DC COMPONENTS CO., LTD.
R
SF31
THRU
SF38
RECTIFIER SPECIALISTS
TECHNICAL SPECIFICATIONS OF SUPER FAST RECTIFIER
VOLTAGE RANGE - 50 to 600 Volts
CURRENT - 3.0 Amperes
FEATURES
*
*
*
*
*
*
*
High reliability
Low leakage
Low forward voltage
High current capability
Super fast switching speed
High surge capability
Good for switching mode circuit
DO-27
MECHANICAL DATA
*
*
*
*
*
Case: Molded plastic
Epoxy: UL 94V-0 rate flame retardant
Lead: MIL-STD-202E, Method 208 guaranteed
Mounting position: Any
Weight: 1.18 grams
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Dimensions in inches and (millimeters)
SYMBOL
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Volts
Maximum DC Blocking Voltage
Maximum Average Forward Current
at T
A
= 55
o
C
Peak Forward Surge Current I
FM
(surge):8.3 ms single half
sine-wave superimposed on rated load (JEDEC Method)
Maximum Forward Voltage at 3.0A DC
Maximum DC Reverse Current
at Rated DC Blocking Voltage
Maximum Reverse Recovery Time (Note 1)
Typical Junction Capacitance (Note 2)
Operating and Storage Temperature Range
NOTES : 1. Test Conditions: I
F
=0.5A, I
R
=1.0A, I
RR
=0.25A.
2. Measured at 1 MH
Z
and applied reverse voltage of 4.0 volts.
@T
A
= 25
o
C
@T
A
=150
o
C
V
RRM
V
RMS
V
DC
I
O
I
FSM
V
F
I
R
trr
C
J
T
J
, T
STG
SF31
50
35
50
SF32
100
70
100
SF33
150
105
150
SF34
200
140
200
3.0
125
SF35
300
210
300
SF36
400
280
400
SF38
600
420
600
UNITS
Volts
Volts
Volts
Amps
Amps
0.95
5.0
1.25
1.7
Volts
uAmps
300
35
50
-65 to + 150
30
nSec
pF
0
C
44
