18W AC-DC High Reliability Slim Wall-mounted Adaptor
SGA18U
series
■
Features
Ultra slim
Universal AC input / Full range
2 pole USA plug
No load power consumption <0.075W
Energy efficiency Level
Ⅵ
Comply with EISA 2007/DoE
Class
Ⅱ
power (without earth pin)
Protections: Short circuit / Overload / Over voltage
Fully enclosed plastic case
Pass LPS
LED indicator for power on
3 years warranty
■
Applications
Consumer electronic devices
Telecommunication devices
Office facilities
Industrial equipments
■
Description
SGA18U is a 18W ultra slim wall-mounted style single-output green adaptor series, which is compact and
convenient for carry. SGA18U is a class
Ⅱ
power unit (without FG) equipped with the standard 2-Pin U.S.
plug, accepting the input range from 90VAC to 264VAC. The whole series provides different models with
output voltages ranging between 5VDC and 48VDC that it can satisfy the demands for various types of
consumer electronic devices.
With the efficiency up to 86% and the extremely low no-load power consumption below 0.075W, SGA18U
is compliant with the latest U.S. energy regulation EISA 2007/DoE(Level
Ⅵ
). The supreme feature allows
the adaptor to save the energy when it is under either the operating mode or the standby mode. The entire
series is approved for international safety regulations; moreover, it adopts the 94V-0 flame retardant plastic
case that it can effectively prevent users from electric hazards.
■
Model Encoding
SGA 18 U 05 - P1J
P1J: Plug for standard model, 2.1
ψ×
5
.
5
ψ×
11mm,
C+ tuning fork type
DC plug type
Optional plug type available per request
Output voltage
US 2 pin AC plug
Output wattage
Series name
File Name:SGA18U-SPEC 2015-10-02
{
18W AC-DC High Reliability Slim Wall-mounted Adaptor
SPECIFICATION
ORDER NO.
SAFETY MODEL NO.
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER (max.)
OUTPUT
SGA18U05-P1J
SGA18U05
Note.2
5V
SGA18U
SGA18U18-P1J
SGA18U18
18V
1A
0 ~ 1A
18W
80mVp-p
±3.0%
±1.0%
±3.0%
SGA18U24-P1J
SGA18U24
24V
0.75A
0 ~ 0.75A
18W
100mVp-p
±2.0%
±1.0%
±2.0%
series
SGA18U09-P1J
SGA18U09
9V
2A
0 ~ 2A
18W
80mVp-p
±5.0%
±1.0%
±5.0%
SGA18U12-P1J
SGA18U12
12V
1.5A
0 ~ 1.5A
18W
80mVp-p
±3.0%
±1.0%
±3.0%
SGA18U15-P1J
SGA18U15
15V
1.2A
0 ~ 1.2A
18W
80mVp-p
±3.0%
±1.0%
±3.0%
SGA18U48-P1J
SGA18U48
48V
0.375A
0 ~ 0.375A
18.2W
120mVp-p
±2.0%
±1.0%
±2.0%
3A
0 ~ 3A
15W
RIPPLE & NOISE (max.)
Note.3
80mVp-p
VOLTAGE TOLERANCE
Note.4
±5.0%
LINE REGULATION
LOAD REGULATION
Note.5
±1.0%
Note.6
±5.0%
SETUP, RISE, HOLD UP TIME
300ms, 30ms, 16ms/230VAC
VOLTAGE RANGE
Note.7
90 ~ 264VAC
FREQUENCY RANGE
INPUT
EFFICIENCY (Typ.)
AC CURRENT
INRUSH CURRENT (max.)
LEAKAGE CURRENT(max.)
OVERLOAD
PROTECTION
OVER VOLTAGE
WORKING TEMP.
WORKING HUMIDITY
ENVIRONMENT STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
SAFETY STANDARDS
WITHSTAND VOLTAGE
SAFETY &
ISOLATION RESISTANCE
EMC
(Note. 8)
EMC EMISSION
EMC IMMUNITY
LIFE
OTHERS
MTBF
DIMENSION
PACKING
PLUG
CABLE
47 ~ 63Hz
80.5%
0.45A / 115VAC
30A / 115VAC
0.25mA / 240VAC
84.5%
300ms, 30ms, 16ms/115VAC at full load
84%
84%
84.5%
85%
86%
0.2A / 230VAC
45A / 230VAC
120 ~ 180% rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
110 ~ 140% rated output voltage
Protection type : Clamp by zener diode, output short
-20 ~ +60
℃
(Refer to "Derating Curve")
20% ~ 90% RH non-condensing
-20 ~ +85
℃
, 10 ~ 95% RH
±
0.03% /
℃
(0 ~ 40
℃
)
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
TUV EN60950-1 approved
I/P-O/P:4242VDC
I/P-O/P:100M Ohms / 500VDC / 25
℃
/ 70% RH
Compliance to EN55022 class B, EN61000-3-2,3
Compliance to EN61000-4,-2,3,4,5,6,8,11,
light industry level, criteria A
3 years : 100% load 40
℃
, 8hours / day
450Khrs min. MIL-HDBK-217F(25
℃
)
75.5*32*47.5mm (L*W*H)
150g ; 60pcs / 10kg / CARTON
See page 3 ; Other type available by customer requested
See page 3 ; Other type available by customer requested
CONNECTOR
NOTE
1.All parameters are specified at 115VAC input, rated load, 25
℃
70% RH ambient.
2.DC voltage: The output voltage set at point measure by plug terminal & 50% load.
3.Ripple & noise are measured at 20MHz by using a 12" twisted pair terminated with a 0.1uf & 47uf capacitor.
4.Tolerance: includes set up tolerance, line regulation, load regulation.
5.Line regulation is measured from low line to high line at rated load.
6.Load regulation is measured from 10% to 100% rated load.
7.Derating may be needed under low input voltages. Please check the static characteristics for more details.
8.The power supply is considered as an independent unit, but the final equipment still need to re-confirm that the whole system complies with the
EMC directives. For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.
(as available on http://www.meanwell.com)
File Name:SGA18U-SPEC 2015-10-02
