0805CP Series – SMD WIRE WOUND CERAMIC CHIP INDUCTORS
Rev. A
A. Electrical Specifications:
L Test
P/N
Freq.
Tol.
(MHz)
2.20
250
K, J
0805CP-2N2_
2.70
250
K, J
0805CP-2N7_
2.80
250
K, J
0805CP-2N8_
2.90
250
K, J
0805CP-2N9_
3.00
250
K, J
0805CP-3N0_
3.30
250
K, J
0805CP-3N3_
5.60
250
K, J
0805CP-5N6_
6.80
250
K, J
0805CP-6N8_
7.50
250
K, J
0805CP-7N5_
8.20
250
K, J, G
0805CP-8N2_
10.0
250
K, J, G
0805CP-10N_
11.0
700
K, J, G
0805CP-11N_
12.0
250
K, J, G
0805CP-12N_
15.0
250
K, J, G
0805CP-15N_
18.0
250
K, J, G
0805CP-18N_
22.0
250
K, J, G
0805CP-22N_
24.0
250
K, J, G
0805CP-24N_
27.0
250
K, J, G
0805CP-27N_
33.0
250
K, J, G
0805CP-33N_
36.0
250
K, J, G
0805CP-36N_
37.0
350
K, J, G
0805CP-37N_
38.0
350
K, J, G
0805CP-38N_
39.0
250
K, J, G
0805CP-39N_
43.0
200
K, J, G
0805CP-43N_
47.0
200
K, J, G
0805CP-47N_
56.0
200
K, J, G
0805CP-56N_
68.0
200
K, J, G
0805CP-68N_
82.0
150
K, J, G
0805CP-82N_
91.0
150
K, J, G
0805CP-91N_
100
150
K, J, G
0805CP-R10_
110
150
K, J, G
0805CP-R11_
120
150
K, J, G
0805CP-R12_
150
100
K, J, G
0805CP-R15_
180
100
K, J, G
0805CP-R18_
200
100
K, J, G
0805CP-R20_
220
100
K, J, G
0805CP-R22_
240
100
K, J, G
0805CP-R24_
250
100
K, J, G
0805CP-R25_
270
100
K, J, G
0805CP-R27_
300
100
K, J, G
0805CP-R30_
330
100
K, J, G
0805CP-R33_
360
100
K, J, G
0805CP-R36_
390
150
K, J, G
0805CP-R39_
430
100
K, J, G
0805CP-R43_
470
50
K, J
0805CP-R47_
560
25
K, J
0805CP-R56_
620
25
K, J
0805CP-R62_
680
25
K, J
0805CP-R68_
820
25
K, J
0805CP-R82_
0805CP has first inductance color code only.
L
(nH)
Q Min.
35
35
80
50
65
50
65
50
50
50
60
45
50
50
50
55
50
55
60
55
40
40
60
60
60
60
60
65
65
65
50
50
50
50
50
50
44
45
48
25
48
35
48
25
33
23
23
23
23
Q Test
Freq.
(MHz)
1500
1000
1000
1000
1500
1500
1000
1000
1000
1000
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
500
250
250
250
250
250
250
250
250
250
250
250
250
100
100
50
50
50
50
SRF Min.
(GHz)
3.00
6.00
7.90
4.70
7.90
7.90
5.50
5.50
4.50
4.70
4.20
3.00
4.00
3.40
3.30
2.60
2.00
2.50
2.05
1.70
1.80
1.80
2.00
1.65
1.65
1.55
1.45
1.30
1.20
1.20
1.00
1.10
0.920
0.870
0.860
0.850
0.690
0.660
0.650
0.450
0.600
0.400
0.560
0.400
0.375
0.340
0.220
0.188
0.215
DCR
Max.
Ω
0.08
0.03
0.06
0.05
0.06
0.08
0.08
0.11
0.14
0.12
0.10
0.15
0.15
0.17
0.20
0.22
0.22
0.25
0.27
0.27
0.27
0.27
0.29
0.34
0.31
0.34
0.38
0.42
0.48
0.46
0.48
0.51
0.56
0.64
0.68
0.70
1.00
1.20
1.00
1.40
1.40
0.90
1.50
1.70
1.76
1.90
2.20
2.20
2.35
I rms.
Max.(mA)
600
600
800
600
800
600
600
600
600
600
600
600
600
600
600
500
500
500
500
500
500
500
500
500
500
500
500
400
400
400
400
400
400
400
400
400
350
350
350
300
310
300
290
190
250
230
210
190
180
Color
code
White
Brown
Gray
Blue
White
Black
Violet
Brown
Green
Red
Red
Orange
Orange
Yellow
Green
Blue
Gray
Violet
Gray
Yellow
Green
Blue
White
Yellow
Black
Brown
Red
Orange
Black
Yellow
Brown
Green
Blue
Violet
Red
Gray
Red
Yellow
White
Gray
Black
Orange
Brown
White
Violet
Orange
Yellow
Green
Brown
Frontier Electronics Corp.
®
http://www.frontierusa.com
Page
1
of
3
667 E. Cochran St., Simi Valley, CA 93065
Phone: 1-805-522-9998, Fax: 1-805-522-9989
0805CP Series – SMD WIRE WOUND CERAMIC CHIP INDUCTORS
Rev. A
B. Dimensions: mm (Inch)
Series
0805CP
Tol.
a
2.29(0.090)
Max.
b
c
d
e
f
g
h
1.73 (0.068) 1.52 (0.060) 0.51(0.020) 1.02(0.040) 0.76 (0.030) 1.02 (0.040) 1.78 (0.070)
Max.
Max.
Typ.
Typ.
Typ.
Typ.
Typ.
C. General Information:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
P/N: 0805CP-xxx_, “0805CP” = Size Type, “xxx” = Inductance, “_” = Tolerance.
Tolerance “_” : K: ± 10%, J: ± 5%, G: ± 2%.
Small and lightweight surface mounting type.
High Q at high frequency & High self-resonance frequency.
For 15ºC Temperature Rise at 25ºC ambient.
Inductance & Q measured with HP4291B Impedance Analyzer.
SRF measured using the HP8720D or HP8753E Network Analyzer.
DCR measured using the 16502 milliohm meter.
Operating temperature: -40°C to +125ºC.
This series has no color code due to the size is small.
Inductance and Current Range: From 2.2 nH (600mA) to 820 nH (180 mA)
SRF: From 188 MHz to 7900 MHz
MSL: Level 1.
D. Applications:
1.
2.
3.
4.
5.
6.
Game Consoles
Set Top Boxes
Cables Modems
Computers
Mobile Communication Devices (Cell Phones, Radios, etc.)
RF Filters
E. Characteristics Curve:
