Features
Available in Linear and Audio Taper
Switch Type Available in Both Audio and Linear Taper
Solder Lug and Combination Type Terminals
Perfect for Consumer Electronics Applications
24mm Potentiometer
Potentiometer
−
1/2 Watt and 1/4 Watt,
6mm dia. shaft
P9
.453 (11.5)
1.181 (30.0)
.256
(6.5)
.945 (24.0) Dia
.236
(6.0)
.740
(18.8)
M9*0.75
.969 (24.6)
NTE Part No.
502−0401
502−0402
502−0403
502−0404
502−0405
502−0406
502−0407
502−0408
502−0409
502−0410
502−0411
502−0412
502−0413
502−0414
502−0415
502−0416
502−0417
502−0418
502−0419
502−0420
502−0421
502−0422
502−0423
502−0424
502−0425
Value
(Ohms)
500
1K
1K
1K
5K
5K
5K
10K
10K
10K
10K
50K
50K
50K
100K
100K
100K
500K
500K
500K
500K
1M
1M
1M
1M
Taper
Linear
Linear
Audio
Audio
Audio
Linear
Audio
Linear
Linear
Audio
Audio
Linear
Audio
Audio
Linear
Audio
Audio
Linear
Linear
Audio
Audio
Linear
Linear
Audio
Audio
Switch
No
No
Yes
No
Yes
No
No
No
Yes
No
Yes
No
No
Yes
No
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes
Terminal Style
Combination
Solder Lug
Combination
Combination
Combination
Solder Lug
Combination
Solder Lug
Combination
Combination
Combination
Solder Lug
Combination
Combination
Solder Lug
Combination
Combination
Solder Lug
Combination
Combination
Combination
Solder Lug
Combination
Combination
Combination
Diag No.
P9
P10
P11
P9
P11
P10
P9
P10
P11
P9
P11
P10
P9
P11
P10
P9
P11
P10
P11
P9
P11
P10
P11
P9
P11
.787 (20.0)
.728
(18.5)
M9*0.75
.236
(6.0)
.787 (20.0)
P10
.449 (11.4)
1.181 (30.0)
.256
(6.5)
.953 (24.2) Dia
Specifications
Electrical
Resistance Range
−
Linear Taper:
500 to 1 Meg
Resistance Range
−
Audio Taper:
1K to 1 Meg
Resistance Tolerance:
20%
Sliding Noise:
less than 47mV
20 (R > 10K)
Residual Resistance:
10 (R 10K)
Insulation Resistance:
more than 100 Meg at 500VDC
Switch Contact Resistance:
less than 0.3
Operating Voltage:
250VAC
Rated Power
−
Linear Taper:
0.5W
Rated Power
−
Audio Taper:
0.25W
Switch Rated Power:
125VAC at 1A
Withstand Voltage:
1 minute at 500VAC
P11
.787 (20.0)
.197
(5.0)
1.181 (30.0)
.256
(6.5)
.945 (24.0) Dia
Mechanical
.236
(6.0)
M9*0.75
.787 (20.0)
.787 (20.0)
Total Rotation Angle:
300 10
Switch Angle:
50 5
Rotation Torque:
30gf.cm to 200gf.cm
Switch Action:
150gf.cm to4350gf.cm
Rotation Stopper Strength:
5Kgf.cm Min
Shaft Push−Pull Strength:
7Kgf. Min
Rotation Life:
15,000 cycles
Switch Life:
10,000 cycles
Mounting Hole:
.312” (7.9mm) dia,
Environmental
Operating Temperature:
−10
C to +70 C
Resistance to Soldering Heat:
260 C for 3 seconds
66
NTE Electronics, Inc.
Voice (973) 748−5089
FAX (973) 748−6224
http://www.nteinc.com
