MHI1000BRWI8
Series
Compact, 10W
Ultra-High Isolation
DC/DC Converters
Electrical Specifications
Key Features:
•
10W Output Power
•
8.0 kV Isolation
•
15 kV/µS CMTI
•
Reinforced Insulation
•
EN 60950 Approved
(Pend.)
•
Wide 2:1 Input Range
•
Compact 1” x 2” Case
•
-40°C to +75°C Operation
Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Input
Parameter
Input Voltage Range
Start-Up Threshold Voltage
Under Voltage Shutdown
Short Circuit Input Power
Input Filter
Conducted EMI
Conditions
12 VDC Input
24 VDC Input
48 VDC Input
12 VDC Input
24 VDC Input
48 VDC Input
12 VDC Input
24 VDC Input
48 VDC Input
Min.
9.0
18.0
36.0
7.0
13.0
30.0
Typ.
12.0
24.0
48.0
8.0
15.0
33.0
Max.
18.0
36.0
75.0
9.0
18.0
36.0
8.5
16.0
34.0
3,000
Units
VDC
VDC
VDC
mW
(Pi)
Filter
Meets EN 55022 Class A & FCC Level A
Conditions
Dual Output, Balanced Loads
V
IN
= Min to Max
See Note 2
5 VDC Output Models
All Other Models
25% Load Step Change
Min.
Typ.
±0.5
±0.3
±0.5
Max.
±1.0
±2.0
±0.5
±1.0
100
150
600
±6.0
±0.05
Units
%
%
%
%
mV P - P
µSec
%
%
%/°C
Output
Parameter
Output Voltage Accuracy
Output Voltage Balance
Line Regulation
Load Regulation
Ripple & Noise (20 MHz)< See Note 3
Transient Recovery Time, See Note 4
Transient Response Deviation
Output Power Protection
Temperature Coefficient
Output Short Circuit
300
±3.0
120
150
±0.02
Continuous (Autorecovery)
Min.
4,000
8,000
10
15
120
Typ.
General
Parameter
Isolation Voltage, 60 Sec
Isolation Resistance
Isolation Capacitance
Common Mode Transient Immunity
Switching Frequency
Conditions
Rated For 60 Sec
Tested For 1 Sec
500 VDC
100 kHz, 1V
Max.
Units
VAC rms
VDC
G
pF
kV/µS
kHz
Units
°C
°C
%
60
150
Typ.
+25
80
180
Max.
+75
+95
+125
95
Environmental
Parameter
Operating Temperature Range
Storage Temperature Range
Cooling
Humidity
Physical
Case Size
Case Material
Weight
Conditions
Ambient
Case
Min.
-40
MicroPower Direct
292 Page Street
Suite D
Stoughton, MA 02072
USA
T:
(781) 344-8226
F:
(781) 344-8481
E:
sales@micropowerdirect.com
W:
www.micropowerdirect.com
-50
Free Air Convection
RH, Non-condensing
See Mechanical Diagram (Page 2)
Non-Conductive Black Plastic (UL94-V0)
0.86 Oz (24.5g)
Conditions
Min.
Typ.
MIL HDBK 217F, 25°C, Gnd Benign
1.0
UL 60950, EN 60950 (Pending)
Conditions
12 VDC Input
24 VDC Input
48 VDC Input
1.5 mm From Case for 10 Sec
Min.
Typ.
Max.
Units
MHours
Reliability Specifications
Parameter
MTBF
Safety Standards
Absolute Maximum Ratings
Parameter
Input Voltage Surge (0.1 Sec)
Lead Temperature
Max.
25.0
50.0
100.0
260
Units
VDC
°C
Caution: Exceeding Absolute Maximum Ratings may damage the module. These are not continuous operating ratings.
www.micropowerdirect.com
Model Selection Guide
Voltage
(VDC)
Current
(mA)
Nominal
Range
Full-Load No-Load
MHI1012S-05BRWI8
12
9.0 - 18.0
889
30
MHI1012S-05.1BRWI8
12
9.0 - 18.0
919
30
MHI1012S-12BRWI8
12
9.0 - 18.0
1,057
30
MHI1012D-12BRWI8
12
9.0 - 18.0
1,042
30
MHI1012D-15BRWI8
12
9.0 - 18.0
1,028
30
MHI1024S-05BRWI8
24
18.0 - 36.0
548
20
MHI1024S-05.1BRWI8
24
18.0 - 36.0
567
20
MHI1024S-12BRWI8
24
18.0 - 36.0
522
20
MHI1012D-12BRWI8
24
18.0 - 36.0
516
20
MHI1012D-15BRWI8
24
18.0 - 36.0
508
20
MHI1048S-05BRWI8
48
36.0 - 75.0
274
10
MHI1048S-05.1BRWI8
48
36.0 - 75.0
283
10
MHI1048S-12BRWI8
48
36.0 - 75.0
261
10
MHI1048D-12BRWI8
48
36.0 - 75.0
258
10
MHI1048D-15BRWI8
48
36.0 - 75.0
254
10
Model
Number
Input
Voltage
(VDC)
www.micropowerdirect.com
Output
Current
(mA, Max)
Current
(mA, Min)
Fuse
Efficiency Reflected Capacitive
Rating
Ripple
Load
(%, Typ)
Slow-Blow
(mA)
(µF, Max)
(mA)
5.0
5.1
12.0
±12.0
±15.0
5.0
5.1
12.0
±12.0
±15.0
5.0
5.1
12.0
±12.0
±15.0
1,600
1,600
835
±417
±333
1,600
1,600
835
±417
±333
1,600
1,600
835
±417
±333
0.0
0.0
0.0
±0.0
±0.0
0.0
0.0
0.0
±0.0
±0.0
0.0
0.0
0.0
±0.0
±0.0
75
74
79
80
81
76
75
80
81
82
76
75
80
81
82
12.0
10.0
10.0
10.0
10.0
12.0
10.0
10.0
10.0
10.0
12.0
10.0
10.0
10.0
10.0
1,000
1,000
470
220
220
1,000
1,000
470
220
220
1,000
1,000
470
220
220
2,000
2,000
2,000
2,000
2,000
1,000
1,000
1,000
1,000
1,000
600
600
600
600
600
Notes:
1. The specified maximum capacitive load is for each output.
2. Load regulation is measured over a range of 15% I
OUT
to 100% I
OUT
.
3. When measuring output ripple & noise, it is recommended that an external capacitor (0.47
µF
typ.) be placed from the
+V
OUT
to the -V
OUT
pins for single output units and from each output to common for dual output models. To further reduce
output ripple, a 3.3
µF
is recommended.
4. Transient recovery is measured to within a 1% error band for a load step change of 75% to 100%.
5. The converter should be connected to a low ac-impedance source. An input source with a highly inductive impedance
may affect the stability of the converter. In applications where the converter output loading is high and input power is
supplied over long lines, it may be necessary to use a capacitor on the input to insure start-up. In this case, it is recom-
mended that a low ESR (ESR <1.0 at 100 kHz) capacitor be mounted close to the converter. For 12V input units a
10
µF
is recommended; for 12V input units, a 4.7
µF;
and for 24V units a 2.2
µF.
6. Operation at no-load will not damage the unit, but they may not meet all specifications.
7. It is recommended that a fuse be used on the input of a power supply for protection. See the Model Selection tables for
the correct rating.
Derating Curve
IGBT Applications
Notes:
The
MHI1000x-xxB
series is a good
choice for applications involving high
speed switching, such as driving IGBTs.
They are designed to withstand the
extra stress caused by the high voltage
switching transients present in IGBT
drive circuits.
All of the
MHIxxx
series have isolation
levels that range from 5.2 to 8 kV. Many
of these have reinforced insulation. The
high isolation levels (and the correspond-
ingly low capacitive coupling rates) allow
them to be safely used in applications
with highly dynamic switched AC or DC.
Mechanical Dimensions
Pin Connections
Pin
1
7
8
9
10
16
Pin
1
7
8
9
10
16
Notes:
•
All dimensions are typical in inches (mm)
•
Tolerance x.xx = ±0.02 (±0.50)
Single Output
-V
IN
No Connection
No Connection
+V
OUT
-V
OUT
+V
IN
Dual Output
-V
IN
No Connection
Common
+V
OUT
-V
OUT
+V
IN
MicroPower Direct
We Power Your Success - For Less!
292 Page Street Ste D Stoughton, MA 02072
•
TEL: (781) 344-8226
•
FAX: (781) 344-8481
•
E-Mail: sales@micropowerdirect.com
