Total
Tota Power International, Inc.
TPSPU60 SERIES
Features:
Wide Operating Voltage 90 to 264 VAC,47 to 63 Hz
IEC-320-C14 Input Inlet
Over Voltage Protection (Crowbar Design)
Optional Output Connector (See page appendix)
Single Output
Energy Star 2.0, Efficiency level V
Class I
2 year warranty
60W Desk Top Type
I.T.E. Power Supplies
Electrical Characteristics:
Vin
fin
Po
Vo
Io
Iil
Iih
Ir
Eff
REG-i
OVP
OCP
Ttr
Th
Ts
Vp-p
Ilk
TC
Pno
Vps
Vpg
Ris
Safety Approvals Input Voltage Range
Operate Voltage Range
Input Frequency
Output Power Range
Output Voltage Range
Output Current Range
Input Current (Low Line)
Input Current (High Line)
Low Line Inrush Current
High Line Inrush Current
Efficiency
Line Regulation
Over Voltage Protection
Over Current Protection
Time of Transient Response
Hold-Up Time
Start Up Time
Ripple & Noise(Peak to Peak)
Safety Ground Leakage Current
Temperature Coefficient
No-Load Power Consumption
Dielectric Withstanding Voltage
for Primary to secondary
Dielectric Withstanding Voltage
for Primary to PE
Isolation Resistance
Io=Full Load to Half Load, Vin=100VAC
Io=Full Load, Vin=110VAC
Io=Full Load, Vin=100VAC
Full Load, Vin=90VAC
Vin=240VAC/60Hz
All output
No load, Vin=230VAC
Primary to secondary
Primary to PE
Test Voltage=500VDC
Io=Full load, Vin=100VAC
Io=Full load, Vin=240VAC
Io=Full load, 25°C, Cool start, Vin=115VAC
Io=Full load, 25°C, Cool start, Vin=230VAC
Io=Full Load, Vin=230VAC
Io=Full Load
Vin=230VAC
100~240VAC
90~264VAC
47~63Hz
See rating chart
See rating chart
See rating chart
Application:
- POS System
- AV Equipment
- Industrial PC
- Note PC
- Charger
- LED Lighting
1.6A
1.0A
42A (max.)
85A (max.)
75~90%
0.5~1%
3~7%
112~132%
110~150%
4mS (max.)
16mS (min.)
2S (max.)
1% (max.)
0.75mA (max.)
±0.04%/°C
See rating chart
4242VDC (min.)
2594VDC (min.)
50M
(min.)
Safety Approvals:
S&E
REG-o Load Regulation
RoHS
2002/95/EC
COMPLIANT
UL/c-UL(UL 60950-1:2nd Edition)
TUV/GS(EN 60950-1:2nd Edition)
The
TPSPU60-108
is
available
with
KC mark
(Korea Certification).
Note:
The Ripple & Noise which is under 3.3VDC at 2% max
Environmental
To
Ts
Ho
Hr
MTBF
Pd
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Operating Temperature at 25°C
,
Calculated per MIL-HDBK-217F
Derate linearly from 100% load at 40°C to 50% load at 70°C
See derating curve
-40~85°C
0~95%
0~95%
0.1M Hrs (min.)
Total Power In
International, Inc
Toll Free: 877-646-0900
www.total-power.com
Tota Power International, Inc.
Total
TPSPU60 SERIES
Output Voltage And Current Rating Chart ( Single Output ) :
Model Number
TPSPU60-101
TPSPU60-102
TPSPU60-103
TPSPU60-104
TPSPU60-105
TPSPU60-105-1
TPSPU60-106
TPSPU60-107
TPSPU60-108
TPSPU60-109
TPSPU60-110
TPSPU60-111
60W Desk Top Type
I.T.E. Power Supplies
Output Voltage
3 ~ 5 VDC
5 ~ 6 VDC
6 ~ 8 VDC
8 ~ 11 VDC
11 ~ 13 VDC
11 ~ 13 VDC
13 ~ 16 VDC
16 ~ 21 VDC
21 ~ 27 VDC
27 ~ 33 VDC
33 ~ 40 VDC
40 ~ 50 VDC
Output Current
6.60 ~ 4.00 A
6.00 ~ 5.00 A
5.83 ~ 4.37 A
5.00 ~ 3.63 A
4.54 ~ 3.84 A
5.45 ~ 4.61 A
4.23 ~ 3.43 A
3.75 ~ 2.85 A
2.85 ~ 2.22 A
2.22 ~ 1.81 A
1.81 ~ 1.50 A
1.50 ~ 1.20 A
Total
Regulation
7%
5%
5%
5%
5%
5%
5%
5%
5%
5%
3%
3%
Max
.
Output Power
20W
30W
35W
40W
50W
60W
55W
60W
60W
60W
60W
60W
Pno
(max.)
0.5W
0.5W
0.5W
0.5W
0.5W
0.5W
0.5W
0.5W
0.5W
0.5W
0.5W
0.5W
TPSPU60-105-1
is required to use AWG#16/4FT,UL2464 output cable.
TPSPU60-105,106~107
are required to use AWG#16/4FT,UL1185 output cable.
TPSPU60-108~111
are required to use AWG#18/4FT,UL1185 output cable.
Mechanical Specifications:
Note:
1. Dimensions are shown in mm.
2. Weight: 340gs approx.
3. Optional output connector:
See page Appendix.
Derating Curve :
120%
100%
Output Watts (%)
1. Operating Temperature: 0 to 70°C
2. Derate linearly from 100% load at 40°C to 50%
load at 70°C
80%
60%
40%
20%
0%
0
10
20
30
40
50
60
70
80
Temperature (deg c)
Total Power In
International, Inc
Toll Free: 877-646-0900
www.total-power.com
