MN34130
1/ 3.06” 13.4M pixel CMOS Image Sensor
MN34130
SmartFSI
®
Photos courtesy of Myomanji-temple, Kyoto
* This picture is SAMPLE picture.
What’s
SmartFSI
®
?
T
his photograph shows the ambience of a traditional Japanese tea room with its scarlet red carpet and
outside is the beautiful green garden of Kyoto.
SmartFSI
®
captures the moment with exceptional
clarity, displaying natural colors under different lighting conditions. Just like human eye would see...
SmartFSI
®
delivers comparable picture quality to that of a DSC. Can take the same picture quality as
your digital still camera?
Features
•
SmartFSI
®
superior to BSI evolves mobile devices.
• High picture quality equal to DSC, allowing you to take a night view
photo beautifully and vividly in detail
• Multi-fab supply for high-performance chip
• High CRA of up to 35~40 degrees, allowing a low-profile module
Chip Image
Camera Module Image
* “SmartFSI” is a registered trademark or trademark of Panasonic Corporation.
Publication date: June 2014
Page 1 of 2
MN34130
Specifications
Parameter
Scan mode
Optical size
Number of effective pixels
Number of active pixels
Total number of pixels
Pixel size
Actual imaging area dimensions
(active pixel area）
Color filter arrangement
Power supply voltage
Master clock
Bit number of internal ADC
Output signal type
Register I/F
Progressive scan
1/3.06 type 4:3aspect
4224 (H) x 3168 (V) = 13,381,632 (pixel)
4208 (H) x 3152 (V) = 13,263,616 (pixel)
4280 (H) x 3312 (V) = 14,175,360 (pixel)
1.12 (H) um x 1.12 (V) um
4712.96 (H) um x 3530.24 (V) um
R,G,B Bayer Pattern
2.8V / 1.8V / 1.2V
6MHz ~ 60MHz TYP 18MHz Jitter200ps
10bit
MIPI DDR method 648 Mbps
CSI-2 (I2C I/F)
Full scan mode
MIPI 4Lane 10bit format : 15.0 fps
Full HD mode (V2/2mix_cH2/2mix Mode)
MIPI 4Lane 10bit format : 60.0 fps
Full scan mode (15.0 fps)
1 / 15.02 s
1 / 52174 s (1/52174 step)
Analog gain 0dB ~+24dB 0.09375dB/step
Digital gain 0dB ~ +18dB 0.09375dB/step
Full scan mode H/V cropping
Preview
H: 1/2 ~ n/7 sub-sampled, weight considered mix mode
V: 1/2 ~ n/7 sub-sampled, weight considered mix mode
Functions
HD movie mode
1080/60p (V2/2mix_cH2mix_H/V cropping mode)
1080/30p (V2/2mix_cH2mix_V cropping mode)
720/60p (V3/3mix_cH3mix_V cropping mode)
Vertical and horizontal flip mode, Xenon/LED Flash control,
Support Mechanical shutter, OTP 512Byte, Power on Reset
Content
Output frame rate per second
Electronic shutter (Full scan)
Variable gain
Block Diagram
SCL
SDA
I2C
IF
Power
TG
MCLK
(6½60MHz)
Pixel Area
Digital
Circuit
External Supply
1.2v
1.8v
2.8v
PLL
MIPI
TX
IF
(648Mbps)
MIPI
RX
Parallel A/D Converter of Row
