RoHS
SCM25
.126±.007
(3.2±0.2)
Common Mode Filter
.086±.007
(2.2±0.2)
Dimensions:
Inches
(mm)
E
.098±.007
(2.5±0.2)
1
2
.023
(0.6)
4
3
.031±.004
(0.8±0.1)
.031±.004
(0.8±0.1)
.063
(1.6)
.173
(4.4)
Features
• SMD (1210) common mode filter
• Excellent noise attenuation in a small
package
• Suitable for automated assembly
• SCM series offers wide impedance
range
• Excellent solderability
Electrical
Impedance range:
90 Ω to 1000 Ω
Tolerance:
25% over entire range
Test Frequency:
100Mhz
Operating Temp:
-40ºC ~ 125ºC
Rated Current:
Based on temp rise of
40ºC above ambient with no current
D
Allied
Part
Number
Impedance
(Ω)
+/-25%
.138
(3.5)
D
Test Freq.
(MHz)
Rated
Current
(mA)Max
Rated Withstand
Voltage
Volt (Vdc)
Vdc Max
(Max)
DCR
Max.
(Ω)
IR
(Ω)
Min
SCM25-900T-RC
90
100
1000
50
10
0.27
10
SCM25-601T-RC
600
100
1000
50
10
0.20
10
SCM25-102T-RC
1000
100
1200
50
10
0.30
10
All specifications subject to change without notice.
SCM25-900T-RC
1000
10000
SCM25-601T-RC
Resistance to Solder Heat
IMPEDANCE(Ohm)
Pre-Heat 150ºC, 1 minute
Solder Composition:
Sn/Ag3.0/Cu0.5
Solder Temp:
260ºC peak for 10 sec.
Test time:
4 minutes
Test Equipment
(Z):
HP4286A / HP4287A /
(DCR):
Chen Hwa 502BC
Insulation Resistance:
HP4339B
Physical
Packaging:
2000 pieces per 7 inch reel
Marking:
None
Schematic
IMPEDANCE(Ohm)
100
Common Mode
1000
Common Mode
100
10
10
Normal Mode
1
Normal Mode
1
0.1
1
10
100
1000
0.1
1
10
100
1000
10000
FREQUENCY(MHz)
FREQUENCY(MHz)
SCM25-102T-RC
10000
1000
Common Mode
IMPEDANCE(Ohm)
100
10
1
Normal Mode
0.1
1
10
100
1000
10000
FREQUENCY(MHz)
949-356-1780
ALLIED COMPONENTS INTERNATIONAL
07/07/2015
www.alliedcomponents.com
