Only One Name Means ProTek’Tion™
GBLC05CDN - GBLC24CDN
ULTRA LOW CAPACITANCE TVS ARRAY
DESCRIPTION
The GBLCxxCDN Series are ultra low capacitance transient voltage suppressor arrays, designed to protect applications
such as portable electronics and SMART phones. This series is available in a bidirectional configuration and is rated at
350 Watts for an 8/20µs waveshape.
The GBLCxxCDN Series meets IEC 61000-4-2 (ESD) and IEC 61000-4-4 (EFT) requirements. At higher operating
frequencies or faster edge rates, insertion loss and signal integrity are a major concern. This series offers a ultra low
capacitance and low leakage current in a miniature DFN-2 package.
DFN-2 PACKAGE
FEATURES
•
Compatible with IEC 61000-4-2 (ESD): Air - 15kV, Contact - 8kV
Exceeds Level 4: Handles 10kV Contact & 25kV Air Discharge
•
Compatible with IEC 61000-4-4 (EFT): 40A - 5/50ns
•
Compatible with IEC 61000-4-5 (Surge)
•
350 Watts Peak Pulse Power per Line (tp = 8/20µs)
•
Replacement for MLV (0805)
•
Bidirectional Configuration
•
Protects One Power or I/O Port
•
ESD Protection > 25kV
•
Low Clamping Voltage
•
Available in Multiple Voltages Ranging From 5V to 24V
•
Ultra Low Capacitance: 3pF (Typical)
• RoHS Compliant
• REACH Compliant
APPLICATIONS
•
•
•
•
Ethernet 10/100/1000 Base T
SMART Phones
Handheld - Wireless Systems
USB Interface
MECHANICAL CHARACTERISTICS
Molded JEDEC DFN-2 Package
Approximate Weight: 0.8 milligrams
Lead-Free Pure-Tin Plating (Annealed)
Solder Reflow Temperature:
Pure-Tin - Sn, 100: 260-270°C
•
8mm Tape and Reel Per EIA Standard 481
•
Flammability Rating UL 94V-0
•
•
•
•
PIN CONFIGURATION
1
2
05415.R1 11/13
Page 1
www.protekdevices.com
05415
Only One Name Means ProTek’Tion™
GBLC05CDN - GBLC24CDN
TYPICAL DEVICE CHARACTERISTICS
MAXIMUM RATINGS
@ 25°C Unless Otherwise Specified
PARAMETER
Peak Pulse Power (tp = 8/20µs) - See Figure 1
Operating Temperature
Storage Temperature
SYMBOL
P
PP
T
A
T
STG
VALUE
350
-55 to 150
-55 to 150
UNITS
Watts
°C
°C
ELECTRICAL CHARACTERISTICS PER LINE
@ 25°C Unless Otherwise Specified
PART
NUMBER
DEVICE
MARKING
RATED
STAND-OFF
VOLTAGE
V
WM
VOLTS
GBLC05CDN
GBLC08CDN
GBLC12CDN
GBLC15CDN
GBLC24CDN
5C
8C
2C
6C
4C
5.0
8.0
12.0
15.0
24.0
MINIMUM
BREAKDOWN
VOLTAGE
@ 1mA
V
(BR)
VOLTS
6.0
8.5
13.3
16.7
26.7
MAXIMUM
CLAMPING
VOLTAGE
(Fig. 2)
@ IP = 1A
V
C
VOLTS
9.8
13.4
19.0
24.0
43.0
MAXIMUM
CLAMPING
VOLTAGE
(Fig. 2)
@ 8/20µs
V
C
@ I
PP
18.3V @ 17.0A
18.5V @ 17.0A
26.5V @ 11.0A
31.8V @ 10.0A
56.0V @ 6.0A
MAXIMUM
LEAKAGE
CURRENT
@V
WM
I
D
µA
5
2
1
1
1
TYPICAL
CAPACITANCE
@0V, 1MHz
C
pF
3
3
3
3
3
05415.R1 11/13
Page 2
www.protekdevices.com
05415
Only One Name Means ProTek’Tion™
GBLC05CDN - GBLC24CDN
TYPICAL DEVICE CHARACTERISTICS
FIGURE 1
PEAK PULSE POWER VS PULSE TIME
10,000
P
PP
- Peak Pulse Power - Watts
1,000
350W, 8/20µs Waveform
100
10
0.1
1
10
100
t
d
- Pulse Duration - µs
1,000
10,000
120
I
PP
- Peak Pulse Current - % of I
PP
FIGURE 2
PULSE WAVE FORM
t
f
Peak Value I
PP
TEST
WAVEFORM
PARAMETERS
t
f
= 8µs
t
d
= 20µs
100
80
60
40
20
0
0
5
e
-t
t
d
= t/(I
PP
/2)
10
15
t - Time - µs
20
25
30
05415.R1 11/13
Page 3
www.protekdevices.com
05415
Only One Name Means ProTek’Tion™
GBLC05CDN - GBLC24CDN
SPICE MODEL
FIGURE 1
SPICE MODEL
I/O
ABD
LCRD
LCRD
LCRD
Lg
0.6nH
Lg
0.6nH
ABD
ABD
I/O
LCRD
UNIDIRECTIONAL
BIDIRECTIONAL
ABD - Avalanche Breakdown Diode (TVS)
LCRD: Low Capacitance Rectifier Diode
Lg - Lead Inductance
TABLE 1 - SPICE PARAMETERS
PARAMETER
BV
IBV
C
jo
I
S
Vj
M
N
R
S
TT
EG
UNIT
V
µA
pF
A
V
-
-
Ohms
s
eV
ABD(TVS)
See Table 2
1
See Table 2
See Table 2
0.6
0.33
1
See Table 2
1E-8
1.11
LCRD
200
0.01
6
1E-11
0.6
0.33
1
0.75
1E-9
1.11
PART NUMBER
GBLC05CDN
GBLC08CDN
GBLC12CDN
GBLC15CDN
GBLC18CDN
GBLC24CDN
TABLE 2 - ABD SPECIFIC SPICE PARAMETERS
I
S
(AMPS)
B
V
(VOLTS)
C
jo
(
p
F)
6.0
8.5
13.3
16.7
20.0
26.7
284
146
123
102
80
61
1E-11
1E-11
1E-13
1E-13
1E-13
1E-13
R
s
(OHMS)
0.14
0.28
0.40
0.52
0.80
1.54
05415.R1 11/13
Page 4
www.protekdevices.com
