DUP45V6P5
QUAD SURFACE MOUNT TVS ARRAY
Features
•
•
•
•
•
•
Quad TVS in Common Anode Configuration
Ultra-Small Surface Mount Package
Ideal For Transient Suppression and ESD Protection
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
•
•
•
•
•
Case: SOT953
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminal Finish: Matte Tin, Annealed Over Copper Leadframe.
Solderable per MIL-STD-202, Method 208
Weight: 0.002 grams (approximate)
NEW PRODUCT
ESD Capability
•
•
IEC 61000-4-2 Contact Method ±8kV
IEC 61000-4-2 Air Discharge Method ±15kV
K4
5
D4
D1
1
K1
2
A1/A2
A3/A4
D3
K3
4
D2
3
K2
Top View
Device Schematic
Ordering Information
(Note 4)
Part Number
DUP45V6P5-7
Notes:
Case
SOT953
Packaging
10,000/Tape & Reel
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com.
Marking Information
V2
V2 = Product type marking code
DUP45V6P5
Document number: DS36048 Rev. 3 - 2
1 of 5
www.diodes.com
February 2013
© Diodes Incorporated
DUP45V6P5
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Forward Voltage @ I
F
= 10mA
Symbol
V
F
Value
0.9
Unit
V
NEW PRODUCT
Thermal Characteristics
Characteristic
Power Dissipation (Notes 5)
Peak Power Dissipation, 8x20µS Waveform (Note 6)
Thermal Resistance, Junction-to-Ambient (Note 5)
Operating and Storage Temperature Range
Symbol
P
D
P
pk
R
θ
JA
T
J,
T
STG
Value
300
20
417
-55 to +150
Unit
mW
W
°C/W
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Type
Number
DUP45V6P5
Notes:
Marking
Code
V2
Breakdown Voltage
(Note 7)
V
BR
@ I
T
= 1mA
Min (V) Nom (V) Max (V)
5.3
5.6
5.9
Leakage Current
(Note 7)
I
RM
@ V
RM
(V)
Max(μA)
1.0
3.0
Max. Clamping
Voltage
(Note 6)
V
C
@ I
PP
V
C
(V) I
PP
(A)
10.5
1.0
Capacitance
@0V Bias(pF)
(Note 8)
C
T
Typ
Max
13
17
Capacitance
@3V Bias(pF)
(Note 8)
C
T
Typ
Max
7.0
11.5
5. Device mounted on FR-4 PCB, 1 inch x 0.85 inch x 0.062 inch; pad layout as shown on Diodes Inc. Suggested Pad Layout Document AP02001,
which can be found on our website at http://www.diodes.com.
6. Non-repetitive current pulse per Figure 3 and derate above T
A
= +25°C per Figure 3.
7. Short duration pulse test used to minimize self-heating effect.
8. Per element, f = 1MHZ, T
A
= +25°C
300
Note 5
100
PEAK PULSE DERATING IN % OF
PEAK POWER OR CURRENT
P
D
, POWER DISSIPATION (mW)
250
75
200
150
50
100
25
50
0
0
25
50
75
100
125
150
T
A
, AMBIENT TEMPERATURE (
°
C)
Figure 1 Power Derating Curve
175
0
0
25
50
75
100 125 150 175
T
A
, AMBIENT TEMPERATURE (°C)
Figure 2 Pulse Derating Curve
200
DUP45V6P5
Document number: DS36048 Rev. 3 - 2
2 of 5
www.diodes.com
February 2013
© Diodes Incorporated
DUP45V6P5
1000
100
I
F
, INSTANTANEOUS FORWARD CURRENT (mA)
I
PP
, PEAK PULSE CURRENT (%I
PP
)
100
T
A
= 85°C
10
T
A
= 125°C
T
A
= 25°C
NEW PRODUCT
50
1
T
A
= 150°C
0.1
T
A
= -55°C
0
0
20
40
60
t, TIME (µs)
Figure 3 Pulse Waveform
I
R
, INSTANTANEOUS REVERSE CURRENT(nA)
0.01
300
500
700
900
1100
1300
V
F
, INSTANTANEOUS FORWARD VOLTAGE (mV)
Figure 4 Typical Forward Characteristics
20
100
f = 1MHz
18
C
T
, TOTAL CAPACITANCE (pF)
16
14
12
10
8
6
T
A
= 25°C
10
1
0
1
2
3
4
5
V
R
, INSTANTANEOUS REVERSE VOLTAGE(V)
Figure 5 Typical Reverse Characteristics
4
0
2
3
4
V
R
, REVERSE VOLTAGE (V)
Figure 6 Typical Total Capacitance
vs. Reverse Voltage (Per Element)
1
5
DUP45V6P5
Document number: DS36048 Rev. 3 - 2
3 of 5
www.diodes.com
February 2013
© Diodes Incorporated
DUP45V6P5
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
D
e1
L
NEW PRODUCT
E1
E
e
b (5 places)
c
A
A1
SOT953
Dim Min
Max
Typ
A
0.40 0.50 0.45
A1
0
0.05
−
b
0.10 0.20 0.15
c
0.12 0.18 0.15
D
0.95 1.05 1.00
E
0.95 1.05 1.00
E1
0.75 0.85 0.80
e
0.35
−
−
e1
0.70
−
−
L
0.05 0.15 0.10
All Dimensions in mm
Suggested Pad Layout
Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.
C
C
Y1
Y (5X)
Dimensions Value (in mm)
C
0.350
X
0.200
Y
0.200
Y1
1.100
X (5X)
DUP45V6P5
Document number: DS36048 Rev. 3 - 2
4 of 5
www.diodes.com
February 2013
© Diodes Incorporated
DUP45V6P5
