5.5 mm
3
REFLECT
60.0mm
1480 nm
PUMP
Ordering Information
Oplink can provide a remarkable range of customized optical solutions. For detail, please contact Oplink’s OEM
design team or account manager for your requirements and ordering information (510) 933-7200.
WDIH
1
9
8
0
Wavelength
1550/980nm = 1598
1585/980nm = 1698
Configuration
Forward Type = F
Backward Type = B
Fiber Length
*
0.5 meter = H
1.0 Meter = 1
1.5 Meters = 5
2.0 Meters = 2
Connector Type
None = 1
FC/PC = 2
FC/SPC = 3
FC/APC = 4
SC/PC = 5
SC/SPC = 6
SC/APC = 7
ST = 8
LC = 9
MU = A
Stage
Single Stage = S
Dual Stage = D
Packaging & Fiber Jacket
P1 + 250μm bare fiber = 11
P2 + 900µm loose tube = 22
* The tolerance of fiber length is +/-0.1m. 1 meter is standard.
The lead-time for special fiber length will be longer.
S0079 - R02. 20111121
