PBBO Series
OPEN FRAME & ENCLOSED
5 - 1 0 W AT T S - A C / D C S I N G L E O U T P U T
FEATURES
•
•
•
•
•
•
•
Small foot print
Low height
High efficiency
High power density
High MTBF
Cost effective
Built-in inrush current and overcurrent protection
SPECIFICATIONS
INPUT
STANDARDS
Nominal voltage
Frequency
Input current
Leakage current
Inrush current
Isolation
85-264VAC / 110-370VDC
47-63Hz
0.15A to 0.3A
0.5A max at nominal load and input voltage.
15A Typ (100VAC), 30A Typ (200VAC)
I/P to O/P 3,000VAC
I/P to FG 2,000VAC
O/P to FG 500VAC
See table.
±0.4% - ±0.6%.
±0.6% - ±1.2%.
No.
No.
1% - 2% max p-p. (0 to +55°C).
Works over 125% of rating and recovers
automatically.
Works over 115% of rating (By zener diode
clamping
-10 to +71°C convection, derate from 55
O
C
-20 to +75°C.
20-90%, RH non condesing.
20-90%, RH non condesing.
3,000m (10,000feet) max.
9,000m (30,000feet) max.
Convection.
19.6m/s2 10-55Hz, 3 minutes period, 60 mins
each along X,Y and Z axis (Non operating)
196.1m/s2 11ms, once each X,Y and Z axis
(Non operating)
65% - 81%
60kHz to 200kHz
1,760,000 hours (PBBO-C). 1,610,000 hours
(PBBO-D)
30g (PBBO-C), 40g (PBBO-D)
Safety standards
C tick
EMI standards
UL1950. C-UL, EN60950, VDE0160 Complies
with DEN-AN and IEC60950.
AS/NZS CISPR11 Group 1 Class A.
Complies with FCC-B and VCCI-A.
SELECTION TABLE
MODEL NUMBER
OUTPUT
POWER
PBBO-3C
PBBO-5C
PBBO-12C
PBBO-15C
PBBO-24C
PBBO-3D
PBBO-5D
PBBO-12D
PBBO-15D
PBBO-24D
3.3V
5V
12V
15V
24V
3.3V
5V
12V
15V
24V
1A
1A
0.45A
0.33A
0.22A
2A
2A
0.9A
0.70A
0.45A
5W
5W
5W
5W
5W
10W
10W
10W
10W
10W
OUTPUT
Voltage
Line regulation
Load regulation
Voltage adjustment
Current adjustment
Ripple and noise
Overcurrent protection
Overvoltage protection
ENVIRONMENTAL
TECHNICAL ILLUSTRATIONS
PBBO-C
Operating temperature
Storage temperature
Operating humidity
Storage humidity
Operating altitude
Storage altitude
Cooling
Vibration
Impact
Efficiency
Switching frequency
MTBF
Weight
PBBO-D
10
Doc. No. PBC9 Rev.C 28-4-11
