Connectors (Inlets/Outlets)
https://www.schurter.com /PG07
4710
IEC Appliance Outlet J, Snap-in Mounting, Front Side, IDC Terminal
Arrangement "cross"
(wires cross to pin axis)
Arrangement "along"
(wires along to pin axis)
Arrangement "cross", view from rear side
(wires cross to pin axis)
Type J
See below:
70° C
Approvals and Compliances
Description
Characteristics
-
-
-
-
- Panel mount :
Snap-in version , from front side
- Connector , Pin temperature 70 °C , Protection class I
- Wire gauge 10AWG/6.0mm², 12AWG/4.0mm², 2.5mm²
- IDC terminals acc. to IEC 60998-2-3 for solid wires
Protection cover can be used as wire press
Live contact available as IDC, solder or quick connect terminal
ready to use with V-Lock cordsets
Suitable for use in equipment according to IEC/UL 60950
Unique Selling Proposition
-
-
-
-
Other versions on request
- Other panel thickness
Reduces labor costs
Allows wiring of multiple terminals at once
Cross and along orientation
V-Lock cord retaining standard
References
Weblinks
Alternative: version for 10 A (15 A)
4710-5; 6610
pdf datasheet, html-datasheet, General Product Information, Distributor-
Stock-Check, Accessories, Detailed request for product, Microsite,
Video
The integration of light pipes in the appliance outlet provides status indication in smart PDUs. See PDU Landing Page for more information.
Power Distribution Units
Technical Data
Ratings IEC
Ratings UL/CSA
Dielectric Strength
16 A / 250 VAC; 50 Hz
20 A / 250 VAC; 60 Hz
> 2.5 kVAC between L-N
> 1.5 kVAC between L/N-PE
(1 min/50 Hz)
-25 °C to 70 °C
Suitable for appliances with protection
class I acc. to IEC 61140
IDC terminals
1/1.2/1.5/2/2.5/3 mm
Thermoplastic, black, UL 94V-0
appliance inlet/-outlet
Type J acc. to IEC 60320-3
UL 60320-1, CSA C22.2 no. 60320-1 ,
Protection Class I
Allowable Operation Tempe-
rature
Insulation cover
Terminal
Panel Thickness S
Material: Housing
Approvals and Compliances
Detailed information on product approvals, code requirements, usage instructions and detailed test conditions can be looked up in
Details about
Approvals
Approvals
The approval mark is used by the testing authorities to certify compliance with the safety requirements placed on electronic products.
Approval Reference Type: 4710
Approval Logo
Certificates
VDE Approvals
UL Approvals
CQC Approvals
Certification Body
VDE
UL
CQC
Description
Certificate Number: 40042639
UL File Number: E103791
CCC Certificate Number: 2014010204668919
Product standards
Product standards that are referenced
Connectors
1
4710
Organization
Design
Designed according to
Designed according to
Designed according to
Designed according to
Standard
IEC 60320-1
IEC 60320-3
UL 60320-1
CSA C22.2 no. 60320-1
Description
Connectors (Inlets/Outlets)
https://www.schurter.com /PG07
Appliance couplers for household and similar general purposes
Appliance couplers for household and similar general purposes
Standard for Attachment Plugs and Receptacles
General Use Receptacles, Attachment Plugs, and Similar Wiring Devices
Application standards
Application standards where the product can be used
Organization
Design
Designed for applications acc.
Standard
IEC/UL 60950
Description
IEC 60950-1 includes the basic requirements for the safety of information
technology equipment.
Compliances
The product complies with following Guide Lines
Identification
Details
CE declaration of conformity
Initiator
SCHURTER AG
Description
The CE marking declares that the product complies with the applicable
requirements laid down in the harmonisation of Community legislation on
its affixing in accordance with EU Regulation 765/2008.
EU Directive RoHS 2011/65/EU
The law SJ / T 11363-2006 (China RoHS) has been in force since 1 March
2007. It is similar to the EU directive RoHS.
SCHURTER strives to offer our customers halogen free products.
On 1 June 2007, Regulation (EC) No 1907/2006 on the Registration,
Evaluation, Authorization and Restriction of Chemicals 1 (abbreviated as
"REACH") entered into force.
V-Lock system are based on a matching plug-dose combination. The
connector is equipped with a notch intended for use with the latching
cordset. The cord latching system prevents against accidental removal of
the cordset.
RoHS
China RoHS
Halogen Free
REACH
SCHURTER AG
SCHURTER AG
SCHURTER AG
SCHURTER AG
MicrositeV-Lock
SCHURTER AG
Dimensions [mm]
Version "cross" (wires cross to pin axis)
L/N/PE: IDC terminals
37
R
5
1.
34.7
3
37.6
+0.2
0
42
S
±0.1
2
Connectors
m
ax
.R
5
29.5
+0.2
0
34
29
Connectors (Inlets/Outlets)
https://www.schurter.com /PG07
4710
Version "along" (wires along to pin axis)
L/N/PE: IDC terminals
37
R
1.
34.7
3
37.6
+0.2
0
42
S
±0.1
Version "cross" (wires cross to pin axis)
N/PE: IDC terminals, L: quick connect or solder terminal
34.7
5
m
ax
.
R
5
3
37.6
+0.2
0
42
37
E: Quick connect terminal 6.3x0.8: 46.7 mm
E: Solder terminal:
47.2 mm
R
5.
5
29
Connectors
m
E
ax
.R
5
29.5
+0.2
0
3
34
29.5
+0.2
0
34
29
5
R
1.
4710
Connectors (Inlets/Outlets)
https://www.schurter.com /PG07
Version "along" (wires along to pin axis)
N/PE: IDC terminals, L: quick connect or solder terminal
34.7
3
37.6
+0.2
0
42
37
E: Quick connect terminal 6.3x0.8: 46.7 mm
E: Solder terminal:
47.2 mm
Assembly Instructions
Wire press version "cross"
2.8
17.9
6.6 6.6
0.4
min. 4
6.15
±0.1
R
5.
5
29
Wire press version "along"
26
0.5
min. 4
m
E
ax
.R
5
3.2
±0.1
2.8
±0.1
ø 7.5
ø 4.5
2
ø 7.5
26
6.15
±0.1
2.8
ø 4.5
17.9
21.3
37
6
±0.10
(15)
6
±0.1
(15)
3
15
4.3
+0.10
0
min. 8.2
min. 8.2
21.3
2.85
+0.1
0
15
7.5
4.3
+0.10
0
15
All Variants
Alignment 1)
along
along
along
along
along
along
along
along
along
along
cross
Conductor cross section
2.5 mm²
2.5 mm²
2.5 mm²
4.0 mm² / 12 AWG
4.0 mm² / 12 AWG
4.0 mm² / 12 AWG
4.0 mm² / 12 AWG
6.0 mm² / 10 AWG
6.0 mm² / 10 AWG
6.0 mm² / 10 AWG
2.5 mm²
Panel Thickness
s [mm]
1.5
1.5
1.5
1
1.5
1.5
1.5
1.5
1.5
1.5
1.5
Terminal type live contact
IDC terminal
Quick connect terminal 6.3 x 0.8
Solder terminal
IDC terminal
IDC terminal
Quick connect terminal 6.3 x 0.8
Solder terminal
IDC terminal
Quick connect terminal 6.3 x 0.8
Solder terminal
IDC terminal
Order Number
4710.6014
4710.6254
4710.6154
4710.4012
4710.4014
4710.4254
4710.4154
4710.2014
4710.2254
4710.2154
4710.5014
█
█
█
4
Connectors
2.85
+0.10
0
10.2
±0.1
2
29.5
+0.2
0
34
R
5
1.
Connectors (Inlets/Outlets)
https://www.schurter.com /PG07
4710
Panel Thickness
s [mm]
1.5
1.5
1.5
2
1.5
1.5
1.5
1.5
1.5
Terminal type live contact
Quick connect terminal 6.3 x 0.8
Solder terminal
IDC terminal
IDC terminal
Quick connect terminal 6.3 x 0.8
Solder terminal
IDC terminal
Quick connect terminal 6.3 x 0.8
solder terminal
Order Number
4710.5254
4710.5154
4710.3014
4710.3015
4710.3254
4710.3154
4710.1014
4710.1254
4710.1154
█
█
█
█
Alignment 1)
cross
cross
cross
cross
cross
cross
cross
cross
cross
Conductor cross section
2.5 mm²
2.5 mm²
4.0 mm² / 12 AWG
4.0 mm² / 12 AWG
4.0 mm² / 12 AWG
4.0 mm² / 12 AWG
6.0 mm² / 10 AWG
6.0 mm² / 10 AWG
6.0 mm² / 10 AWG
█
Most Popular.
Availability for all products can be searched real-time:https://www.schurter.com/en/Stock-Check/Stock-Check-
SCHURTER
1) The alignment describes whether the wires are along or across to the connector pin axis.
Packaging unit
Mating Inlets/Plugs
50 Pcs
Category / Description
Plug Overview complete
IEC Plug I, Cord Connector (Rewireable), Straight
IEC Plug I, Cord Connector (Rewireable), Angled
Plug further types to 4710
4796
4789
Mating Inlets/Plugs shuttered
Interconnection Cord Overview complete
VAC19KS, Interconnection, V-Lock cord retaining, 2.0 m, Connector IEC C19, H05VV-F3G1.5 / SJT 3x14 AWG, black
VAC19KS, Interconnection, V-Lock cord retaining, 3.0 m, Connector IEC C19, H05VV-F3G1.5 / SJT 3x14 AWG, black
VAC19KS, Interconnection, V-Lock cord retaining, 1.0 m, Connector IEC C19, H05VV-F3G1.5, black
VAC19KS, Interconnection, V-Lock cord retaining, 1.0 m, Connector IEC C19, H05VV-F3G1.5 / SJT 3x14 AWG, black
VAC19KS, Interconnection, V-Lock cord retaining, 2.0 m, Connector IEC C19, H05VV-F3G1.5, black
Interconnection Cord further types to 4710
3-100-362
3-100-363
6051.2147
6051.2197
6051.2047
