M
ulti
-l
ayer
H
igH
-Q C
apaCitors
These lines of multilayer capacitors have been developed for
High-Q and microwave applications.
•
The
S-Series
(R07S, R14S, R15S) capacitors give an ultra-
high Q performance, and exhibit NP0 temperature characteris-
tics.
•
The
L-Series
(R05L) capacitors give mid-high Q performance,
and exhibit NP0 temperature characteristics.
•
The
E-Series
(S42E, S48E, S58E) capacitors give excellent
high-Q performance from HF to Microwave frequencies.
Typical uses are high voltage, high current applications. They
are offered in chip (Ni barrier or Non-Magnetic Pt.-Ag) or in
Non-Magnetic leaded form.
•
RoHS compliance is standard for all unleaded parts (see
termination options box).
•
Automotive versions (AEC-Q200) of R05L, R07S, R14S,
R15S, and S42E series are available on request
H
ow To
o
rder
252
WVDC
2
250 = 25 V
500 = 50V
201 = 200 V
251 = 250 V
501 = 500 V
102 = 1000 V
152 = 1500 V
252 = 2500 V
362 = 3600 V
722 = 7200 V
S48
CASE SIZE
R05 (0201)
R07 (0402)
R14 (0603)
R15 (0805)
S42 (1111)
S48 (2525)
S58 (3838)
E
470
CAPACITANCE (pF)
1st two digits are
significant; third digit
denotes number of
zeros, R = decimal .
100 = 10 pF
101 = 100 pF
K
TOLERANCE
< 10pF
A = ± 0 .05 pF
B = ± 0 .10 pF
C = ± 0 .25 pF
D = ± 0 .50 pF
≥
10pF
F = ±1 %
G = ±2%
J = ±5%
K = ± 10%
For tolerance
availability, see
chart .
V
TERMINATION
Nickel Barrier
V = Ni/Sn (Green)
T = Ni/SnPb
G = Ni/Au (Green)
Non-Mag
1
U = Cu/Sn (Green)
C = Cu/SnPb
Leaded (All Non-
Mag)
1
1 = Microstrip
2 = Axial Ribbon
3 = Axial Wire
4 = Radial Ribbon
5 = Radial Wire
4
E
PACKAGING
S = Bulk
W = Waffle Pack
0201 - 0603
Y = Paper 5” Reel
T = Paper 7” Reel
R
1
= Paper 13” Reel
J
1
= Paper 5” Reel -
Horizontally Oriented Electrodes
1
-AEC
QUALIFICATION
AEC-Q200
qualification
3
(optional)
DIELECTRIC
S = Ultra High Q NPO
L = High Q NPO
E = Ultra High Q NPO,
High Voltage, High
Power
G = Fully Oriented,
Ultra High-Q NPO
N = Paper 5” Reel -
L = Paper 7” Reel -
Vertically Oriented Electrodes
1
Horizontally Oriented Electrodes
1
V = Paper 7” Reel -
Part Number written:
252S48E470KV4E
Vertically Oriented Electrodes
0805 - 3838
Z = Embossed 5” Reel
E = Embossed 7” Reel
U
1
= Embossed 13” Reel
M
1
= Embossed 5” Reel -
Horizontally Oriented Electrodes
1
MARKING
3 = Cap Code
& Tolerance
4 = No Marking
6 = EIA Code
(Marking option is only available
on 0805 and larger case sizes)
Q = Embossed 5” Reel -
Vertically Oriented Electrodes
1
G = Embossed 7” Reel -
Horizontally Oriented Electrodes
1
P = Embossed 7” Reel -
Vertically Oriented Electrodes
Tape specifications
conform to EIA RS481
1
2
- Not available for all MLCC - Call factory for info.
- WVDC - Working Voltage DC.
3
