IDTF1200 Overview

CAPACITOR, CERAMIC, MULTILAYER, 10 V, X5R, 0.1 uF, SURFACE MOUNT, 0402

IDTF1200 Parametric

Parameter Name	Attribute value
Maximum operating temperature	85 Cel
Minimum operating temperature	-55 Cel
negative deviation	10 %
positive deviation	10 %
Rated DC voltage urdc	10 V
Processing package description	Chip, ROHS COMPLIANT
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
terminal coating	PURE Tin
Installation features	surface mount
Manufacturer Series	GRM15
size code	0402
capacitance	0.1000 uF
packaging shape	Rectangular PACKAGE
Capacitor type	ceramics
Terminal shape	WRAPAROUND
Temperature Coefficient	15%
Temperature characteristic code	×5R
multi-layer	Yes

Preview

Download Datasheet

View All

DATASHEET

Intermediate Frequency Digital Variable Gain Amplifier

IDTF1200

ENERAL

ESCRIPTION

The IDTF1200 is a Digitally Controlled Intermediate

Frequency Differential Variable Gain Amplifier for

BaseStation and other commercial applications with a

low IF frequency. The device offers extremely low

Noise Figure over the entire gain control range. The

device is packaged in compact 5x5 Thin QFNs with 200

ohm differential input and output impedances for ease

of integration into the receiver lineup. Versions

covering IF frequencies up to 300 MHz with low

distortion are available.

EATURES



Ideal for high SNR systems

22 dB typ Maximum Gain

23 dB gain control range

7 bit parallel control

0.25 dB Gain Steps

Excellent

Noise Figure < 3.0 dB

5mm x 5mm 28 pin package

200

Ω Differential Input

200

Differential Output

NF degrades < 2dB @ 12dB reduced gain

50 MHz – 160 MHz frequency range

Ultra-Linear:

IP3

+48 dBm typical

External current setting resistor

Fast Gain Step Settling < 20 nsec

OMPETITIVE

DVANTAGE

The F1200 acts to enhance system SNR when VGA gain

is reduced. The F1200 noise figure (NF) degrades only

slightly (NF slope ~ -0.16

) over a 13 dB control

range while holding the Output IP3 approximately

constant. The resultant improvement in noise can

enhance the system SNR up to 2 decibels at low gain

settings relative to a standard VGA.

The device has excellent DNL and INL simplifying digital

compensation. The device also offers the extremely low

Harmonic, IM2, and IM3 distortion necessary to drive an

ADC directly in an IF sub-sampling application.

EVICE

LOCK

IAGRAM

ATTN

Out

AMP

PPLICATIONS



BaseStation Diversity Receivers

Digital Pre-Distortion

Wave

Point-to-Point Radios

Public Safety Receivers

ATTN

AMP

out

Gain

Control

Decode

Logic

Bias

Control

Part#

Gain

Range

22 to -1

IP3

IF freq

range

50 - 160

RDERING

NFORMATION

Omit IDT

prefix

F1200

2.6

F1206*

20 to -11

150 - 250

3.6

IDTF1200NBGI8

F1207*

20 to -11

230 - 300

3.7

RF product Line

*Future Product

RevO

Page 1 of 13

April, 2011

rie

tar

0.75 mm height Tape &

Reel

package

Green

Industrial

Temp range

ART

# M

ATRIX

MODE

SET

STBY
