AM50E-4805S-NZ: DescriptionDC/DC Converter; Product Weight (grams): 35; Input voltage min (V): 36; Input voltage max (V): 75; Output voltage min: 5; Output voltage max: 5; Output voltage dual assymetric (y/n): Single; Output Power (W): 50; Max Output current (A): 10; Efficiency (%): 93; Max Capacitive load (µF): 18900; Package type: 2x1; Mounting: PCB; W (in): 1; L (in): 2; H (in): 0.46; W (mm): 25.4; L (mm): 50.8; H (mm): 11.8; Min Operating temperature: -40; Max operating temperature (°C): 85; Isolation (VDC): 1500; EMC compliance 2: EN 55022 Class B; Case material: Aluminum; Application 4 (building automation/IoT): 1; Application 5 (Industrial): 1; MTBF (h): 1000000; Derating : 55; Voltage Accuracy (%): ±2; Line Regulation (% of Vin): ±0.3; Load Regulation %: ±0.3; Ripple & Noise (mV p-p): 120; Switching Frequency typ (KHz): 300; Short circuit protection: Continuous; On/Off Control: 1; Voltage adjustment: 1; File Size217KB，5 Pages; ManufacturerAimtec; Websitehttp://www.aimtec.ca/; Environmental Compliance

Download Datasheet Compare View All

AM50E-4805S-NZ Overview

DC/DC Converter; Product Weight (grams): 35; Input voltage min (V): 36; Input voltage max (V): 75; Output voltage min: 5; Output voltage max: 5; Output voltage dual assymetric (y/n): Single; Output Power (W): 50; Max Output current (A): 10; Efficiency (%): 93; Max Capacitive load (µF): 18900; Package type: 2x1; Mounting: PCB; W (in): 1; L (in): 2; H (in): 0.46; W (mm): 25.4; L (mm): 50.8; H (mm): 11.8; Min Operating temperature: -40; Max operating temperature (°C): 85; Isolation (VDC): 1500; EMC compliance 2: EN 55022 Class B; Case material: Aluminum; Application 4 (building automation/IoT): 1; Application 5 (Industrial): 1; MTBF (h): 1000000; Derating : 55; Voltage Accuracy (%): ±2; Line Regulation (% of Vin): ±0.3; Load Regulation %: ±0.3; Ripple & Noise (mV p-p): 120; Switching Frequency typ (KHz): 300; Short circuit protection: Continuous; On/Off Control: 1; Voltage adjustment: 1

Preview

Download Datasheet

View All

Series AM50E-NZ

50 Watt | DC-DC Converter

Picture coming soon

FEATURES:

•

Wide Input range 2:1

High Efficiency up to 93%

Remote On/Off Control

Trim Adjustment

•

Input to Output Isolation of 1500VDC

Input Over Voltage and Under Voltage Lockout

Output OVP, OCP & SCP

Operating Temperature -40 to +85°C

Models

Single output

Model

Input

Voltage (V)

Output

Voltage

(V)

Output Current

max (A)

No load Input

Current

(mA)

Max

Capacitive

Load(uF)

Efficiency

(%)

AM50E-2403S-NZ

18-36

3.3

27000

AM50E-2405S-NZ

18-36

18900

AM50E-2412S-NZ

18-36

4.167

3700

AM50E-2415S-NZ

18-36

3.333

2000

AM50E-2424S-NZ

18-36

2.083

1000

AM50E-4803S-NZ

36-75

3.3

27000

AM50E-4805S-NZ

36-75

18900

AM50E-4812S-NZ

36-75

4.167

3700

AM50E-4815S-NZ

36-75

3.333

2000

AM50E-4824S-NZ

36-75

2.083

1000

Add suffix “-K” for optional heatsink

NOTE: All specifications in this datasheet are measured at an ambient temperature of 25°C, humidity<75%, nominal input voltage and at

rated output load unless otherwise specified.

Input Specifications

Parameters

Voltage range

Filter

Start up time

Absolute Maximum Rating

Peak Input Voltage time

On/Off control*

Input Current

Over Voltage Lockout

Under Voltage Lockout

Input reflected current

Nominal

Typical

18-36

36-75

π(Pi) Network

Maximum

Units

VDC

-0.7 ~ 50

-0.7 ~ 100

ON – open or TTL high (3 - 12VDC) ;

OFF – connected to GND or TTL low (0 - 1.2VDC)

2.24

1.12

VDC

*The voltage on the On/Off Control pin is relative to input Ground.

Isolation Specifications

Parameters

Tested I/O voltage

Resistance

Capacitance

Conditions

1 min, ≤1mA

Isolation 500VDC

100kHz, 0.1V

Typical

1500

>1000

2000

Rated

1500

Units

VDC

MOhm

www.aimtec.com

F 051e R13

Tel: +1 514 620 2722

1 of 5

Toll free: + 1 888 9 AIMTEC

(924 6832)

North America only
