www.amccaps.com
C
OMMERCIAL
S
WITCH
-M
ODE
R
ADIAL
L
EADED
C
APACITORS
K
EY
F
EATURES
• Rated Working Voltages from 25 to 500 VDC
• Rugged Epoxy Coating Offers Increased Protection
• Compact MLC Designs Smaller Than Film or Disc
• Hi-Rel Screened Versions Available
• Custom Sizes, Voltages, and Values Available
A
PPLICATIONS
• Power Supplies
• Voltage Multipliers
• Data Isolation
• Surge Protection
• Industrial Control Circuits
• Custom Applications
C
APACITANCE
/ V
OLTAGE
S
ELECTION
W
H
T
S
Ld
W
H
T
S
Ld
W
H
T
S
Ld
W
H
T
S
Ld
.300 max.
.300 max.
.200 max.
.200 nom.
.020 nom.
.400 max.
.400 max.
.200 max.
.200 nom.
.020 nom.
.500 max.
.500 max.
.200 max.
.400 nom.
.025 nom.
.870 max.
.600 max.
.200 max.
.790 nom.
.032 nom.
(7.62 max.)
(7.62 max.)
(5.08 max.)
(5.08 nom.)
(.510 nom.)
(10.2 max.)
(10.2 max.)
(5.08 max.)
(5.08 nom.)
(.510 nom.)
(12.7 max.)
(12.7 max.)
(5.08 max.)
(10.2 nom.)
(.635 nom.)
(22.1 max.)
(15.2 max.)
(5.08 max.)
(20.1 nom.)
(.813 nom.)
RATED
VOLTAGE
NPO CAPACITANCE (MAX.)
VALUE
CODE
X7R CAPACITANCE (MAX.)
VALUE
CODE
H03
25 VDC
50 VDC
100 VDC
200 VDC
500 VDC
25 VDC
50 VDC
100 VDC
200 VDC
500 VDC
25 VDC
50 VDC
100 VDC
200 VDC
500 VDC
25 VDC
50 VDC
100 VDC
200 VDC
500 VDC
.070 µF
.060 µF
.050 µF
.040 µF
.020 µF
.120 µF
.100 µF
.082 µF
.050 µF
.030 µF
.240 µF
.200 µF
.180 µF
.110 µF
.070 µF
.750 µF
.620 µF
.560 µF
.360 µF
.240 µF
703
603
503
403
203
124
104
823
503
303
244
204
184
114
703
754
624
564
364
244
2.70 µF
2.20 µF
1.80 µF
.800 µF
.300 µF
4.70 µF
3.30 µF
2.70 µF
1.00 µF
.390 µF
8.20 µF
7.50 µF
6.20 µF
2.70 µF
1.00 µF
28.0 µF
24.0 µF
18.0 µF
8.20 µF
3.00 µF
275
225
185
804
304
475
335
275
105
394
825
755
625
275
105
286
246
186
825
305
H04
H05
H06
Advanced Monolythic Ceramics, Inc., A Johanson Company 3101 Constitution Avenue, Olean, New York 14760 • (716) 372-5225 • Fax (716) 372-5467
13
www.amccaps.com
C
APACITANCE
/ V
OLTAGE
S
ELECTION
W
H
T
S
Ld
W
H
T
S
Ld
W
H
T
S
Ld
W
H
T
S
Ld
1.10 max.
.600 max.
.200 max.
.980 nom.
.032 nom.
1.10 max.
.600 max.
.350 max.
.980 nom.
.032 nom.
.670 max.
.540 max.
.200 max.
.575 nom.
.025 nom.
.930 max.
.720 max.
.250 max.
.800 nom.
.032 nom.
(27.9 max.)
(15.2 max.)
(5.08 max.)
(24.9 nom.)
(.813 nom.)
(27.9 max.)
(15.2 max.)
(8.89 max.)
(24.9 nom.)
(.813 nom.)
(17 max.)
(13.7 max.)
(5.08 max.)
(14.6 nom.)
(.635 nom.)
(23.6 max.)
(18.3 max.)
(6.35 max.)
(20.3 nom.)
(.813 nom.)
RATED
VOLTAGE
NPO CAPACITANCE (MAX.)
VALUE
CODE
X7R CAPACITANCE (MAX.)
VALUE
CODE
H07
25 VDC
50 VDC
100 VDC
200 VDC
500 VDC
25 VDC
50 VDC
100 VDC
200 VDC
500 VDC
25 VDC
50 VDC
100 VDC
200 VDC
500 VDC
25 VDC
50 VDC
100 VDC
200 VDC
500 VDC
.680 µF
.560 µF
.470 µF
.330 µF
.200 µF
1.20 µF
1.10 µF
.820 µF
.470 µF
.300 µF
.450 µF
.360 µF
.330 µF
.240 µF
.180 µF
1.00 µF
.900 µF
.750 µF
.470 µF
.300 µF
684
564
474
334
204
125
115
824
474
304
454
364
334
244
184
105
904
754
474
304
24.0 µF
20.0 µF
16.0 µF
6.80 µF
2.40 µF
33.0 µF
22.0 µF
16.0 µF
10.0 µF
5.10 µF
17.0 µF
14.0 µF
11.0 µF
6.00 µF
2.40 µF
39.0 µF
30.0 µF
24.0 µF
16.0 µF
8.00 µF
246
206
166
685
245
336
226
166
106
515
176
146
116
605
245
396
306
246
166
805
H08
H09
H10
W
T
Dielectric specifications are listed on page 16
H
S
Meniscus
Height
.050" Max
H
OW TO
O
RDER
201
VOLTAGE
Standard Voltages:
250 = 25 V
500 = 50 V
101 = 100 V
201 = 200 V
501 = 500 V
H07
CASE SIZE
See Chart
W
DIELECTRIC
N = NPO
W = X7R
105
CAPACITANCE
1st two digits are
significant; third digit
denotes number of
zeros.
102 = 1000 pF
103 = 0.01 µF
105 = 1.00 µF
106 = 10.0 µF
K
TOLERANCE
J = ± 5%
K = ± 10%
M = ± 20%
Z = +80% -20%
Q
TERMINATION
Q = Leaded &
Encapsulated
4
MARKING
4 = Standard
3 = Specified
SPECIAL MODIFIER
H = High Rel Testing
per Customer
Part number written: 201H07W105KQ4
14
Advanced Monolythic Ceramics, Inc., A Johanson Company 3101 Constitution Avenue, Olean, New York 14760 • (716) 372-5225 • Fax (716) 372-5467
www.amccaps.com
C
OMMERCIAL
S
WITCH
-M
ODE
R
ADIAL
L
EADED
C
APACITORS
DIELECTRIC CHARACTERISTICS
NPO DIELECTRIC
TEMPERATURE COEFFICIENT:
DISSIPATION FACTOR:
AGEING:
INSULATION RESISTANCE:
DIELECTRIC STRENGTH:
FOR 1,000 - 5,000 V RATINGS:
FOR 500 V RATINGS:
FOR 200 -250 V RATINGS:
FOR 50 -100 V RATINGS:
TEST PARAMETERS:
0 ± 30 ppm / °C , -55 to 125°C
.001 (0.1%) max, 1Khz, 25°C
None
1000
ΩF
or 100 GΩ, whichever is
less @ 25°C, WVDC (1KVDC max)
1.2 X WVDC, 25°C, 50 mA max
750 VDC, 25°C, 50 mA max
2.0 X WVDC, 25°C, 50 mA max
2.5 X WVDC, 25°C, 50 mA max
1Khz ± 50Hz, 1.0±0.2 VRMS, 25°C
X7R DIELECTRIC
0 ± 15% ,-55 to 125°C
.025 (2.5%) max, 1KHz, 25°C
2.5% / decade hour
1000
ΩF
or 100 GΩ, whichever is
less @ 25°C, WVDC (1KVDC max)
1.2 X WVDC, 25°C, 50 mA max
750 VDC, 25°C, 50 mA max
2.0 X WVDC, 25°C, 50 mA max
2.5 X WVDC, 25°C, 50 mA max
1Khz ± 50Hz, 1.0±0.2 VRMS, 25°C
TYPICAL CAPACITANCE CHANGE VS TEMPERATURE:
2.0%
1.5%
1.0%
0.5%
0.0%
-0.5%
-1.0%
-1.5%
-2.0%
-55°C
-25°C
0°C
25°C
50°C
75°C
100°C
125°C
25%
20%
15%
10%
NPO
5%
0%
-5%
-10%
-15%
-20%
-25%
-55°C
-25°C
0°C
25°C
50°C
X7R
75°C
100°C
125°C
Advanced Monolythic Ceramics, Inc. reserves the right to make design and price changes without notice. All sales
are subject to Advanced Monolythic Ceramics, Inc. terms and conditions printed on the back side of our sales order
acknowledgment forms including a limited warranty and remedies for non-conforming goods or defective goods.
We will be pleased to provide a copy of these terms and conditions for your review.
Advanced Monolythic Ceramics, Inc., A Johanson Company 3101 Constitution Avenue, Olean, New York 14760 • (716) 372-5225 • Fax (716) 372-5467
15
