40W AC-DC High Reliability Slim Wall-mounted Adaptor
SGA40E
series
■
Features
Ultra slim
Universal AC input / Full range
2 pole EURO plug
No load power consumption< 0.075W
Energy efficiency Level
Ⅵ
Comply with EU ErP and meet CoC version 5
Class
Ⅱ
power (without earth pin)
Protections: Short circuit / Overload / Over voltage
Fully enclosed plastic case
Pass LPS
3 years warranty
■
Applications
Consumer electronic devices
Telecommunication devices
Office facilities
Industrial equipments
■
Description
SGA40E is a 40W ultra slim wall-mounted style single-output green adaptor series, which is compact and
convenient for carry. SGA40E is a class
Ⅱ
power unit (without FG) equipped with the standard 2-Pole
European plug, accepting the input range from 90VAC to 264VAC. The whole series provides different
models with output voltages ranging between 5VDC and 48VDC that it can satisfy the demands for various
types of consumer electronic devices.
With the efficiency up to 89% and the extremely low no-load power consumption below 0.075W, SGA40E
is compliant with EU ErP and meet CoC version 5. The supreme feature allows the adaptor to save the
energy when it is under either the operating mode or the standby mode. The entire series is approved
for international safety regulations; moreover, it adopts the 94V-0 flame retardant plastic case that it
can effectively prevent users from electric hazards.
■
Model Encoding
SGA 40 E 05 - P1J
P1J: Plug for standard model, 2.1
ψ×
5
.
5
ψ×
11mm,
C+ tuning fork type
DC plug type
Optional plug type available per request
Output voltage
European 2 pin AC plug
Output wattage
Series name
File Name:SGA40E-SPEC 2015-08-28
{
40W AC-DC High Reliability Slim Wall-mounted Adaptor
SPECIFICATION
ORDER NO.
SAFETY MODEL NO.
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER (max.)
OUTPUT
SGA40E05-P1J
SGA40E05
Note.2
5V
SGA40E
SGA40E18-P1J
SGA40E18
18V
2.22A
0 ~ 2.22A
40W
120mVp-p
±2.0%
±1.0%
±2.0%
SGA40E24-P1J
SGA40E24
24V
1.67A
0 ~ 1.67A
40W
150mVp-p
±2.0%
±1.0%
±2.0%
series
SGA40E09-P1J
SGA40E09
9V
4.44A
0 ~ 4.44A
40W
120mVp-p
±5.0%
±1.0%
±5.0%
SGA40E12-P1J
SGA40E12
12V
3.33A
0 ~ 3.33A
40W
120mVp-p
±3.0%
±1.0%
±3.0%
SGA40E15-P1J
SGA40E15
15V
2.66A
0 ~ 2.66A
40W
120mVp-p
±2.0%
±1.0%
±2.0%
SGA40E48-P1J
SGA40E48
48V
0.84A
0 ~ 0.84A
40W
150mVp-p
±2.0%
±1.0%
±2.0%
5A
0 ~ 5A
25W
RIPPLE & NOISE (max.)
Note.3
120mVp-p
VOLTAGE TOLERANCE
Note.4
±5.0%
LINE REGULATION
LOAD REGULATION
Note.5
±1.0%
Note.6
±5.0%
SETUP, RISE, HOLD UP TIME
500ms, 100ms, 12ms/230VAC
VOLTAGE RANGE
Note.7
90 ~ 264VAC
FREQUENCY RANGE
INPUT
EFFICIENCY (Typ.)
AC CURRENT
INRUSH CURRENT (max.)
LEAKAGE CURRENT(max.)
OVERLOAD
PROTECTION
OVER VOLTAGE
WORKING TEMP.
WORKING HUMIDITY
ENVIRONMENT STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
SAFETY STANDARDS
SAFETY & WITHSTAND VOLTAGE
ISOLATION RESISTANCE
EMC
(Note. 8)
EMC EMISSION
EMC IMMUNITY
LIFE
OTHERS
MTBF
DIMENSION
PACKING
PLUG
CABLE
47 ~ 63Hz
84.5%
1A / 115VAC
40A / 115VAC
0.25mA / 240VAC
88%
0.5A / 230VAC
70A / 230VAC
500ms, 100ms, 12ms/115VAC at full load
86.5%
86.5%
87%
88%
89%
110 ~ 250% rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
110 ~ 140% rated output voltage
Protection type : Clamp by zener diode, output short
-20 ~ +50
℃
(Refer to "Derating Curve")
20% ~ 90% RH non-condensing
-20 ~ +85
℃
, 10 ~ 95% RH
±
0.03% /
℃
(0 ~ 40
℃
)
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
TUV EN60950-1 approved
I/P-O/P:4242VDC
I/P-O/P:100M Ohms / 500VDC / 25
℃
/ 70% RH
Compliance to EN55022 class B, EN61000-3-2,3
Compliance to EN61000-4,-2,3,4,5,6,8,11,
light industry level, criteria A
3 years : 100% load 40
℃
, 12hours / day
400Khrs min. MIL-HDBK-217F(25
℃
)
75.5*32*47.5mm (L*W*H)
165g ; 60pcs / 13kg / CARTON
See page 3 ; Other type available by customer requested
See page 3 ; Other type available by customer requested
CONNECTOR
NOTE
1.All parameters are specified at 230VAC input, rated load, 25
℃
70% RH ambient.
2.DC voltage: The output voltage set at point measure by plug terminal & 50% load.
3.Ripple & noise are measured at 20MHz by using a 12" twisted pair terminated with a 0.1uf & 47uf capacitor.
4.Tolerance: includes set up tolerance, line regulation, load regulation.
5.Line regulation is measured from low line to high line at rated load.
6.Load regulation is measured from 10% to 100% rated load
7.Derating may be needed under low input voltages. Please check the static characteristics for more details.
8.The power supply is considered as an independent unit, but the final equipment still need to re-confirm that the whole system complies with the
EMC directives. For guidance on how to perform these EMC tests, please refer to EMI testing of component power supplies.
(as available on http://www.meanwell.com)
File Name:SGA40E-SPEC 2015-08-28
