C0510X6S0G104M030AC
TDK Item Description : C0510X6S0G104MT****
DC Bias Characteristic
Application & Main Feature
Cap. Change/%
0
-5
-10
-15
-20
-25
-30
-35
-40
-45
-50
0
1
2
3
4
5
Commercial Grade ( Low ESL Reverse Geometry )
Series
C0510 [EIA CC0204]
DC Bias/V
Dimensions
L
W
T
B
0.52mm
1.00mm
0.30mm
0.10mm
+/-0.05mm
+/-0.05mm
+/-0.05mm
Min.
|Z|, ESR vs. Freq. Characteristics
100000
10000
20
10
0
-10
-20
-30
-40
-50
-60
-70
-80
-90
0.01
0.1
1
10
100
1000
-80
-60
Temperature Characteristic
1000
100
10
1
0.1
0.01
0.001
Temperature Characteristic
Characterization Sheet ( Multilayer Ceramic Chip Capacitors )
X6S (-55 to 105 degC +/-22%)
0G (4Vdc)
100nF
Rated Voltage
Capacitance
Cap. Change/%
|Z|, ESR/ohm
-40
-20
0
20
40
60
80
100
120
Frequency/MHz
|Z|
ESR
Temperature/degC
Temp.Chara.
TCBias(1/2Rated)
Capacitance Tolerance
M (+/-20%)
12% Max.
1000
Cap. vs. Freq. Characteristic
25
Ripple Temperature Rise Characteristic
Temperature Rise/degC
20
15
10
5
0
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
Dissipation Factor
Insulation Resitance
1Gohm Min.
Cap./nF
100
10
AEC-Q200
Not Applicable
1
0.001
0.01
0.1
1
10
100
1000
Frequency/MHz
100kHz
Current/Arms
500kHz
1MHz
All specifications are subject to change without notice.
September 27, 2013
