Product availability: Stock - Normally stocked in distribution facility
TeSys D contactor - 3P(3 NO) - AC-3 - <= 440 V
32 A - 230 V AC coil
1
The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein.
This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications.
It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof.
Neither Schneider Electric Industries SAS nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein. *Prices are indicative
Price*: 172.00 USD
Main
Commercial Status
Range of product
Product or component
type
Device short name
Contactor application
Utilisation category
Poles description
Pole contact
composition
[Ue] rated operational
voltage
[Ie] rated operational
current
Commercialised
TeSys D
Contactor
LC1D
Motor control
Resistive load
AC-1
AC-3
3P
3 NO
<= 300 V DC for power circuit
<= 690 V AC 25...400 Hz for power circuit
50 A (<= 140 °F (60 °C)) at <= 440 V AC AC-1 for power
circuit
32 A (<= 140 °F (60 °C)) at <= 440 V AC AC-3 for power
circuit
18.5 kW at 660...690 V AC 50/60 Hz
18.5 kW at 500 V AC 50/60 Hz
15 kW at 415...440 V AC 50/60 Hz
15 kW at 380...400 V AC 50/60 Hz
7.5 kW at 220...230 V AC 50/60 Hz
20 hp at 460/480 V AC 50/60 Hz for 3 phases motors
7.5 hp at 200/208 V AC 50/60 Hz for 3 phases motors
2 hp at 115 V AC 50/60 Hz for 1 phase motors
30 hp at 575/600 V AC 50/60 Hz for 3 phases motors
10 hp at 230/240 V AC 50/60 Hz for 3 phases motors
5 hp at 230/240 V AC 50/60 Hz for 1 phase motors
AC 50/60 Hz
230 V AC 50/60 Hz
1 NO + 1 NC
6 kV conforming to IEC 60947
III
50 A at <= 140 °F (60 °C) for power circuit
10 A at <= 140 °F (60 °C) for signalling circuit
550 A at 440 V for power circuit conforming to IEC 60947
250 A DC for signalling circuit conforming to IEC
60947-5-1
140 A AC for signalling circuit conforming to IEC
60947-5-1
550 A at 440 V for power circuit conforming to IEC 60947
430 A <= 104 °F (40 °C) 1 s power circuit
260 A <= 104 °F (40 °C) 10 s power circuit
138 A <= 104 °F (40 °C) 1 min power circuit
60 A <= 104 °F (40 °C) 10 min power circuit
140 A 100 ms signalling circuit
120 A 500 ms signalling circuit
100 A 1 s signalling circuit
63 A gG at <= 690 V coordination type 2 for power circuit
63 A gG at <= 690 V coordination type 1 for power circuit
10 A gG for signalling circuit conforming to IEC
60947-5-1
2 mOhm at 50 Hz - Ith 50 A for power circuit
Motor power kW
Motor power hp
Control circuit type
Control circuit voltage
Auxiliary contact
composition
[Uimp] rated impulse
withstand voltage
Overvoltage category
[Ith] conventional free
air thermal current
Irms rated making
capacity
Rated breaking
capacity
[Icw] rated short-time
withstand current
Associated fuse rating
Average impedance
2
[Ui] rated insulation
voltage
600 V for signalling circuit certifications UL
600 V for signalling circuit certifications CSA
690 V for signalling circuit conforming to IEC 60947-1
600 V for power circuit certifications UL
600 V for power circuit certifications CSA
690 V for power circuit conforming to IEC 60947-4-1
1.4 Mcycles 50 A AC-1 at Ue <= 440 V
1.65 Mcycles 32 A AC-3 at Ue <= 440 V
5 W AC-1
AC-3
With
Plate
Rail
EN 60947-4-1
EN 60947-5-1
IEC 60947-4-1
IEC 60947-5-1
UL 508
CSA C22.2 No 14
BV
CCC
CSA
DNV
GL
GOST
RINA
UL
LROS
Power circuit: screw clamp terminals 2 cable(s) 0...0.02
in² (2.5...10 mm²) - cable stiffness: solid - without cable
end
Power circuit: screw clamp terminals 1 cable(s) 0...0.02
in² (1.5...10 mm²) - cable stiffness: solid - without cable
end
Power circuit: screw clamp terminals 2 cable(s) 0...0.01
in² (1.5...6 mm²) - cable stiffness: flexible - with cable end
Power circuit: screw clamp terminals 1 cable(s) 0...0.02
in² (1...10 mm²) - cable stiffness: flexible - with cable end
Power circuit: screw clamp terminals 2 cable(s) 0...0.02
in² (2.5...10 mm²) - cable stiffness: flexible - without cable
end
Power circuit: screw clamp terminals 1 cable(s) 0...0.02
in² (2.5...10 mm²) - cable stiffness: flexible - without cable
end
Control circuit: screw clamp terminals 2 cable(s) 0...0.01
in² (1...4 mm²) - cable stiffness: solid - without cable end
Control circuit: screw clamp terminals 1 cable(s) 0...0.01
in² (1...4 mm²) - cable stiffness: solid - without cable end
Control circuit: screw clamp terminals 2 cable(s) 0...0 in²
(1...2.5 mm²) - cable stiffness: flexible - with cable end
Control circuit: screw clamp terminals 1 cable(s) 0...0.01
in² (1...4 mm²) - cable stiffness: flexible - with cable end
Control circuit: screw clamp terminals 2 cable(s) 0...0.01
in² (1...4 mm²) - cable stiffness: flexible - without cable
end
Control circuit: screw clamp terminals 1 cable(s) 0...0.01
in² (1...4 mm²) - cable stiffness: flexible - without cable
end
Power circuit: 22.12 lbf.in (2.5 N.m) - on screw clamp
terminals - with screwdriver Philips No 2
Power circuit: 22.12 lbf.in (2.5 N.m) - on screw clamp
terminals - with screwdriver flat Ø 6 mm
Control circuit: 15.04 lbf.in (1.7 N.m) - on screw clamp
terminals - with screwdriver Philips No 2
Control circuit: 15.04 lbf.in (1.7 N.m) - on screw clamp
terminals - with screwdriver flat Ø 6 mm
12...22 ms closing
4...19 ms opening
Electrical durability
Power dissipation per
pole
Protective cover
Mounting support
Standards
Product certifications
Connections - terminals
Tightening torque
Operating time
3
Safety reliability level
B10d = 20000000 cycles contactor with mechanical load
conforming to EN/ISO 13849-1
B10d = 1369863 cycles contactor with nominal load
conforming to EN/ISO 13849-1
15 Mcycles
3600 cyc/h at <= 140 °F (60 °C)
Mechanical durability
Operating rate
Complementary
Coil technology
Control circuit voltage limits
Without built-in suppressor module
0.85...1.1 Uc at 140 °F (60 °C) operational 60 Hz
0.8...1.1 Uc at 140 °F (60 °C) operational 50 Hz
0.3...0.6 Uc at 140 °F (60 °C) drop-out 50/60 Hz
70 VA at 20 °C (cos ? 0.75) 50 Hz
70 VA at 20 °C (cos ? 0.75) 60 Hz
7 VA at 20 °C (cos ? 0.3) 50 Hz
7.5 VA at 20 °C (cos ? 0.3) 60 Hz
2...3 W at 50/60 Hz
Type mirror contact (1 NC) conforming to IEC 60947-4-1
Type mechanically linked (1 NO + 1 NC) conforming to IEC 60947-5-1
25...400 Hz
5 mA for signalling circuit
17 V for signalling circuit
1.5 ms on energisation (between NC and NO contact)
1.5 ms on de-energisation (between NC and NO contact)
> 10 MOhm for signalling circuit
Inrush power in VA
Hold-in power consumption in VA
Heat dissipation
Auxiliary contacts type
Signalling circuit frequency
Minimum switching current
Minimum switching voltage
Non-overlap time
Insulation resistance
Environment
IP degree of protection
Protective treatment
Pollution degree
Ambient air temperature for operation
Ambient air temperature for storage
Permissible ambient air temperature around the
device
Operating altitude
Fire resistance
Flame retardance
Mechanical robustness
IP2x front face conforming to IEC 60529
TH conforming to IEC 60068-2-30
3
23...140 °F (-5...60 °C)
-76...176 °F (-60...80 °C)
-40...158 °F (-40...70 °C) at Uc
9842.52 ft (3000 m) without derating in temperature
