AHE220 Series
220 Watts
•
•
•
•
•
•
Energy Efficiency Level VI
<0.21 W Standby Power
0 °C to 60 °C Operation
High Power Density
Low Earth Leakage Current
3 Year Warranty
AC-DC Power Supplies
Dimensions:
AHE220:
7.76 x 3.46 x 1.73” (197.0 x 88.0 x 44 mm)
Models & Ratings
Output Power
180 W
220 W
Output Voltage
12.0 V
19.0 V
24.0 V
Output Current
15.0 A
11.57 A
9.16 A
Total Regulation
±5%
Efficiency
(1)
90%
92%
94%
Model Number
AHE220PS12
(2)
AHE220PS19
AHE220PS24
Notes
1. Typical efficiency measured at 100% load and 230 VAC input.
2. For IEC320-C6, add suffix 'C6' to the end of the part number e.g. AHE220PS12C6.
Mechanical Details
6
5
4
1 3
2
4
3
2
1
AHE220PS19/24
AHE220PS12
1.73
(44.0)
Power On Indicator
Mains Leads Order Part:
UK -
C14 inlet: UK-MAINS-IEC, C6 inlet: UK-MAINS-5
European -
C14 inlet: EU-MAINS-IEC, C6 inlet: EU-MAINS-5
US -
C14 inlet: US-MAINS-IEC, C6 inlet: US-MAINS-5
Rubber foot
(4 places.)
Pin Connector
AHE220PS12
Pin
1
2
3
4
Shell
AHE220PS19/24
Function
Output +
Output +
Return/Input Earth
Return/Input Earth
Return/Input Earth
7.76 (197)
3.46 (88.0)
Cable Length
0.02
(0.5)
Optional
IEC 320/C6 Inlet
(12 V model only)
AC Input
IEC 320/C14 Inlet
PS12 -
37.4” ± 1.97” (950 ± 50mm)
PS19/24 -
59.1” ± 1.97” (1500 ± 50mm)
Pin
1
2
3
4
5
6
Function
Return/Input Earth
Return/Input Earth
Return/Input Earth
Output +
Output +
Output +
Notes
1. Dimensions shown in inches (mm). Tolerance is 0.02 (0.5) maximum, except output 4. Output connector for AHE220PS12 is non locking 4 pin DC power plug and mates
cable length.
with Kycon KPJX-4S or equivalent.
2. Weight: 2.31 lb (1050 g).
Output connector for AHE220PS19/24 is molex Mini-Fit part number 39-01-2060
3. Optional output connectors available. Consult sales.
with 5556 terminals and mates with molex plug 39-01-2066 and 5558 terminals
or equivalent.
5. Mains lead length is 76” (1930 mm) approx
1
www.xppower.com
AHE220 Series
Input
Characteristic
Input Voltage
Input Frequency
Input Current
Inrush Current
Power Factor
Earth Leakage Current
No Load Input Power
Input Protection
Minimum
90
47
2.34/0.98
80/160
0.9
220
T3.15A/250 VAC internal fuse in line
250
0.21
Typical
Maximum
264
63
AC-DC Power Supplies
Units
VAC
Hz
A
A
µA
W
Notes & Conditions
Measured at 100/240 VAC
115/230 VAC, cold start at 25 °C
At 230 VAC and full load, EN61000-3-2 Class A
264 VAC, 60 Hz
Output
Characteristic
Output Voltage
Initial Set Accuracy
Minimum Load
Start Up Delay
Start Up Rise Time
Hold Up Time
Line Regulation
Total Regulation
Transient Response
Ripple and Noise
Overshoot
Overload Protection
Overvoltage Protection
Short Circuit Protection
Thermal Protection
Temperature Coefficient
115
112
Trip and restart (hiccup), auto resetting
Measured internally, auto resetting
0.04
Min.
12
Typ.
Max.
24
±2
3
40
10
±0.5
±5
4
1
5
175
160
Units
VDC
%
s
ms
ms
%
%
%
%/pk-pk
%
%
%
Notes & Conditions
See Models and Ratings table
At 50% load
No minimum load required
Full load and 115 VAC
Maximum deviation, recovering to less than 1% within
500 µs for 25% step load
Measured with 20 MHz Bandwidth and 10 µF electrolytic in
parallel with 0.1 µF ceramic capacitor.
At turn on / turn off
Recycle mains to reset
%/°C
Environmental
Characteristic
Operating Temperature
Cooling
Operating Humidity
Storage Temperature
Operating Altitude
Shock
Vibration
Minimum
0
Natural convection
5
-10
Typical
Maximum
+60
Units
°C
Notes & Conditions
Derate from 100% load at 40 °C to 50% load at 60 °C
Non-condensing
90
%RH
+80
°C
5000
m
IEC68-2-27, 30 g, 11 ms half sine, 3 times in each of 6 axes
IEC68-2-6, 10-500 Hz, 2 g 10 mins/sweep, 60 mins for each of 3 axes
Derating Curve
Output Power (%)
100%
80%
60%
40%
20%
0
20
40
Ambient Temperature (ºC)
60
www.xppower.com
2
AHE220 Series
General
Characteristic
Efficiency
Isolation: Input to Output
Input to Ground
Output to Ground
Switching Frequency
Power Density
Mean Time Between Failure
Weight
3000
1500
75
4.55
>500
2.31 (1050)
150
Minimum
Typical
91
Maximum
AC-DC Power Supplies
Units
%
VAC
VAC
VAC
kHz
W/in
3
kHrs
lb (g)
Notes & Conditions
See Models and Ratings table and curves.
Output return is connected to input earth
SR332 at 25 °C GB
Efficiency Curves
AHE220PS12
100%
90%
Efficiency
80%
115Vac input
70%
60%
50%
230Vac input
10
20
30
40
50
60
70
80
90
100
AHE220PS24
100%
90%
Efficiency
80%
Load (%)
115Vac input
70%
60%
50%
230Vac input
10
20
30
40
50
60
70
80
90
100
Load (%)
EMC: Emissions
Phenomenon
Emissions
Harmonic Current
Voltage Flicker
Standard
EN55022
EN61000-3-2
EN61000-3-3
Test Level
Level B
Class A
Notes & Conditions
Conducted & Radiated
EMC: Immunity
Phenomenon
ESD
Radiated
EFT/Burst
Surge
Conducted
Magnetic Fields
Dips and Interruptions
Standard
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
EN61000-4-8
EN61000-4-11
Test Level
±15 kV Air, ±8kV contact
3 V/m
2
Installation Class 3
3V
3 A/m
Dip: 30% 500 ms
Dip: 60% 200 ms
Int: 100% 5000 ms
Int: 100% 10 ms
Criteria
A
A
A
A
A
A
A
A/B
B
A
Notes & Conditions
High Line/Low Line
www.xppower.com
3
AHE220 Series
Safety Approvals
Safety Agency
UL
TUV
CB
Safety Standard
cUL60950-1
EN60950-1
IEC60950-1
AC-DC Power Supplies
Notes & Conditions
Mechanical Details
6
5
4
1 3
2
4
3
2
1
AHE220PS19/24
AHE220PS12
1.73
(44.0)
Power On Indicator
Rubber foot
(4 places.)
Cable Length
PS12 -
37.4” ± 1.97” (950 ± 50mm)
PS19/24 -
59.1” ± 1.97” (1500 ± 50mm)
7.76 (197)
Mains Leads Order Part:
UK -
C14 inlet: UK-MAINS-IEC, C6 inlet: UK-MAINS-5
European -
C14 inlet: EU-MAINS-IEC, C6 inlet: EU-MAINS-5
US -
C14 inlet: US-MAINS-IEC, C6 inlet: US-MAINS-5
Pin Connector
AHE220PS12
3.46 (88.0)
Pin
1
2
3
4
Shell
AHE220PS19/24
Function
Output +
Output +
Return/Input Earth
Return/Input Earth
Return/Input Earth
Optional
IEC 320/C6 Inlet
(12 V model only)
AC Input
IEC 320/C14 Inlet
Pin
1
2
3
4
5
6
Function
Return/Input Earth
Return/Input Earth
Return/Input Earth
Output +
Output +
Output +
Notes
1. Dimensions shown in inches (mm). Tolerance is 0.02 (0.5) maximum,
except output cable length.
2. Weight: 2.31 lb (1050 g).
3. Optional output connectors available. Consult sales.
4. Output connector for AHE220PS12 is non locking 4 pin DC power plug and mates
with Kycon KPJX-4S or equivalent.
Output connector for AHE220PS19/24/48 is molex Mini-Fit part number
39-01-2060 with 5556 terminals and mates with molex plug
39-01-2066 and 5558 terminals or equivalent.
5. Mains lead length is 76” (1930 mm) approx
0.02
(0.5)
www.xppower.com
08-Oct-15
