ECS-.327-6-12L-TR datasheet, PDF

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Passive components> Crystal/resonator> ECS-.327-6-12L-TR

Preview

ECS-.327-6-12L-TR: DescriptionParallel - Fundamental Quartz Crystal,; CategoryPassive components Crystal/resonator; File Size406KB，2 Pages; ManufacturerECS; Websitehttp://www.ecsxtal.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

ECS-.327-6-12L-TR Overview

Parallel - Fundamental Quartz Crystal,

ECS-.327-6-12L-TR Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	7107602148
Reach Compliance Code	compliant
Ageing	3 PPM/FIRST YEAR
Crystal/Resonator Type	PARALLEL - FUNDAMENTAL
Drive level	0.1 µW
frequency stability	0.0144%
frequency tolerance	20 ppm
JESD-609 code	e4
load capacitance	6 pF
Installation features	SURFACE MOUNT
Nominal operating frequency	0.032768 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
physical size	2.0mm x 1.2mm x 0.38mm
Series resistance	100000 Ω
surface mount	YES
Terminal surface	Gold (Au)

Preview

Download Datasheet

View All

Obsolete/End of Life Date 3/11/2022

The ultra-miniature ECX-12L is a very compact SMD Tuning Fork

Crystal. The 2.0 x 1.2 x 0.38 mm

low profile

ceramic package is

ideal for smart cards, mobile devices, and industrial applications.

ECX-12L SMD CRYSTAL

ECX-12L

32.768 KHz

SMD Tuning Fork Crystal

Request a Sample

OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS

PARAMETERS

Frequency

Frequency Tolerance

Load Capacitance

Drive Level

Equivalent Series Resistance

Motional Capacitance

Turnover Temperature

@ +25°C

CONDITIONS

MIN

ECX-12L

TYP

MAX

UNITS

KHz

± 20 *

ppm

pF

0.5

100K

μW

Ω

fF

+30

-0.040

±3

°C

ppm/°C²

pF

ppm

°C

+85

+125

32.768

Specify in P/N

D

L

R

1

7.0

+20

-0.02

Co

@ +25°C ±3°C

T

opr

T

stg

-40

-55

+25

-0.03

1.3

12.5

0.1

•

Low Profile 0.38 mm H

•

2.0 x 1.2 mm Footprint

•

Low Power RTC Applications

such as STM32

AN2867

•

RoHS Compliant

•

Applications: Automotive,

COTS, Industrial, IOT

Temperature Coefficient

Shunt Capacitance

Aging (First Year)

Operating Temperature

Storage Temperature

DIMENSIONS (mm)

PAD CONNECTIONS

1

In/Out

2

Out/In

Figure 1)

Top, Side, and Bottom views

Figure 2)

Suggested Land Pattern

PACKAGE

CUSTOM OPTIONS

Tolerance

-12L = ECX-12L

Blank = ±20 ppm

* C = ± 10 ppm

TR = Tape

& Reel

5K/Reel

PART NUMBERING GUIDE: Example ECS-.327-12.5-12L-TR

ECS - FREQUENCY ABBREVIATION

LOAD

CAPACITANCE

12.5 = 12.5 pF

9 = 9 pF

7 = 7 pF

6 = 6 pF

PACKAGING

ECS

.327 = 32.768 KHz

*Contact ECS for availability

Rev.2022

15351 West 109

th

Street

|

Lenexa, KS 66219

|

Phone: 913.782.7787

|

Fax: 913.782.6991

|

www.ecsxtal.com

ECS-.327-6-12L-TR Related Products

	ECS-.327-6-12L-TR	ECS-.327-6-12L-C-TR
Description	Parallel - Fundamental Quartz Crystal,	Parallel - Fundamental Quartz Crystal,
Is it Rohs certified?	conform to	conform to
Objectid	7107602148	7107602147
Reach Compliance Code	compliant	compliant
Ageing	3 PPM/FIRST YEAR	3 PPM/FIRST YEAR
Crystal/Resonator Type	PARALLEL - FUNDAMENTAL	PARALLEL - FUNDAMENTAL
Drive level	0.1 µW	0.1 µW
frequency stability	0.0144%	0.0144%
frequency tolerance	20 ppm	10 ppm
JESD-609 code	e4	e4
load capacitance	6 pF	6 pF
Installation features	SURFACE MOUNT	SURFACE MOUNT
Nominal operating frequency	0.032768 MHz	0.032768 MHz
Maximum operating temperature	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C
physical size	2.0mm x 1.2mm x 0.38mm	2.0mm x 1.2mm x 0.38mm
Series resistance	100000 Ω	100000 Ω
surface mount	YES	YES
Terminal surface	Gold (Au)	Gold (Au)
